Set Module Parameters - ProSoft Technology inRAx MVI46-GEC User Manual

MVI46-GEC ♦ SLC Platform
Generic ASCII Ethernet Interface Module
Adding a Project
To add a project to an existing project file:
Select the Default Project icon.
1
Choose Project from the Project menu, then choose Add Project. A new
2
project folder appears.

2.3.2 Set Module Parameters

Notice that the contents of the information pane and the configuration pane
changed when you added the MVI46-GEC module to the project.
At this time, you may wish to rename the "Default Project" and "Default Location"
folders in the tree view.
To rename an object:
Select the object, and then click the right mouse button to open a shortcut
1
menu. From the shortcut menu, choose Rename.
Type the name to assign to the object.
2
Click away from the object to save the new name.
3
Page 24 of 78
Module Configuration
ProSoft Technology, Inc.
April 30, 2008
