C C o o n n s s o o l l e e O O p p e e r r a a t t i i o o n n s s
Talkback
Talkback switches:
Listen switch:
Red light switch:
TB switches disable Listen:
TB to FB:
See Communications for more details of these options

Monitor section

Monitor Gain Display:
Monitor Set CAL level:
See Monitor Level Display and Calibrated listening level for more details of these options
Solo Gain boost:
Isolated channels AFL on solo:
Desk Setup
Stereo Mix Insert Mode
Input Cut Enable
Analogue Meter Scaling
2 2 - - 4 4 4 4
Select the operation of the talkback buttons: Momentary / Latching
/ Auto (Play) / Auto (Record).
Select the operation of the Listen buttons: Latching / Auto (Play) /
Auto (Record).
Select the operation of the Red Light switch: Manual / Auto (Play) /
Auto (Record).
This allows the Listen function to be switched off when talkback is
activated, thus avoiding feedback problems.
(Sums / Replaces) When assigning talkback to foldbacks, this option
defines whether talkback sums with or replaces the normal foldback
signal.
The calibration of the main monitor Gain pot and display can be set
to one of three industry-standard monitoring modes: Music (Off to
11) / Film (Off to 95dB) / Gain (Off to 0dB)
When in Film monitoring mode, the calibrated listening level can be
adjusted: 70 - 90 (dB).
When auditioning signals which are low in the mix, it is possible to
boost the solo bus signal level (Range: 0-10dB).
Set solo-isolated channels to automatically solo in AFL (ON/OFF).
This enables the stereo mix matrix 'SUM' option to be selected,
where the insert return sums with the main signal path. Select
REPLACE to disable this function.
If set ON, the channel strip CUT button will cut prefade sends, ie.
Aux and CHOP sends (ON / OFF).
Set the analogue level corresponding to 0dBfs on the console meters.
(Range 18, 20, 22, 24 dBu).
