Package Contents; Install Prosoft Configuration Builder Software - ProSoft Technology inRAx MVI46-GEC User Manual

MVI46-GEC ♦ SLC Platform
Generic ASCII Ethernet Interface Module
16-color VGA graphics adapter, 640 x 480 minimum resolution (256 Color
800 × 600 recommended)
CD-ROM drive
3.5 inch floppy disk drive
HyperTerminal or other terminal emulator program capable of file transfers
using Zmodem protocol.
1.2

Package Contents

The following components are included with your MVI46-GEC module, and are
all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Qty. Part Name
1 MVI46-GEC
Module
1 Cable
1 Cable
1 inRAx
Solutions
CD
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
1.3

Install ProSoft Configuration Builder Software

You must install the ProSoft Configuration Builder (PCB) software in order to
configure the MVI46-GEC module. You can always get the newest version of
ProSoft Configuration Builder from the ProSoft Technology web site.
To install ProSoft Configuration Builder from the ProSoft Web Site
Open your web browser and navigate to http://www.prosoft-
1
technology.com/pcb
Click the Download Here link to download the latest version of ProSoft
2
Configuration Builder.
Page 10 of 78
Part Number Part Description
MVI46-GEC Generic ASCII Ethernet Interface Module
Cable #15, RS232 For RS232 Connection to the CFG Port
Null Modem
RJ45 to DB9 Male
For DB9 Connection to Module's Port
Adapter
Contains sample programs, utilities and
documentation for the MVI46-GEC module.
Start Here
ProSoft Technology, Inc.
April 30, 2008
