• The radio can be keyed using the
the radio. (If the radio is left in a keyed state it is automatically unkeyed
after several minutes.)
• The is sampled in a raw, continuous fashion regardless of whether
RSSI
the unit is a master or a remote.
Entering or
Q QUIT
A timer keeps the Setup mode from accidentally leaving the system disabled.
After 10 minutes the system behaves as if
returning to normal operation.

SER

Displays the Serial Number of the radio.

SHOW PWR

The
SHOW PWR
in dBm. Unlike the
being measured, not the programmed RF power setting.

SHOW SYNC

When used at a Remote station, this command will display
and
Unit Address
synchronized. The network depth at the remote, defined as the number of
downstream links from the Master, is displayed in parentheses.

SKIP [NONE, 1...8]

This command sets or displays which, if any, of the eight 3.2 MHz-wide
zones will be skipped from the radio's hopping sequence. Skipping zones is
one way of dealing with constant interference on one or more frequencies.
See "A Word About Radio Interference" on page 9
dealing with interference.
Table 11 shows the frequency range covered by each zone. The command
parameter is either the keyword
digits where each digit 1...8 represents a corresponding zone to skip. (For
zone parameter input, the digits can appear in any order and can be optionally
separated by a blank space.) The
radios. (Remotes must be synchronized with the master radio to display the
skip status.)
In the USA, a maximum of four zones may be skipped, per FCC rules. Check
the regulatory requirements for your region.
ZONE 1 ZONE 2
902.200 905.400
to to
905.200 908.400
36 MDS TransNET 900 I&O Guide
returns the system to normal operation.
command displays the actual (measured) RF power output
command, this command shows the actual level
PWR
of the Master or Extension radio to which the Remote is
NONE
SKIP
Table 11. Frequency Zones
ZONE 3 ZONE 4
908.600 911.800
to to
911.600 914.800
command.
KEY DKEY
or had been entered,
Q QUIT
for more information on
or an undelimited string of up to four
command is display-only at remote
ZONE 5 ZONE 6
915.000 918.200
to to
918.000 921.200
MDS 05-2708A01, Rev. B
is used to unkey
Extended Address
ZONE 7 ZONE 8
921.400 924.600
to to
924.400 927.600
