Installation Instructions
Connecting SMB Cables
Figure 8: Connecting SMB cables
10
You will need a Phillips #2 screwdriver.
1. Remove the rear panel: See Figure 8 below.
Using a Phillips #2 screwdriver, remove the two screws securing the
rear panel to the main chassis.
Rear panel
Rear support bracket
WCA2UP-03 & RSA3UP-03 Instructions
A10 A/D board
