Table 7. Operational Configuration—Set/Program (Continued)
Command
RXTOT [NONE, 0–1440]
Details, page 35
RTU [ON, OFF, 0-80]
Details, page 35
SLEEP [ON, OFF]
Details, page 37
UNIT [10000–65000]
Details, page 37
XADDR [0–31]
Details, page 38
XPRI [0–31]
Details, page 38
XMAP [00000000-FFFFFFFF]
Details, page 38
XRSSI [NONE, –40...–120]
Details, page 38
ZONE CLEAR
Details, page 38
Table 8. Operating Status—Display Only
Command
ADDR
Details page 27
AMASK
Details page 28
ASENSE
Details page 28
BAUD
Details page 28
BUFF
Details page 28
CODE
Details page 29
24 MDS TransNET 900 I&O Guide
Description
Maximum duration (in minutes) before
time-out alarm. Default is OFF.
Enable or Disable unit's built-in RTU simula-
tor. Default is OFF. Set RTU address between
zero and 80.
Enable or Disable the radio's Sleep mode
function.
Unit address used for network-wide diagnos-
tics. (Unique within associated network.)
This unit's Extended address
Typically, the Master is set to zero (0).
Address of the primary Extended radio unit

(Extension).

Included Extended units in MODE X. (Exten-
sions and Remotes only).
Minimum RSSI level required to preserve syn-
chronization with a non-primary radio.
(Only meaningful when XPRI is not NONE)
Reset zone data statistics
Description

Network address

Alarm mask (response)
Current sense of the alarm output.
Data communication parameters. Example:
BAUD 9600 8N1
Data buffering mode: ON = seamless data,
OFF = fast byte throughput
Security/encryption operational status.
"NONE" (Inactive), or "ACTIVE"
