Enabling the IQ Input Function
WCA2UP-03 & RSA3UP-03 Instructions
Edit the Option.cal file on the analyzer to enable the IQ input function using the
following procedure.
1. Turn on the analyzer.
2. Connect a USB mouse and a USB keyboard to the USB ports on the
analyzer side panel. You can connect them to either or both ports.
You can also connect the mouse to the USB port on the keyboard.
USB ports
Figure 11: USB ports (side panel)
Installation Instructions
Front
13
