Module Configuration
Module Entries
To configure module parameters
Click on the plus sign next to the icon
1
information.
Double-click the
2
To edit a parameter, select the parameter in the left pane and make your
3
changes in the right pane.
Click OK to save your changes.
4
Comment Entries
To add comments to your configuration file:
Click the plus sign to the left of the
1
Comments.
Double-click the
2
appears.
Enter your comment and click OK to save your changes.
3
Printing a Configuration File
To print a configuration file:
Select the Module icon, and then click the right mouse button to open a
1
shortcut menu.
On the shortcut menu, choose View Configuration. This action opens the
2
View Configuration window.
On the View Configuration window, open the File menu, and choose Print.
3
This action opens the Print dialog box.
On the Print dialog box, choose the printer to use from the dropdown list,
4
select printing options, and then click OK.
ProSoft Technology, Inc.
April 30, 2008
Generic ASCII Ethernet Interface Module
to expand module
icon to open the Edit dialog box.
icon to expand the Module
icon. The Edit - Module Comment dialog
MVI46-GEC ♦ SLC Platform
