Monitor Options

A wide range of monitor options are available via the soft keys and associated display on the monitor panel. Pressing
the MONITOR OPTIONS button above the display produces the following choices; press the button below an
entry to select that option.
INS — Switches the encoder/decoder insert into the monitor path for use with 5.1 monitor sources selected via
the EXT B monitor selector.
PFM — Routes the PFL signal to the Mini A or B loudspeakers. In this mode, PFL level is controlled by the PFL level
control only — the Main and Mini monitor level controls have no effect.
SRA — Both sets of Main speaker outputs are capable of handling six channels. If you are mixing in 5.1 and the client
turns up with an alternative set of 'front' (LCR) speakers only, the surround feeds may be locked to the Main 5.1
(Main A) outputs by selecting the SRA ('Surround on A') function. This allows you to switch to the alternative LCR
speakers, connected to the ALT 5.1 (Main B) output, and still maintain full surround monitoring. A further option
(A2B — see next page) enables the subwoofer output to be included in this arrangement.
LRA — Similar to the SRA function except that the LCR monitor feeds are locked to the Main A outputs but an
alternative set of surround speakers may be selected by switching to the Main B output. This can be useful in rooms
that work on both music, using full bandwidth separate surround speakers, and film using multiple lower powered
surround speakers.

Bass Management

BASS — Selecting this option produces a further layer of bass management options (see following pages for options
held under CAL):
80H — Inserts a 7th order, 80Hz, low pass filter into the LFE monitor bus, to deal with listening to 5.1 material
that has a full range, unfiltered, LFE channel.
