Page 1 Reference Manual ® 2130 RBM Consultant Pro Laser Alignment Analyzer and Fixtures Part # 97191 Rev. 1...
Page 2 Macromedia FreeHand . Printed copies are produced ® ™ not represent a commitment on the part of Emerson using the Xerox DocuTech publishing system. ™ ™ Process Management. The information in this manual is not all-inclusive and cannot cover all unique situations.
Page 3 All other brand or product names are trademarks or reg- up to any applicable maximum number of licensed istered trademarks of their respective companies. users. You may not relicense the Software or use the Software for third party training, commercial time shar- Patents ing, rental, or service bureau use.
Page 4 INABILITY TO USE THIS PROGRAM. After the one year service warranty expires, each return of a Emerson Process Management hardware product is THE LICENSEE'S SOLE AND EXCLUSIVE REMEDY IN subject to a minimum service fee. If the cost of repair...
Page 5 Obsolete Hardware Returning Items Although Emerson Process Management will honor all 1. Call Product Support (see page 2) to obtain a return contractual agreements and will make every effort to authorization number. Please write it clearly and ensure that its software packages are “backward com- prominently on the outside of the shipping patible,”...
Page 7: Table Of Contents
Contents How To Use This Manual · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-1 Emphasis Paragraphs ·...
Page 8 Turn the Laser Beams On· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2-40 Center the Laser Beams · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 2-41 Rough Alignment of the Laser Beams ·...
Page 9 Job Manager Function Keys · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-35 Edit Job Setup · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-38 Edit Job Setup Function Keys ·...
Page 10 Data Detail (Tolerance Plots) · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-162 Data Detail (Tolerance Plot) Function Keys · · · · · · · · · · · · · · · · · 3-166 Display Sine Fit ·...
Page 11 Offset Move · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-41 Offset Move Function Keys ·...
Page 12 Batteries/Analyzer Chargers· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·D-2 Alignment Fixtures · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·D-2 Customer Support ·...
Page 13: How To Use This Manual
Chapter Read This First How To Use This Manual This manual is arranged in the following manner: • Chapter 1 — read this chapter before attempting to use the Model 2130 Laser Alignment program or before proceeding to subsequent chapters. •...
Page 14 Note In this manual, “8215” and “8225” (sometimes quoted as “8215/ 8225”) refer to both the RF versions (Models 821500 and 822500) and the direct-connect only versions (Models 821501 and 822501 ) laser systems except where information specific to one type of laser system is discussed.
Page 15 Introduction The UltraSpec Pro 8215/8225 Laser Alignment Fixtures are the latest in a com- plete line of alignment equipment provided by Emerson Process Management. The 8215/8225 system is used in conjunction with the Model 2130 Laser Align pro- gram. Although the Model 2130 analyzer can be purchased separately, it must be used to process the data from the fixtures.
Page 16 Some advantages of the UltraSpec Pro 8215/8225 Laser Alignment Fixtures are: • Easy setup • No fixture sag • Visible laser to assist with rough alignments • Large diameter mounting range • Large span range between sensor heads • Large vertical expansion to clear larger couplings •...
Page 17: Emphasis Paragraphs
Emphasis Paragraphs Two different types of paragraphs are used throughout this manual to call attention to the adjacent text: Note The note paragraph indicates special comments or instructions. Caution! The caution paragraph alerts you to actions that may have a major impact, such as lost data or damage to the analyzer or its accessories.
Page 18: Ultramgr Software And Prerequisites
UltraMgr Software and Prerequisites Note Your AMS™ Suite: Machinery Health™ Manager software and Model 2130 RBMC must have compatible software. ONSULTANT Requirements Model 2130 RBMC firmware version v.6.3.8.0 or later. ONSULTANT The following, 4.90 or later, AMS™ Suite: Machinery Health™ Manager files - dated 08/08/2005 or later: •...
Page 19: Standard Equipment
When checking the kit to ensure that everything ordered was shipped, compare the contents of the package to your shipping invoice. For additional assistance, refer to the following fixtures case layouts. If a discrepancy is found, call Emerson Customer Support at (865) 671-4274.
Page 20: Fixtures Case Layout (Top Section)
Fixtures Case Layout (top section)
Page 21: Chapter 2 • Setting Up And Using Laser Alignment Fixtures
Chapter Setting Up and Using Laser Alignment Fixtures Special Instructions About the 8215/8225 Laser Fixtures Warning! Prior to mounting the laser alignment fixtures on machine shafts, all switches operating the machines should be “locked out” (follow lockout procedures for your facility). On completion of the align- ment, inspect the work area to ensure that all equipment is clear of rotating shafts and couplings, prior to removal of the lockout protec- tion.
Page 22 Laser heads, front view Laser heads, rear view Setting Up and Using Laser Alignment Fixtures...
Page 23 Note Only the Models 821501 and 822501 direct-connect only laser sys- tems have CE approval. Laser radiation caution...
Page 24: Models 821500 And 822500 Rf Laser Systems Only
Caution! This device has been designed to operate solely with the antenna type provided, Emerson part number 88200. An antenna having a higher gain is strictly pro- hibited per regulations of Industry Canada. Setting Up and Using Laser Alignment Fixtures...
Page 25: General Description
General Description Sensor Head Description This section describes both the old and current versions of the 8215/8225 laser heads. The older version of heads can be identified by their gray front panels and black grid lines. The current version of heads have different color front panels. Head A has a gray front panel with white grid lines and blue on/off buttons, while head B has a blue front panel with white grid lines and gray on/off buttons.
