Command Lever - Adjust (H.40.B.05.05 - F.45.A.01); 435, 445, 445Ct - Case 445CT Repair Manual

Command Lever - Adjust (H.40.B.05.05 - F.45.A.01)

435, 445, 445CT

1. With the ROPS down and latched, sit in the
operators seat and lower the seat bar and turn the
key switch to the IGN position. This releases the
loader control spool interlocks.
2. Move each control handle to the full forward/full
outward postion and measure the distance from the
control handle to the front ROPS post. Clearance
between the control handle and front ROPS post
should be 25 - 40 mm ( 0.98 - 1.57 in).
3. Adjust the length of the control rod (1) to 185 - mm
(7.28 - in)
4. Adjust the length of the control rod (2) to 233 - mm
(9.17 - in)
WORKING ARM - SINGLE ARM Lift
1 04/05/2005
