11.98
Desig- Description
nation
CBP Communications board with interface for SINEC-L2-DP,
(Profibus) (small-format board; must be plugged onto
the ADB on the right-hand side or below)
CBC Communications board with interface for CAN protocol
(small-format board; must be plugged onto the ADB on
the right-hand side or below)
Table 9.3 Option boards and bus adapter
Slot in the electronics box
Left Slot 1 (PSR)
Middle Slot 3 (options)
Right Slot 2 (options)
If only one technology board is used, it must always be plugged into slot 2 of the electronics box.
It is only permissible for each optional supplementary board to be mounted once in the electronics box.
If a technology board is used in conjunction with a communications board, the communications board must
be plugged into slot G (small-format boards, CBP and CBC) or slot 3 (large-format boards, CB1 and CB2).
The data of large-format boards always appear under slot E or slot G. This means that, for example, the
software version of a technology board is displayed by means of r060.003.
In order to use small-format boards (CBP and CBC) an ADB (adapter board) is necessary in addition to the
LBA. Due to their small mechanical dimensions, these boards must be plugged onto an ADB so that they
can be slotted into the electronics box.
A maximum of 2 supplementary boards can be used.
Table 9.4 Slots in the electronics box
One or two of the option boards listed in Table 9.3 can be plugged into the electronics box with the help of the
LBA option (local bus adapter).
The slots are marked as shown in the following illustration.
1 3 2
F D
Marking of
slots 1 to 3 and
slots D to G in the
electronics box
G E
Siemens AG 6SE7087-6AC85-0AA0
Common Rectifier Operating instructions
Board
Board
Boards
PSR
CB1 / SCB1 / SCB2 / CBC (with ADB) / CBP (with ADB)
CB1 / CB2 / CBP (with ADB) / CBC (with ADB) / SCB1 /
SCB2 / T100 / T300
NOTE
Options
Order No.
6SE7090-0XX84-0FF0
6SE7090-0XX84-0FG0
9-3
ENGLISH