Page 26 The sensor head with the laser source on top is the Master head (known as head “A”). The other head is the Slave (known as head “B”). The model number is listed on the back of each head. They can be identified by the letter A or B on the front. There are no differences between the older and current versions of the 8215/8225 laser heads with the exception of the front panels and batteries.
Page 27 The Activity LED on the front panel can be red, yellow, or green. An explanation of their meaning is shown in the following table. Table 1: LED Status Meaning Required Action Green Yellow Normal Operation - When the No Action Required Laser Head systems are all functioning properly and the laser beam from the companion...
Page 28 Table 1: LED Status Meaning Required Action Green Yellow Low battery 1st warning (sensor Recharge sensor heads. head) - The Laser Head has the ability to monitor its own battery power. The battery power is checked periodically to determine if it is below the X (flashing) minimum acceptable power.
Page 29 LED Functionality Difference Due to Dual Pass mode The functionality of the LED differs slightly from the states described in the above table when the Dual Pass mode of operation is selected. The difference lies in the LED state when the companion Laser Heads laser beam is on the PSD. In Dual Pass mode, when the laser beam is on or off of the PSD the LED will be a solid yellow, even when the beam is in the linear portion of the PSD.
Page 30: General Maintenance
• Store sensor heads in protective hard-shell carrying case when not in use. Calibration The Model 8215/8225 calibration should be checked every two years. Return the sensor heads to Emerson for a calibration check. All calibrations are NIST trace- able. Caution! Do not remove the CSI Quality label on the back of the sensor head.
Page 31: Battery Charging
Battery Charging Batteries must be charged with the Model 8211charger. The Model 8211 charger is a “smart, drop-in” charger that can provide a fast- or trickle-charge for the laser heads and analyzer. This section describes both the old and current version of the 8211 charger. The older version of the 8211 charger can be identified by its solid gray front panel.
Page 32 The current version of the 8211 charger will charge both the former and current versions of the 8215/8225 laser heads but at a slower charge rate than the older ver- sion of the 8211 charger. The former version of the 8211 charger charges the former version of the 8215/8225 laser heads, but it will only trickle charge the cur- rent version of the 8215/8225 laser heads.
Page 33 Note The discharge cycle is intended for older versions of the laser heads, powered by Nickel Cadmium (NiCad) batteries. This function is not required for the current version of the laser heads, powered by Nickel Metal Hydride (NiMH) batteries. However, use of this function on laser heads with NiMH batteries will not result in any damage to the heads or charger.
Page 34 After the Fast charging cycle has completed, the charger’s beeper sounds and the charger automatically begins trickle charging. When this condition begins, the Trickle indicator light turns on indicating that the battery is almost completely charged, or is completely charged. For the laser head batteries, the two conditions occur within a few minutes of each other.
Page 35 Note After a charging cycle begins, if that charging cycle is interrupted (e.g. disconnecting the power to the charger or removing the sensor head from the charger) the charging process described above initiates from the beginning. Therefore, if the charger cycle is interrupted while the Fast charge mode is in progress, then the charger automat- ically begins trickle charging after Pending(see below).
Page 36: Battery Usage - Laser Heads
The battery is designed to have a long life and is not intended to be replaced by the user. Replacement should be per- formed only at Emerson. Emerson recommends that the batteries be replaced after 500 charges.
Page 37: Precautions
Model 8215/8225 laser heads. The use of any other charger will most likely damage the equipment. • Do not use Emerson battery chargers with anything other than the product for which they are designed. Do not use the 8211 charger to charge any- thing else! •...
Page 38: Introduction To Laser Alignment Fixtures Setup
Introduction to Laser Alignment Fixtures Setup This section takes you through a step-by-step setup of the 8215/8225 Laser Align- ment Fixtures. Before before beginning the actual machine alignment, be sure all pre-alignment checks have been completed. Warning! Prior to mounting the laser alignment fixtures on machine shafts, all switches operating the machines should be locked out.
Page 39: Attaching The Fixtures
Attaching the Fixtures This section shows how to attach and secure the mounting base, chains, align the two mounting bases by leveling, install the sensor heads, turn on the sensor heads, and center the lasers on their targets. Attaching the B821007 Carbon Steel Mounting Base The B821007 3/4 inch (19mm) wide carbon steel mounting bracket is suitable for the majority of alignment jobs where the laser fixtures can be rigidly mounted to a shaft that can be rotated freely.
Page 40: Attaching Chain To The Chain Pickup
Attaching Chain to the Chain Pickup This photograph illustrates how the chain attaches and actually clamps the shaft. The base is placed on the shaft (or coupling) and a link of the chain is slipped into the chain pickup to secure the base to the shaft. After slipping a chain link into the chain pickup, tighten the bolt at the end of the chain.
Page 41: Allowing Maximum Tightening Range
Allowing Maximum Tightening Range To allow for maximum tightening range, ensure that the chain nut is flush with the end of the chain bolt (as shown by arrow). Notice that the chain bolts are on oppo- site sides. As shown in later sections, each mounting base can be installed on either end and the chain bolts placed on either side of the shaft.
Page 42: Positioning A Mounting Base
Positioning a Mounting Base Tighten one of the mounting bases and rotate it (along with the shaft) until it is somewhat level at the top of the rotation. To tighten the mounting base, use a 9/16 inch wrench or your hand, depending on which chain tightener is being used. Caution! Do not overtighten the chain —...
Page 43: Positioning The Other Mounting Base
Positioning the Other Mounting Base With the previous mounting base still in its level position, if necessary, loosen and rotate the other mounting base until it is somewhat level with it. Tighten this base and recheck the other base to ensure that both are now level in relation to one another.
