LOOP-BACK

With the use of an IP-Debug-IO plus the software contained in the UserAp for the IP-
429-II Loop-Back can be performed. The following table shows the connections used
for the Dynamic Engineering test software. There are 4 possible devices and all are
shown. The first set is for Device 1. The first entry is for the A signal and the second
for the B.
The second table is for the Parallel Port. The lower signals are tied to the upper.
TX CH1
7 1
8 2
16 10
17 11
26 19
27 20
35 29
36 30
PIO
41 45
42 46
43 47
44 48
CH2
4
5
13
14
22
23
32
33
