Page 1: User Manual
User Manual 1/2,8" HD Camera, Day&Night, 1920x1080, WDR, 30x AF Zoom, 4,3-129mm, Indoor MPC-52A0030P0A... - Page 2 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK)
-
Page 3: Fcc Compliance Statement
FCC COMPLIANCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC INFORMATION: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 5: Table Of Contents
Table of Contents Chapter 1 — Introduction ....................6 1.1 Features ..........................6 Chapter 2 — Installation and Configuration ..............7 2.1 Package Contents ......................7 2.2 Setting Camera ........................7 2.3 Connections ........................8 2.4 Getting Started ........................9 Chapter 3 —... -
Page 6: Chapter 1 - Introduction
Chapter 1 — Introduction 1.1 Features • Built-in optical power zoom camera with True Night Shot function • 240 Preset positions with the individual camera AE setup • 8 Tours consist of Presets • 16 Privacy Zones • 1 Alarm input, 1 Alarm output (5VTTL) •... -
Page 7: Chapter 2 - Installation And Configuration
Chapter 2 — Installation and Configuration 2.1 Package Contents The package contains the following. * Dome Camera * Instruction Manual (This Document) 2.2 Setting Camera SW905 You can set video signal with D1 and video type with D2 in SW905. SW905-D1 Video Signal SW905-D2... -
Page 8: Connections
2.3 Connections • Connecting to the RS-485/422 The camera can be controlled remotely by an external device or control system, such as a control keyboard, using RS-485 half-duplex, RS-422 full-duplex serial communications signals. Connect Marked TX+(485+), TX-(485-) to TX+(RX+), TX-(RX-) of the RS-485 control system. If control system is RS-422, connect TX+(485+), TX-(485-) and RX+, RX- of the camera to RX+, RX- and TX+, TX- of the control device respectively. -
Page 9: Getting Started
2.4 Getting Started Once installed apply power to the camera. The camera will start a configuration sequence. STATUS of FUNCTION TITLE AF AE FOCUS and AE INFORMATION EMPTY DATA DISPLAY ALARM:1 ALARM DISPLAY CAM ID:0001 CAMERA TITLE & ID OSD Position... -
Page 10: Chapter 3 - Program And Operation
Chapter 3 — Program and Operation 3.1 Camera Selection IF you use the keyboard, before you program or operate a camera, you must select the camera by pressing No. + CAM keys. Example: Pressing 1 , 0 + CAM keys sequentially will select camera 10. The selected camera ID will be displayed on the LCD monitor of the keyboard. -
Page 11: Preset
3.4 Preset If you need to view specific places routinely, you should program Presets. A Preset is a programmed video scene with automatic pan, tilt, zoom, focus, and AE settings. In addition, Presets may be assigned the “home” position for the camera. As many as 240 Presets, whose positions are saved in the camera’s firmware, may be programmed. - Page 12 6. Select “CAMERA SET” and press the Right or Left key. Then the Preset camera setup displays. PRESET CAMERA SETUP FOCUS : AUTO MOTION : OFF MOTION SETUP AE SETUP SAVE AND EXIT(ESC TO CANCEL) Set FOCUS AUTO, MANUAL Set MOTION OFF, ON Select “MOTION SETUP”...
-
Page 13: Tour
3.5 Tour There are 8 programmable Tours. Each Tour consists of up to 40 Preset positions, Patterns, Scans or other Tours (second-level). Using second-level Tours, it can be expanded to over 300 functions in a single Tour. TOUR SETUP NUMBER : 01 TITLE : T01... -
Page 14: Privacy Zone
3.6 Privacy Zone Hide up to 16 unwanted scenes in a camera. There are four pages of Privacy Zone menu. Each page has 4 Privacy Zones. PRIVACY ZONE SETUP (CTRL KEY) METHOD COLOR BLOCK BLACK BLOCK BLACK ----- BLACK ----- BLACK NEXT PAGE SAVE AND EXIT(ESC TO CANCEL) -
Page 15: Camera Menu
3.7 Camera Menu CAMERA SETUP FOCUS CONTROL WB CONTROL AE CONTROL CAMERA CONTROL SHARPNESS : 03 DIGITAL ZOOM : OFF IMAGE FLIP : OFF PRESET FREEZE : OFF RESOLUTION : 1080P/25 SAVE AND EXIT(ESC TO CANCEL) SHARPNESS The higher the value, the more edges in the picture will be enhanced. (0 ~ 10) DIGITAL ZOOM OFF: Zoom range is limited to the optical. - Page 16 • WB (White Balance) CONTROL WB SETUP MODE : AUTO R GAIN : --- B GAIN : --- SAVE AND EXIT(ESC TO CANCEL) MODE AUTO, MANUAL, INCANDESCENT, FLUORESCENT, OUTDOOR AUTO Computes the white balance value output using color information from the entire screen automatically. INCANDESCENT Auto white balance mode that is compatible with incandescent lamps.
