P-COM Plus common
IN1/ALM General-purpose input1/Alarm input
IN2/INP General-purpose input2/Positionig input
IN3/SD General-purpose input3/Slow down input
IN4/LTC General-purpose input4/counter latch input
General-purpose input5/positioning
IN5/PCS
operation start input
IN6 General-purpose input6
IN7 General-purpose input7
ORG Origin input
+LIM Positive-direction limit
-LIM Negative-direction limit
A+ Encoder phaseA input+
A- Encoder phaseA input-
Figure 3.3. Pin Assignments of Interface Connector (CNA, CNB) (2/2) < SMC-8DL-PCI >
SMC-4DL-PCI, SMC-8DL-PCI
B+ Encoder phaseB input+
B- Encoder phaseB input-
Z+ Encoder phaseZ input+
Z- Encoder phaseZ input-
OUT1 General-purpose output1
OUT2 General-purpose output2
OUT3 General-purpose output3
DIR+/CCW+ Direction/CCW output+
DIR-/CCW- Direction/CCW output-
OUT+/CW+ Pulse/CW output+
OUT-/CW- Pulse/CW output-
Power ground input (common to internal
GND
GND)