Page 44: Attaching Excess Chain
Attaching Excess Chain One of the problems with using chains as a mounting bracket is that the excess chain flops and can cause errors. CSI’s Laser Alignment Fixtures provide solutions for this problem. Two slots are provided (one on either side) to take up the slack. As shown in the following photographs, you can use either or both of the slots as needed.
Page 45 Using the L-shaped Slot Caution! Do not attach excess chain prior to tightening the mounting base chain bolts. Doing so may cause damage to the L and T-shaped slots. Attaching the Fixtures 2-25...
Page 46: Using The Chain Clip
You will almost always have a little extra chain left over. In that case, use the chain clip (part number D22745) to attach it to the previous chain loop. Emerson recom- mends that you use this clip to help prevent the chain from sliding out of the L-slot as the shafts are rotated.
Page 47: Installing A Post
Installing a Post Screw a mounting post (part number D23465) into each of the outer holes in the mounting base. Tighten each post with the supplied tightener (Phillips screw- driver) or with a 1/8 inch Allen wrench (not supplied with kit). Attaching the Fixtures 2-27...
Page 48: Mounting A Sensor Head
Mounting a Sensor Head Note The gray sensor head with the laser source on top is designated head “A”. The “B” designation is attached to the blue sensor head with the laser source on the bottom. In addition to their color difference, head A and B are identified with letters on the front panel.
Page 49 Note Longer mounting posts are not available. However, if you wish to make your own, refer to the mechanical drawing of a mounting post in the section entitled “Mounting Post (part number D23465) For Alignment Brackets” in Appendix B. Attaching the Fixtures 2-29...
Page 50: Models 821500 And 822500 Rf Laser Systems Only
Models 821500 and 822500 RF Laser Systems Only Depending on the clearance around which the laser head will be rotated, the posi- tion of the RF antenna may have to be adjusted. When the antenna is in its most upright position it extends up above the top of the laser head. Holding the antenna housing (not the antenna itself), rotate or twist the antenna down (or up depending on its starting position) to its desired position.
Page 51: Mounting The Other Sensor Head
Mounting the Other Sensor Head Install the opposite sensor head in the same manner (Head A or Head B, depending on which sensor head was mounted on the other side). Models 821500 and 822500 RF Laser Systems Only 2-31...
Page 52: Communication Between The Fixtures And Analyzer
Caution! Changes or modifications not expressly approved by Emerson could void the user's authority to operate the equipment. There may be times when an RF communication between each sensor head and the analyzer is not convenient.
Page 53 A message will be displayed on the analyzer until the communication link is established. When communication using RF becomes difficult, Emerson recommends that you use the Direct Connect link as described in “Direct Connect (All Models)” on page 2-36.
Page 54: Connecting The 8000Rf Interface
Connecting the 8000RF Interface Attaching 8000RF to 25-pin Connector Install the 8000RF Interface onto the serial port of the analyzer by completing the following steps: 1. . . Ensure that the Model 2130 analyzer is turned off. 2. . . Connect the 25-pin connector of the 8000RF Interface to the RS-232 port on the Model 2130 analyzer.
Page 55 Caution! Do not rotate or twist the antenna on the 8000RF Interface. Attempting to do so will damage the unit. The Attached 8000RF Interface. Models 821500 and 822500 RF Laser Systems Only 2-35...
Page 56 Direct Connect (All Models) Direct Connect is designed for those conditions where it is difficult to communi- cate between the analyzer and the sensor heads using RF. Conditions such as building construction materials and contents, other radio systems operating in the vicinity at or near the same operation frequency, and noise generated by nearby equipment all may make RF communication unsatisfactory.
Page 57 To use Direct Connect, complete these steps: 1. . . Make sure the analyzer is turned off. 2. . . Attach the 25-pin connector of the direct connect cable to the RS232 port on top of the analyzer. 3. . . Connect the Lemo connectors of the direct connect cable to the mating straight Lemo connector on the extension cables, if applicable.
Page 58 Caution! When using any cable connector inside the sensor head connector, do not turn or twist the connector. This will shear the cable pins off (inside the connector) totally disabling the sensor head and cable. Pull the cable connector completely out of the sensor head connector before turning the cable.
Page 59 The extension cables are eight feet (2.4 meters) long. With two extension cables and the connection pigtail, the total length is 13 feet (4 meters). When standing between the sensor heads, a 22 foot (6.7 meters) span can be aligned, depending on the diameter of the shaft.
Page 60: Turn The Laser Beams On
Use of controls, or adjustments, or performance of procedures other than those speci- fied by Emerson may result in hazardous laser radiation exposure. To do so could result in serious personal injury. Always ensure that the sensor heads are mounted securely before turning on the laser beam.
Page 61: Center The Laser Beams
Center the Laser Beams Vertical Adjustment Horizontal Adjustment Center both Lasers on their associated target by adjusting the thumb wheels on the front of each sensor head. Models 821500 and 822500 RF Laser Systems Only 2-41...
Page 62: Rough Alignment Of The Laser Beams
Rough Alignment of the Laser Beams Rough alignment may be required to keep the laser beam on the target as the fix- tures are rotated. Either of these methods can be used: • Visible Beam rough alignment — utilizes the visible laser beams without the use of the analyzer •...
Page 63 The gridlines on the front panel should assist you in determining the approximate movement(s) needed to rough the machines in. Gridline spacing is 0.3 inches (7.5 mm). The following table shows recommended moves based upon the gross move- ment of the laser beam on the sensor head. Gross movements are discussed in ver- tical terms for simplicity.
