 Expansion Interface
 One PCIe x16 slot.
 One PCIe x4 slot.
 Two PCI-Express Mini Card socket which complies with PCI-Express Mini Card
Spec. V1.2.
 Two PCIe x1 slots.
 Battery
 Lithium 3V/220mAH.
 Size
 244 x 291mm.
 Board Thickness
 1.6mm.
 Operation Temperature
 -40°C ~ +85°C (-104°F ~ 185°F).
 Operation Humidity
 10% ~ 95% relative humidity, non-condensing.
All specifications and images are subject to change without notice.
Note
1.3

Utilities Supported

 Audio driver
Introduction
CEB94011 COM Express
TM
Type 6 Development Baseboard
3
