10.98
CAUTION
d
b
e
c
a
Sitting
Siemens AG
6SE7087-6KP50
SIMOVERT MASTERDRIVES
Components which can be destroyed by electrostatic discharge (ESD)
The board contains components which can be destroyed by
electrostatic discharge. These components can be easily destroyed if
not carefully handled. If you have to handle electronic boards, please
observe the following:
Electronic boards should only be touched when absolutely necessary.
The human body must be electrically discharged before touching an
electronic board.
Boards must not come into contact with highly insulating materials - e.g.
plastic parts, insulated desktops, articles of clothing manufactured from
man-made fibers.
Boards must only be placed on conductive surfaces.
Boards and components should only be stored and transported in
conductive packaging (e.g. metalized plastic boxes or metal
containers).
If the packing material is not conductive, the boards must be wrapped
with a conductive packaging material, e.g. conductive foam rubber or
household aluminium foil.
The necessary ESD protective measures are clearly shown again in the
following diagram:
♦ a = Conductive floor surface
♦ b = ESD table
♦ c = ESD shoes
♦ d = ESD overall
♦ e = ESD chain
♦ f = Cubicle ground connection
f
f
c
Standing
Fig. 1-1
ESD protective measures
Operating Instructions
d
f
f
a
Definitions and Warnings
b
d
e
f
c
a
Standing / Sitting
1-3
