Cylinder - Assemble (H.50.C.26 - F.10.A.20)

435, 445, 445CT

NOTE: If a new gland is being installed, put the part number of the cylinder on the new gland.
1. Lubricate all components with hydraulic oil.
2. Lubricate a new seal with clean hydraulic oil. Insert
the new seal into the gland so the lips are toward
the small end of the gland.
3. Lubricate a new wiper with clean hydraulic oil. Insert
the new wiper into the gland so the lips are toward
the large end of the gland.
4. Lubricate a new backup ring with clean hydraulic
oil. Insert the new backup ring into the groove on
the outside of the gland so the flat side is toward
the large end of the gland.
5. Lubricate a new O-ring with clean hydraulic oil.
Insert the O-ring into the groove and onto the
backup ring on the outside of the gland.
6. Fasten the piston rod end in a vise.
7. Remove any marks or sharp edges on the
chamfered end of the piston rod.
8. Lubricate the bore of the gland with clean hydraulic
oil.
9. Push the gland onto the piston rod. If the gland
will not slide easily onto the piston rod, use a soft
hammer to drive the gland onto the piston rod.
10. To prevent damage to the piston rod, place a support
below and near the end of the piston rod. Use a
shop cloth between the support and the piston rod.
11. Install the piston onto the end of the piston rod.
12. Slide the washer onto the bolt.
13. Clean the threads on the end of the piston rod
and the threads of the bolt using Loctite cleaning
solvent. Allow all the parts to dry. Apply 1/2 in of
Loctite 242 onto the threads of the piston rod 1/4 in
from the open end of the piston rod.
NOTE: Do not apply Loctite 242 to the first 1/4 in of the
piston rod threads.
14. Install the bolt.
15. Tighten the bolt to a torque of 365 - 469 Nm (270 -
346 lb ft). A torque multiplier can be used to tighten
the bolt.
16. Lubricate a new backup ring with clean hydraulic
oil. Slide the backup ring into the center groove on
the outside of the piston.
17. Lubricate a new seal with clean hydraulic oil. Slide
the new seal on top of the backup ring on the
outside of the piston.
18. Lubricate a new wear ring with clean hydraulic oil.
Slide the new wear ring into the end groove on the
opposite end of the piston.
WORKING ARM - SINGLE ARM TOOL ATTACHMENT Tilt
1 04/05/2005
H.50.C / 20
