Address Map

Function
// IP 429 relative addresses //
#define IP429II_BASE_REG0
#define IP429II_BASE_REG1
#define IP429II_BASE_REG2
#define IP429II_BASE_REG3
#define IP428II_VECTOR
#define IP429II_STATUS0
#define IP429II_STATUS1
#define IP429II_PARALLEL
#define IP429II_INFO
#define IP429II_TS_DEV1_CH1_LWR 0x14
#define IP429II_TS_DEV1_CH1_UPR
#define IP429II_TS_DEV1_CH2_LWR 0x18
#define IP429II_TS_DEV1_CH2_UPR
#define IP429II_TS_DEV2_CH1_LWR
#define IP429II_TS_DEV2_CH1_UPR
#define IP429II_TS_DEV2_CH2_LWR
#define IP429II_TS_DEV2_CH2_UPR
#define IP429II_TS_DEV3_CH1_LWR
#define IP429II_TS_DEV3_CH1_UPR
#define IP429II_TS_DEV3_CH2_LWR
#define IP429II_TS_DEV3_CH2_UPR
#define IP429II_TS_DEV4_CH1_LWR
#define IP429II_TS_DEV4_CH1_UPR
#define IP429II_TS_DEV4_CH2_LWR
#define IP429II_TS_DEV4_CH2_UPR
#define IP429II_OE0_DEV1_L
#define IP429II_OE0_DEV1_U
#define IP429II_OE1_DEV1_L
#define IP429II_OE1_DEV1_U
#define IP429II_LD1_DEV1
#define IP429II_LD2_DEV1
#define IP429II_CNTL_DEV1
#define IP429II_OE0_DEV2_L
#define IP429II_OE0_DEV2_U
#define IP429II_OE1_DEV2_L
IO Space
Offset Width
0x00 // byte on word boundary
0x02 // byte on word boundary
0x04 // byte on word boundary
0x06 // byte on word boundary
0x08 // byte on word boundary
0x0a // byte on word boundary
0x0c // byte on word boundary
0x0e // byte on word boundary
0x10 // Driver info register word
Time Tag Device 1 receiver 1 D15..D0 read only
0x16 Time Tag Device 1 receiver 1 D31..D16 read only
Time Tag Device 1 receiver 2 D15..D0 read only
0x1A Time Tag Device 1 receiver 2 D31..D16 read only
0x1C Time Tag Device 2 receiver 1 D15..D0 read only
0x1E Time Tag Device 2 receiver 1 D31..D16 read only
0x20 Time Tag Device 2 receiver 2 D15..D0 read only
0x22 Time Tag Device 2 receiver 2 D31..D16 read only
0x24 Time Tag Device 3 receiver 1 D15..D0 read only
0x26 Time Tag Device 3 receiver 1 D31..D16 read only
0x28 Time Tag Device 3 receiver 2 D15..D0 read only
0x2A Time Tag Device 3 receiver 2 D31..D16 read only
0x2C Time Tag Device 4 receiver 1 D15..D0 read only
0x2E Time Tag Device 4 receiver 1 D31..D16 read only
0x30 Time Tag Device 4 receiver 2 D15..D0 read only
0x32 Time Tag Device 4 receiver 2 D31..D16 read only
0x40 // read from Device 1 port 1 lower half
0x42 // read from Device 1 port 1 upper half
0x44 // read from Device 1 port 2 lower half
0x46 // read from Device 1 port 2 upper half
0x48 // write to Device 1 TX port lower half
0x4a // write to Device 1 TX port upper half
0x4c // write to Device 1 control word
0x50 // read from Device 2 port 1 lower half
0x52 // read from Device 2 port 1 upper half
0x54 // read from Device 2 port 2 lower half
Embedded Solutions
Type
Page 10