Page 64 Gross Movement Recommended Machine Move at Gearbox at Motor Small Large, Angular & Offset – add shims under the inboard down Gearbox feet or remove shims from the outboard Gearbox feet. Large, Small Angular & Offset – add shims under the inboard Motor down feet or remove shims from the outboard Motor feet.
Page 65 This procedure also works when using the Dual Pass mode. Note Roughing in the machine so that the laser beam is kept on the target (PSD) as the laser fixtures are rotated can be quicker with a larger PSD (e.g. with the 20x20mm PSD on the 8225 laser fixtures). Models 821500 and 822500 RF Laser Systems Only 2-45...
Page 66: Introduction To Special Applications
Introduction to Special Applications This section covers using additional mounting blocks, mounting on large diame- ters ( shafts > 8 inches (203 mm), and using alternative mounting brackets. Nor- mally, additional blocks are used to achieve greater coupling clearance. In some cases, you may find that one (or both) of the mounting blocks must be installed on the coupling itself.
Page 67: Using Additional Mounting Blocks
Mounting a One-inch (25 mm) Block This photograph shows a 1-inch (25 mm) block being mounted onto the mounting block itself. Note Emerson recommends that you tighten all vertical mounting block cap screws to 50 in-lbs (without lubrication). Using Additional Mounting Blocks 2-47...
Page 68: Adding A 2-Inch (51 Mm) Block
Adding a 2-inch (51 mm) Block This is a picture of a 2-inch (51 mm) block being attached on top of the 1-inch (25 mm) block (the blocks can be stacked in either order). 2-48 Setting Up and Using Laser Alignment Fixtures...
Page 69 This shows the complete 3-inch (76 mm) extension setup. The following table lists which blocks are to be used for the various vertical extension ranges. For Vertical Extension Use These Block(s) Length (inches) (inches) 1, 2 Using Additional Mounting Blocks 2-49...
Page 70: Mounting One Bracket On A Coupling
Mounting One Bracket on a Coupling If at all possible, Emerson recommends that you mount the brackets on the shafts. However, this is not always possible. Occasionally, you may have to mount the bracket on a coupling. This view shows the B821007 carbon steel mounting brackets being mounted to the shaft on one side and the coupling on the other.
Page 71: Mounting On Shafts (Or Couplings) > 8-Inch
Although the mounting base itself can be used on shaft diameters up to 26 inches (660 mm), additional section(s) of chain must be used for applications greater than 8 inches (203 mm) in diameter. Emerson sells extension lengths in two-feet chain increments for the B821007 carbon steel mounting bracket (part number D22773) and the A800052 soft-mount (non-rotational) mounting bracket (part number A832001).
Page 72: Using Alternative Mounting Brackets
Using Alternative Mounting Brackets Attaching the A800052 Soft-Mount (Non-Rotational) Mounting Base The A800052 soft mount bracket was developed for machines with shafts or rotors that are too large and heavy or difficult to turn like cement kilns, rock crushers, gearboxes and hammer mills. This bracket is typically used for uncoupled align- ments where either the Manual Sweep or Dual Pass methods are being used.
Page 73 Before using, inspect the soft mount base to ensure that all eight ball bearings are tight and free of play. Screw the mounting posts into each hole in the mounting base and tighten with the supplied tightener (Phillips screwdriver) or with a 1/8 inch Allen wrench (not supplied with kit).
Page 74 To ensure measurement accuracy, the contact surfaces of the shaft (or coupling) must be free of dirt, grease, oil, etc. If cleaning is needed, Emerson recommends that you use a solvent-base cleaner. Shaft keys should be avoided to reduce errors in accuracy.
Page 75 Attaching the A8AA54 Narrow Mounting Base The A8AA54, 1/2 inch (13mm) wide, narrow bracket was developed for small machines with shaft diameters of 4 - 1/2 inches (114 mm) and below, where the shaft can be rotated freely. Top and bottom v-shaped bars clamp snugly around the shaft.
Page 76 Screw the mounting posts into each hole in the mounting base and tighten with the supplied tightener (Phillips screwdriver) or with a 1/8 inch Allen wrench (not supplied with kit). Mount the laser fixtures to the posts as described in “Attaching the B821007 Carbon Steel Mounting Base”...
Page 77 Attaching the A8AA55 Quick Mount Narrow Mounting Base The A8AA55, 1/2 inch (13mm) wide quick mount narrow bracket is a chain type bracket for optimal stability in tight spaces on a wide range of shaft sizes, where the shaft can be rotated freely. The chain assembly should be slipped into the mounting base.
Page 78 Screw the mounting posts into each hole in the mounting base and tighten with the supplied tightener (Phillips screwdriver) or with a 1/8 inch Allen wrench (not supplied with kit). Mount the laser fixtures to the posts as described in “Attaching the B821007 Carbon Steel Mounting Base”...
Page 79 Attaching the A800056 Magnetic Mounting Base The A800056 9/16 inches (14 mm) thick magnetic bracket was developed to mount on the side of couplings made of ferromagnetic material. Recommended minimum coupling diameter is 3-4 inches (75-100 mm), where the shaft can be rotated freely.
Page 80 Screw the mounting posts into each hole in the mounting base and tighten with the supplied tightener (Phillips screwdriver) or with a 1/8 inch Allen wrench (not supplied with kit). Mount the laser fixtures to the posts as described in “Attaching the B821007 Carbon Steel Mounting Base”...