- Page 17 The NIGHT SHOT option removes the IR cutoff filter of the camera and makes the camera sensitive to near infrared. AUTO Camera goes in to B&W mode at low light. GLOBAL Controlled by the keyboard (NOTE: GLOBAL function operates F2E protocol only) The operator can enable NIGHT SHOT for all dome cameras at the same time.
-
Page 18: Communication
3.8 Communication To prevent damage, each camera must have a unique address (ID). The factory default setting is 1. COMMUNICATION MASTER ID : 0001 SLAVE ID : 0001 TYPE : SLAVE PORT : 485 MASTER PROTOCOL : PELCO-D SLAVE PROTOCOL : PELCO-D BAUDRATE : 9600... - Page 19 - SLAVE: By using RS-485 or RS-422 RX serial communication port, it allows you to control the camera by controller or DVR. - MASTER/SLAVE: By using RS-422 TX serial communication port, it allows you to control the external device (Pan & Tilt System) through CoC (Control over Coax) signal from DVR. By using RS-422 RX serial communication port, it allows you to control the external device (Pan &...
-
Page 20: Alarm
3.9 Alarm ALARM SETUP (CTRL KEY) FUN IN HOLD LATCH 001 NO OUT1 03 SAVE AND EXIT(ESC TO CANCEL) NO (Number) Alarm input number FUN (Function) Stored function number to be called by alarm. IN (Input) NO/NC – normally open/closed, OFF – ignore OUT (Output) OUT1 –... -
Page 21: System Setup
3.10 System Setup SYSTEM SETUP HOME FUNCTION SETUP FACTORY DEFAULT RESET OSD DISPLAY ORIGIN CHECK FUNCTION RUN SYSTEM INFORMATION PRESET FOCUS : AUTO EXIT(ESC TO EXIT) • HOME FUNCTION SETUP HOME FUNCTION SETUP FUNCTION : NONE NUMBER : --- WAITING TIME : 120 SEC ENABLE : OFF... - Page 22 • FACTORY DEFAULT Select “FACTORY DEFAULT” to initialize the data. FACTORY DEFAULT ARE YOU SURE ? CANCEL • RESET RESET ARE YOU SURE ? CANCEL This feature is used to re-calibrate the orientation of a selected camera. Origin offset value is not affected by this function.
- Page 23 • ORIGIN CHECK If you find the camera in the wrong zoom position during operation, execute this origin check and the camera will return to the right zoom position after the origin check operation. ORIGIN CHECK ARE YOU SURE ? CANCEL •...
- Page 24 • SYSTEM INFORMATION SYSTEM INFORMATION CAMERA TYPE : xxxx-Vx.xx H/W VERSION : Vx.xx-xxxx ROM VERSION : Vx.xxxxxx PROTOCOL : xxxx BAUDRATE : 9600(NONE) HD B/D VERSION : Vx.xx EXIT(ESC TO EXIT) The system information provides essential information about the camera if service is required. This screen displays the camera type and ROM version.
-
Page 25: Appendix A - Specifications
Appendix A — Specifications Model HD Analog Camera IMAGE Optical Zoom 30X Lens 4.3mm ~ 129.0mm Angle of View 61.8° (H) ~ 2.9° (H) Type 1/2.8" SONY STARVIS CMOS sensor Image Sensor Pixels 1945 (H) x 1097 (V) Color : 0.35 Lux @ 50IRE Min. - Page 26 Figure – Dimension...
-
Page 27: Appendix B - Troubleshooting
Appendix B — Troubleshooting If problems occur, verify the installation of the camera with the instructions in this manual and with other operating equipment. Isolate the problem to the specific piece of equipment in the system and refer to the equipment manual for further information. Problem Possible Solution Verify that power is connected to all pieces of equipment... - Page 28 VIDEOR E. Hartig GmbH Exclusive distribution through special- ised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
