Removing Old A10 Board
GPIB
W75
A70
DC power
A40
Memory
A30
Trigger
A20
DDC
A10
A/D
RF5
RF4
RF3
RF2
A62
Front
connection
CPU
Figure 3: Top view of the card cage
WCA2UP-03 & RSA3UP-03 Instructions
You will need a Phillips #2 screwdriver.
1. Locate the A10 A/D board in Figure 3 (top view of the card cage).
TRIG
To fan
W47
W46
W31
WCA280A or RSA3308A only
FDD
Rear
TRIG
Q- -
Q+
I- -
IN
OUT
IN
IN
IN
W30
HDD
Front
Installation Instructions
I+
REF
REF
IN
IN
OUT
W41
W40
W25
To remove the A10 board,
unplug the SMB cables from the
connectors indicated by ovals
(Refer to step 3 on page 6).
Fan
5