Page 81: Chapter 3 • Horizontal Alignment
Chapter Horizontal Alignment The horizontal alignment feature of the Advanced and Basic Laser Align applica- tions is used to collect and display alignment data for machines in which the machine moves are accomplished at the machine feet. Help Depending on where you are within the program, an alignment helper may be available at the bottom of the screen to provide you with a brief explanation of the highlighted step or screen.
Page 82: Advanced And Basic Laser Align Applications
Advanced and Basic Laser Align Applications The laser alignment program is available as an advanced laser align program (which includes the ability to perform Basic jobs), and as a basic laser align pro- gram (which can only perform basic alignment jobs). Advanced Laser Align If the Advanced Laser Align application is loaded in a 2130 analyzer, the program can be launched from the 2130 analyzer’s Home screen by pressing the Adv Laser...
Page 83: Main Screen
Main Screen The main Laser Align Application screen (sometimes referred to as the Main Menu) allows you to monitor progress throughout the alignment job. When a hor- izontal alignment job is active, the Main screen displays as illustrated below. Laser Align Application Main screen at job start The application defaults to a predefined setup when a new job is created.
Page 84 The steps required to perform an alignment are displayed in the center portion of the main screen. The 2130 Laser Align program leads you through each step of a routine alignment procedure starting with the Enter Dimensions selection at the Main screen.
Page 85: Three Step Alignment
Three Step Alignment To simulate the basic steps required to complete a horizontal alignment job, the 2130 Laser Align main screen is set up to allow an alignment job to be performed using the following three steps: enter dimensions, • enter machine dimensions •...
Page 86: Main Screen Function Keys
Main Screen Function Keys Enter Dimensions Use the Enter Dimensions key to advance to the Edit Dimensions screen where the dimensions for the machine being aligned can be entered. This is the first step of the three-key operation used in performing an alignment job. If thermal growth is enabled, thermal growth information can also be entered from under this step.
Page 87: Alt Main Screen
Alt Main Screen The Alt Main screen (also known as the Main Menu Alt2 screen) allows you to setup alignment job parameters and job flow. The Alt Main screen is reached by pressing the Alt key on the Main screen. Laser Align Application Alt Main (Advanced Mode) Alt Main Screen...
Page 88: Alt Main Screen Function Keys
Alt Main Screen Function Keys Notes Use the Notes key to advance to the Notes screens where notes can be assigned to the current job. In addition to the predefined notes, user defined notes can also be created and assigned to the current job from under this option. Refer to the Notes section on page 3-180 for more information.
Page 89 Laser Config Use the Laser Config key to advance to the Laser Configuration screen where the laser head and analyzer addresses can be reviewed and set, and the Laser Head A and B locations can be set. Refer to the Laser Configuration section on page 3-23 for more information.
Page 90 3-10 Horizontal Alignment...
Page 91: Job Reset
Job Reset The Job Reset key allows the operator to “Clear Job Data,” “Load Default Values,” or “Load Default Tolerances.” Clear Job Data Use the Clear Job Data function to clear all stored data and notes from the active job. Before any data is cleared, a warning message will be displayed asking the oper- ator if this is truly the operation to be performed.
Page 92: Basic Mode
Basic Mode When running the Basic Laser Align application in the 2130 analyzer, or when the Job Mode in the Advanced Laser Align application is set to Basic, the functionality described throughout this manual will be limited to the subset described in this sec- tion.
Page 93: Basic Mode Function Keys
Basic Mode Function Keys Notes This option functions exactly the same as is does for Advanced Horizontal jobs. Refer to the Notes section on page 3-180 for more information. Job Mode When a 2130 analyzer is running the Advanced Laser Align application, the Job Mode soft key functions as described in the section “Job Mode ”...
Page 94 Tolerance Type Use the Tolerance Type key to toggle the alignment tolerance type between the only two options available in Basic mode: Standard (default) and Jackshaft. Refer to the Tolerance Type section on page 3-22 and the Tolerances section on page 3-193 for more information.
Page 95 • If accessing an external memory card, only Basic Horizontal jobs can be viewed and edited; therefore, if the card were to contain any Advanced Hor- izontal jobs they would not be available. Job Flow Since thermal growth information is the only Job Flow parameter that can be spec- ified, the Job Flow option is not available.
Page 96: Job Reset
Job Reset The Job Reset key allows the operator to “Clear Job Data,” “Load Default Values,” or “Load Default Tolerances.” Clear Job Data Use the Clear Job Data function to clear all stored data and notes from the active job. Before any data is cleared, a warning message will be displayed asking the oper- ator if this is truly the operation to be performed.
Page 97 Machine Configuration From the Machine Configuration screen you can select the machine components for the current job. The Machine Configuration screen is reached by pressing the Machine Config key on the Alt Main screen. Machine Configuration Screen When this option is first selected, the machine type defined for the left machine will be highlighted by a red box around the machine type by default.
Page 98: Machine Configuration Function Keys
When “Other” is selected as the machine type you can enter a machine name (up to 7 characters in length). The following machine types can be defined for the job: Machine Types Machine Configuration Function Keys Select Left Machine Use the Select Left Machine key to set the left machine component to the machine type highlighted by the red box.
Page 99 Laser Align Method From the Laser Align (Alignment) Method subwindow you can select the align- ment method for the current job. The Laser Align (Alignment) Method sub- window is reached by pressing the Laser Align Method key on the Alt Main screen. Alignment Method Subwindow Basic Mode Function Keys 3-19...
Page 100: Laser Align (Alignment) Method Function Keys
Laser Align (Alignment) Method Function Keys Method Use the Method key to select the alignment method. The choices are: Auto Sweep (default), Dual Pass, Manual Sweep, Auto 4 Point, and Manual 4 Point. Refer to the Acquiring Alignment Data section on page 3-82 for more information. Mode Use the Mode key, if the alignment method is Auto Sweep or Manual, to define the mode of operation for the alignment method defined.
