Case 445CT Repair Manual page 66

TECHNICAL DATA
Control valve
Control valve - General specification (H.50.C.13 - D.40.A.10)
435, 445
Control valve - General specification (H.50.C.13 - D.40.A.10)
445CT
Cylinder
Cylinder - Torque (H.50.C.26 - D.20.A.10)
435, 445, 445CT
Relief valve
Relief valve - General specification (H.50.C.17 - D.40.A.10)
435, 445
Relief valve - General specification (H.50.C.17 - D.40.A.10)
445CT
FUNCTIONAL DATA
Cylinder
Cylinder - Sectional view (H.50.C.26 - C.10.A.30)
435, 445, 445CT
SERVICE
SINGLE ARM TOOL ATTACHMENT Tilt - Cleaning (H.50.C - F.30.A.10)
435, 445, 445CT
SINGLE ARM TOOL ATTACHMENT Tilt - Decontaminating (H.50.C - F.30.A.60)
435, 445, 445CT
Control valve
Control valve - Remove (H.50.C.13 - F.10.A.10)
435, 445, 445CT
Control valve - Install (H.50.C.13 - F.10.A.15)
435, 445, 445CT
Cylinder
Cylinder - Disassemble (H.50.C.26 - F.10.A.25)
435, 445, 445CT
Cylinder - Visual inspection (H.50.C.26 - F.40.A.10)
435, 445, 445CT
Cylinder - Assemble (H.50.C.26 - F.10.A.20)
435, 445, 445CT
Relief valve
Relief valve - Pressure test (H.50.C.17 - F.40.A.30)
435, 445, 445CT
Relief valve - Flow test (H.50.C.17 - F.40.A.45)
435, 445, 445CT
WORKING ARM - H
SINGLE ARM TOOL ATTACHMENT Tilt - 50.C
Contents
39751 1 04/05/2005
H.50.C / 2
3
3
4
5
5
6
7
11
13
14
15
18
20
22
23
