testing mode (SETUP command) 35
SETUP command (enter testing and
setup mode) 35
SHOW command (display power
output) 36
Site selection 7
SKIP command (set/display frequency
zone to skip) 36
SLEEP command (display/set radio's
sleep setting) 37
Sleep Mode 18
Spread spectrum, basic principles of 3
SREV command (display transceiver
software version) 37
STAT command (list alarms) 37
Store-and-Forward (SAF) 5, 22, 25, 26,
32, 35, 39, 46, 49
SWR (Standing Wave Ratio)
performance optimization 20
Synchronization qualifiers 39, 46
T
Tables
accessories 5
alarm codes 41
antenna system gain vs. power output
setting 12
DATA INTERFACE connector pin
descriptions 55
LED status indicators 19, 40
troubleshooting 42
MDS 05-2708A01, Rev. B
Tail-end link
cable wiring for, illustrated 17
illustrated 4
installation 17
Technical specifications 53-54
TEMP command (display internal
temperature) 37
Temperature, display internal (TEMP
command) 37
Transceiver
connecting to data equipment 14, 21
default settings 33
mounting
instructions/dimensions 13-14
performance optimization 19
sleep mode 18
Troubleshooting 39-42
performing network-wide
diagnostics 43
table 42
X
XADDR (extended address
command) 16, 26, 32, 33, 38, 39, 46,
50
XMAP command (32-bit hex entry) 38
XPRI command (display/set extended
address) 38
XRSSI command (sets minimum RSSI
level to maintain sync. w/non-primary
extension radio) 38