Page 101 Note If a lower percentage (smaller valid window) is selected, a slower rota- tional speed may be required especially with a smaller PSD (e.g. with the 10x10mm PSD on the 8215). For example, a 10% Target Window would define a 2mm wide window on an 8225 and a 1mm wide window on an 8215 centered around the PSD's vertical center- line in which data will be acquired as the laser beam passes across the window.
Page 102: Tolerance Type
Tolerance Type From the Tolerance Type subwindow you can select the tolerance type for the cur- rent job. The Tolerance Type subwindow is reached by pressing the Tolerance Type key on the Alt Main screen. Tolerance Type Subwindow Tolerance Type Function Keys Tolerance Type Use the Tolerance Type key to define the tolerance type for the job.
Page 103 Jackshaft tolerances are used when the laser heads are mounted 20 or more inches apart. In these cases, Standard Tolerances are the less practical to use. This method measures the two angles between the shafts. Optimum alignment occurs when the two angles are zero.
Page 104: Laser Configuration Function Keys
The location of each head is based on how the machines are viewed. It does not matter which head is put on which machine; however, the analyzer must know each head’s location. Caution! Selecting the proper configuration for the laser heads is extremely important! If the setting is wrong, all of the machine move calculations will be incorrect.
Page 105 Resend Data Use the Resend Data key to resend data from the laser heads. This key is active when the alignment method is set to Auto Sweep or Dual Pass on the Alt Laser Con- figuration screen. This option is useful if for some reason the data transfer from the heads to the analyzer was aborted before completion.
Page 106: Laser Address Selection
Laser Address Selection From the Current Addresses screen you can review, read, and set the laser head (Models 821500 and 822500 only) and the analyzer addresses. The Current Addresses screen is reached by pressing the Laser Address Selection key on the Laser Configuration screen.
Page 107 Laser addressing is necessary when using either direct connect or RF communica- tions. If one laser system (a system consists of a pair of laser heads and an analyzer) using RF communication is operating in close proximity to another laser system using RF communication, this option prevents the two from interfering with each other.
Page 108 Read Head A Address key Use the Read Head A Address key to read and set the address in Head A. To read and set the laser head addresses the direct connect cable must be attached to each of the laser heads and the analyzer first before this option is selected. After the direct connect cable is attached, turn Head A on and leave Head B turned off.
Page 109 Note If you enter a number outside the range of 1 to 10 or try to enter two addresses which are the same, you will get a warning telling you of the error. Should this happen, press the Enter key to continue and repeat the procedure.
Page 110: Check Lasers
Check Lasers From the Laser Head Status screen you can check the operational status of the heads and change the sample rate. The Laser Head Status screen is reached by pressing the Check Lasers key on the Laser Configuration screen. Laser Head Status Screen (show bar graphs) 3-30 Horizontal Alignment...
Page 111 Laser Head Status Screen (show numbers) Note Both laser heads need to be turned on for this option to function properly. Laser Address Selection 3-31...
Page 112: Laser Head Status Function Keys
Laser Head Status Function Keys Show Numbers Use the Show Numbers key to replace the Battery, Laser, and Sensor bar graphs with numbers as illustrated above in “Laser Head Status Screen (show numbers)” on page 3-31. Show Bar Graphs Use the Show Bar Graphs key to replace the Battery, Laser, and Sensor numbers with bar graphs as illustrated above in “Laser Head Status Screen (show bar graphs)”...
Page 113 Show Laser Angle Use the Show Laser Angle key similarly as you would the Hide Laser Angle key except this key is used to show the laser angle if it is hidden. Laser Address Selection 3-33...
Page 114: Job Manager
Job Manager From the Job Manager screen you can perform job related tasks (e.g. creating, editing, deleting, transferring, copying, and activating jobs). In addition to jobs, alignment tolerances can also be transferred from the PC to the analyzer. The Job Manager screen is reached by pressing the Job Manager key on the Alt Main screen.
Page 115: Job Manager Function Keys
Job Manager Function Keys Create New Job Use the Create New Job key to create a new default horizontal job and advance you to the Edit Job screen. Refer to the Edit Job Setup section on page 3-38 for more information.
Page 116 Caution! Use extreme caution with the delete jobs option when the analyzer contains important alignment data. Once you answer yes to the warning message all data on the selected jobs will be lost. Note Alignment jobs can also be deleted from under the File Utility option. Alignment jobs have a .LJB file extension.
Page 117 Job Up and Down Arrows Use the Job Up and Down Arrow keys to scroll through the list of jobs one at a time. The highlighted job will toggle from top to bottom and vise versa with these keys. The keys are only active when more than one job is listed. Page Up and Down Arrows Use the Page Up and Down Arrow keys to scroll through the list of jobs one page at a time.
Page 118: Edit Job Setup
Edit Job Setup Press the Edit This Job soft key to advance to the Edit Job Setup screen where the job parameters used for job identification and storage may be edited. The Edit Job Setup screen is reached by pressing the Edit This Job key on the Job Manager screen.
Page 119: Edit Job Setup Function Keys
Edit Job Setup Function Keys Edit Job ID Use the Edit Job ID key to edit the Job ID. This option provides for the creation of a unique ID useful for identifying the job. For example, it could be tied back to the work order number, etc.
