WCA2UP-03 & RSA3UP-03 Instructions
This kit provides parts and instructions to replace the A10 A/D board and add
Option 03 (IQ input function) to your WCA230A and WCA280A Portable
Wireless Communication Analyzers or RSA3303A and RSA3308A Real-Time
Spectrum Analyzers.
This document supports Tektronix modification ECR30645.
WCA230A and WCA280A
RSA3303A and RSA3308A
Required tools and equipment
Screwdriver handle
#1 Phillips tip
#2 Phillips tip
Fig. & index
number Quantity
WCA2UP-03, RSA3UP-03
1-1 1 ea
1-2 4 ea
1-3 4 ea
1-4 8 ea
1-5 16 ea
1-6 1 ea
1-7 1 ea
without Option 03
without Option 03
Description
Accepts Phillps-driver bits
Phillips-driver bit for #1 size screw heads
Phillips-driver bit for #2 size screw heads
Part number Description
671-B158-55 CIRCUIT BD ASSY:A10
131-6607-00 CON,RF,JACK:BNC
174-B980-00 CABLE ASSY,RF:50OHM,COAX
211-0871-00 SCREW,MACHINE:M3X6MM L
211-A151-00 SCREW,MACHINE:M2.5X6MM L
334-1377-50 MARKER, IDENT
075-1268-02 INSTRUCTION MANUAL,
WCA2UP-03 & RSA3UP-03
