ProSoft Technology inRAx MVI46-GEC User Manual page 60

MVI46-GEC ♦ SLC Platform
Generic ASCII Ethernet Interface Module
Object In GSCInStat
Server[0].Enabled
Server[0].State
Server[0].IP
Server[0].Port
Server[0].Open
Server[0].Established
Server[0].Closed
Server[0].RxCount
Server[0].RxOverflow
Server[0].TxCount
Server[0].TxOverflow
Server[0].Timeout
Server[0].CfgErrWord
Server[1].Enabled
Server[1].State
Server[1].IP
Server[1].Port
Server[1].Open
Server[1].Established
Server[1].Closed
Server[1].RxCount
Server[1].RxOverflow
Server[1].TxCount
Page 60 of 78
Block Description
Offset
Start
115 This flag defines if the server is utilized. A value of 0 indicates
the server is not used. Any other value indicates the server is
used.
116 This flag defines the current state of the server.
117 This double-word value contains the IP address of the client
connected to the server.
119 This word value contains the port address for the client
connected to the server.
120 This status value contains the total number of times the server
performed an open operation.
121 This status value contains the total number of times a
connection was established on the socket.
This status value contains the total number of times a close
122
operation was performed on the socket.
123 This status value contains the total number of messages
received by the server.
124 This status value contains the total number of messages
received that exceed the specified buffer size for the server.
125 This status value contains the total number of messages
transmitted by the server.
126 This status value contains the total number of transmit
messages that exceeded the specified maximum buffer size
for the server.
127 This status value contains the total number of times a
connection timeout occurred on the socket.
This bit mapped word defines the configuration errors for the
128
server.
129 This flag defines if the server is utilized. A value of 0 indicates
the server is not used. Any other value indicates the server is
used.
130 This flag defines the current state of the server.
131 This double-word value contains the IP address of the client
connected to the server.
133 This word value contains the port address for the client
connected to the server.
134 This status value contains the total number of times the server
performed an open operation.
135 This status value contains the total number of times a
connection was established on the socket.
136 This status value contains the total number of times a close
operation was performed on the socket.
137 This status value contains the total number of messages
received by the server.
This status value contains the total number of messages
138
received that exceed the specified buffer size for the server.
139 This status value contains the total number of messages
transmitted by the server.
Reference
ProSoft Technology, Inc.
April 30, 2008