Page 120 Edit Equip ID Use the Edit Equip ID key to edit the Equipment ID. This option is useful for iden- tifying the equipment being aligned. The Equipment ID is displayed in the upper section of the main screen (for the active job). The Equipment ID can be a max- imum of 10 characters.
Page 121 • any of the information setup under Edit Job Setup does not clear since this information is common to each of the modes, • any data stored on the job clears, • the default setup conditions for the mode specified (except for the informa- tion setup under Edit Job Setup) loads into the job.
Page 122: Job Flow
Job Flow From the Job Flow subwindow, select which optional parameters are to be included or excluded as part of the job flow for the current job. These optional parameters include: entering thermal growth inputs, performing a foot pre-check, performing a vertical live move, enabling an audible tone and flashing LED during a live move, and review alignment results and data averaging.
Page 123: Job Flow Function Keys
Job Flow Function Keys Thermal Growth Use the Thermal Growth key to define the type of Thermal Growth for the current job. The choices are: No Thermal Growth (default), At Feet, At Profile, Gap/ Offset, Face/Rim, and Reverse Dial. Refer to the Entering Thermal Growth Infor- mation section on page 3-56 for more information.
Page 124 If the Status Beeper option located under the 2130 analyzer’s Home/General Setup screen is enabled and the Enable Alert option is enabled, the audible tone will be generated as described above, but if the Status Beeper option located under the 2130 analyzer’s Home/General Setup screen is disabled and the Enable Alert option is enabled, the audible tone will not be generated as described above.
Page 125: Enter Dimensions
Enter Dimensions The Enter Dimensions screen allows you to enter the dimensions for the machine being aligned. If thermal growth is enabled, thermal growth information can also be entered from under this step. The Enter Dimensions screen is reached by pressing the Enter Dimensions key on the Main screen.
Page 126 Enter Dimensions Screen (right machine fixed) Note When a machine has been configured as a “Fixed” machine (as shown in the second figure above) the program will not require any dimensions to be entered for that machine. Although dimensions are not required for this machine, without them, no machine moves for that machine can be given.
Page 127 Dimensions can be expressed in either inches or millimeters (mm), depending on the analyzer units. The range of values that can be entered for the A, C, and E dimensions are 0.01 to 3600 inches and 0.254 to 91440 mm. The range of values that can be entered for the B, D, and F dimensions are -3600 to 3600 inches and --91440 to 91440 mm.
Page 128 If only the RPM and A, B, C, and F dimensions have been entered, then no alter- nate solutions will be available for the right machine. If only the RPM and D, E, C, and F dimensions have been entered, then no alternate solutions will be available for the left machine.
Page 129 Refer to the following table for a description of each dimension. Measure Dimension Measurement Description to the Nearest Center of outboard foot to center of inboard foot of the 1/8 inch machine on the left. (3 mm) Center of inboard foot on the left machine to the laser head 1/8 inch face on the left machine.
Page 130 Left and Right Arrow keys Use the Left and Right Arrow keys to select the field to modify (highlighted with the red box around it). Enter key Use the Enter key to advance to either the Sweep Laser Heads step or the thermal growth screen(s).
Page 131: Entering Fractions
Entering Fractions With the analyzer units set to English, the decimal “.” and forward slash “/” charac- ters can be used to enter fractional values on numeric entry screens in which these two characters are available. The decimal “.” character is used to separate the integer part from the fractional part of the numerical value.
Page 132 For example, if a fractional value of 5.3/4 is entered (shown in the screen above) it will be converted to 5.75 (shown in the screen below) when either another dimen- sion is selected or the Enter key is pressed to accept the screen and advance to the next step in the procedure.
Page 133: Quick Spec
Quick Spec Quick Spec mode allows you to make a quick check of the alignment condition of a machine with minimal setup and effort. If a machine is found to have unaccept- able alignment, the procedure can be readily converted to a full alignment proce- dure and machine moves calculated.
Page 134 After viewing the tolerance plot(s), use the Enter key to advance to the next step in the procedure. In the next step, you will be given a choice to consider the align- ment finished, retake data, align the standard machine, or align the C-face machine.
Page 135 If Align C-face Machine is selected, data remains stored and you advance to the C- face Setup screen where the machine dimensions for the flange location where moves are to be made can be entered. Once the required dimensions have been entered use the Enter key to advance to the C-face Solution screen where the align- ment condition and machine moves can be viewed.
Page 136: Entering Thermal Growth Information
Entering Thermal Growth Information Thermal growth can cause a machine alignment to change significantly as machines are started from a “cold” position and run up to operating speed (“hot” position). The Thermal Growth screens allow you to enter the amount of thermal growth both machines experience during operation.
Page 137: Growth At Feet
Growth at Feet If Thermal Growth at Feet has been defined as the thermal growth method for the job, you are able to input the amount of vertical and horizontal thermal growth at each machine foot. Enter Growth at Feet Growth in the vertical direction is displayed in the upper section of the screen while growth in the horizontal direction is displayed in the lower section of the screen.
Page 138 Note If one or both machines actually experience a downward growth during operation, then negative numbers should be used for the ver- tical direction. If one or both machines experience a growth to the right during operation, then negative numbers should be used for the horizontal direction.
Page 139: Growth At Profile
Growth at Profile If Thermal Growth at Profile has been defined as the thermal growth method for the job, you are able to input the amount of vertical and horizontal thermal growth at a location other than at each machine foot. The program uses this information to calculate the vertical and horizontal thermal growth at each machine foot.
Page 140 Note Dimension I is negative, if the location of profile P4 is closer to the coupling than the outboard feet of the left machine. When entering any of the machine dimensions, they should be measured and extended to the nearest 1/8 inch (3 mm). Refer to the Entering Fractions section on page 3-51 for information about entering fractions.
