SINGLE ARM Lift - Visual inspection (H.40.B - F.40.A.10)

435, 445, 445CT

1. Inspect the loader frame (1) for cracks, corrosion,
and any other damage, refer to the illustration in
Figure 1. Use new parts as required.
2. Inspect the pins (14) removed from the loader lift
frame (1) for wear, cracks, corrosion, and any other
damage. Use new parts as required.
3. Inspect the loader lift pin bushings (20 and 22) and
spacers (15) for wear, cracks, corrosion, and any
other damage. Use new parts as required.
4. Inspect the loader H-frame arm assembly (1) for
cracks, corrosion, and any other damage, refer
to the illustration in Figure 2. Use new parts as
required.
5. Inspect the pins (8) removed from the loader
H-frame arm assembly (1) for wear, cracks,
corrosion, and any other damage. Use new parts
as required.
6. Inspect the loader H-frame arm assembly bushings
(2) and spacers (3) for wear, cracks, corrosion, and
any other damage. Use new parts as required.
WORKING ARM - SINGLE ARM Lift
1 04/05/2005
H.40.B / 18
