DAW setup
The next few items in the Setup menu are concerned with DAW interconnection, but are included here for
completeness; see Section 3 for more details. Note that changes to any of these DAW settings will require a console
reboot before they take effect: hold down the Restart softkey and press the Confirm softkey which appears to
its right.
Transport lock layer*:
DAW 1 Jog wheel sends:
MIDI connects via: **
DAW 1:
DAW 2*
First physical channel DAW 1:
Channel Count DAW 1:
Single Layer*:
* Not displayed if MIDI connects via: MIDI Ports is selected.
** Only displayed if the DualitySE software features have been enabled
Desk settings
Scribble Strip Brightness
TFT Backlight Brightness
Turn Off Display After
Console Channel Count
Note that TFT and scribble strip displays can each be turned off by turning the control pot clockwise
(beyond 8 or 6) to 'Off '.
D D u u a a l l i i t t y y S S E E O O p p e e r r a a t t o o r r ' ' s s M M a a n n u u a a l l
Select the master DAW layer for transport control between DAW
1, DAW 2 or Off.
Define the control data sent by the jog wheel for HUI DAWs.
Options are Jog / Nudge (40 / 20 / 13 / 10 / 8 / 6 / 5 per revolution).
When DAW 2 is HUI, there is a DAW 2 Jog wheel sends*:
menu entry.
Select the ports used for MIDI connections: MIDI Ports (the physical
MIDI ports on the console) or Network (MIDI over Ethernet).
Select from Protools HUI / Logic / Logic Handshake / Nuendo /
Digital Performer / Sonar
Select from Protools HUI / Logic / Logic Handshake / Nuendo /
Digital Performer / Sonar / None
Select the console channel number that is controlling the first track
number on DAW 1. When DAW 2 is assigned, there is a First
physical channel DAW 2*: menu entry.
Select the total number of channels dedicated to DAW control (8-
48 in steps of 8). When DAW 2 is assigned, there is a Channel
Count DAW 2*: menu entry.
Assign both DAWs to a single layer (ON/OFF).
Use this to adjust the channel scribble strip brightness (range: 1-6)
Use this to adjust the backlight level (range: 1-8)
Shuts off the TFT display after a predetermined time: 30 mins to 5
hours in 30 minute increments.
Should be set to the size of your console: 24, 48, 72 or 96. This setting
determines the range of channels selected by the Central Routing
Panel's ALL button.
C C o o n n s s o o l l e e O O p p e e r r a a t t i i o o n n s s
2 2 - - 4 4 5 5
