Introducing the CIO-DIO96

The CIO-DIO96 is a 96-bit digital I/O board with four 82C55 parallel-interface chips. The board provides the

96 bits in 24-bit groups based on the 82C55 specification.

Each 82C55 chip controls 24 CMOS/TTL-compatible digital I/O pins. Each 24-bit group is divided into three

eight-bit ports, or two 8-bit ports and two 4-bit ports. Each port is programmable for input or output.

All I/O bits are set to input mode (high impedance) on power up and reset. Locations are available for installing

pull-up or pull-down resistors.

All signals pass through a 50-pin connector.

For information on the features of InstaCal and the other software included with your CIO-DIO96, refer to the

Quick Start Guide that shipped with your device. The Quick Start Guide is also available in PDF at

www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.

Check

www.mccdaq.com/download.htm

for the latest software version.