Page 141 Enter key Use the Enter key to advance to the Enter Growth at Profile screen. Enter Growth at Profile The Enter Growth at Profile screen, allows entry of the amount of vertical and hor- izontal thermal growth at a location other than at each machine foot. Growth in the vertical direction displays in the upper section of the screen, while growth in the horizontal direction displays in the lower section of the screen.
Page 142 Note If one or both machines actually experience a downward growth during operation, then negative numbers should be used for the ver- tical direction. If one or both machines experience a growth to the right during operation, then negative numbers should be used for the horizontal direction.
Page 143 The Growth at Feet screen displays the calculated vertical and horizontal thermal growth at each machine foot. Growth in the vertical direction is displayed in the upper section of the screen while growth in the horizontal direction is displayed in the lower section of the screen.
Page 144: Gap/Offset
Gap/Offset If Gap/Offset has been defined as the thermal growth method for the job, you are able to input the vertical and horizontal thermal growth using the target gap and offset readings at the coupling. This is probably the most the commonly used con- version method of specifying thermal growth targets.
Page 145 When entering any of the machine dimensions, they should be measured and extended to the nearest 1/8 inch (3 mm). Refer to the Entering Fractions section on page 3-51 for information about entering fractions. Refer to the following table for a description of each dimension. Measure Dimension Measurement Description...
Page 146 Enter key Use the Enter key to advance to the Enter Gap/Offset Target screen. Enter Gap/Offset Target The Enter Gap/Offset Target screen, allows you to enter the gap and offset thermal growth target numbers at the coupling. Growth in the vertical direction is displayed in the upper section of the screen while growth in the horizontal direction is displayed in the lower section of the screen.
Page 147 Offset is the difference in the coupling halves at the top. For this parameter, either the coupling of the left machine is higher than the right machine or the coupling of the right machine is higher than the left machine. Set Gap and Set Offset keys Use the Set Gap and Set Offset keys to enter the gap and offset thermal growth for the corresponding direction.
Page 148: Face/Rim
Face/Rim If Face/Rim has been defined as the thermal growth method for the job, you are able to input the amount of vertical and horizontal thermal growth using target face and rim dial indicator readings. This is probably the second-most commonly used, conversion method of specifying thermal growth targets.
Page 149 When entering any of the machine dimensions, they should be measured and extended to the nearest 1/8 inch (3 mm). Refer to the Entering Fractions section on page 3-51 for information about entering fractions. Refer to the following table for a description of each dimension. Measure Dimension Measurement Description...
Page 150 Change Sensor Location key Use the Change Sensor Location key, when the coupling is selected (highlighted with the red box around it), to change the side of the coupling on which the target dial indicator readings are to be taken. The sensor location determines the direc- tion (sign) of the Rim TIR (Total Indicator Runout).
Page 151 The target face and rim dial indicator readings can be expressed in either mils or millimeters (mm), depending on the analyzer units. All values must be entered before continuing. The range of values that can be entered for both the face and rim readings are -2048 to 2048 mils or -52.02 to 52.02 mm.
Page 152: Reverse Dial
Reverse Dial If Reverse Dial has been defined as the thermal growth method for the job, you are able to input the amount of vertical and horizontal thermal growth using target reverse dial indicator readings. The program will then use this information to cal- culate the vertical and horizontal thermal growth at each machine foot.
Page 153 When entering any of the machine dimensions, they should be measured and extended to the nearest 1/16 inch (1.5 mm). Refer to the Entering Fractions sec- tion on page 3-51 for information about entering fractions. Refer to the following table for a description of each dimension. Measure Dimension Measurement Description...
Page 154 Enter key Use the Enter key to advance to the Enter Reverse Dial Target screen. Enter Reverse Dial Target The Enter Reverse Dial Target screen, allows you to enter the target reverse dial indicator readings. The target reverse dial indicator readings can be expressed in either mils or milli- meters (mm), depending on the analyzer units.
Page 155: Sweep Laser Heads
The Growth at Feet screen displays the calculated vertical and horizontal thermal growth at each machine foot. Refer to the Growth at Profile section on page 3-59 for more information. Sweep Laser Heads Once all required machine dimensions have been entered, you are automatically advanced to the Sweep Laser Heads step.
Page 156: Foot Pre-Check
Foot Pre-Check The Foot Pre-Check option allows you to check the soft foot condition of the machine being aligned. Refer to “Machinery Shaft Alignment — General Overview” on page A-1 for more information. If this option is enabled for this job, the Foot Pre-Check screens will be automati- cally displayed only once as you advance through the procedure.
Page 157 Once this option has been completed, it will not be automati- cally displayed if the Sweep Laser Heads step is re-entered. Note Emerson recommends that you always check all feet before acquiring alignment data. The current laser head position (represented by a hash mark on the outer most part of the circle) is displayed graphically at the bottom of the screen.
Page 158: Foot Pre-Check Function Keys
Foot Pre-Check Function Keys (prior to starting the Foot Pre-Check) Start Use the Start key to start the foot pre-check once you have verified that all hold- down bolts are tight and positioned the laser heads. Clear All Use the Clear All key to clear all acquired data on all feet if data has been acquired and stored on any foot.
Page 159 Check Lasers Use the Check Lasers key to check the operational status of the heads. Refer to the Check Lasers section on page 3-30 for more information. Performing a Foot Pre-Check Once the Foot Pre-Check starts, a prompt displays as notification to loosen the hold- down bolt for the selected foot and wait for the data to stabilize.
Page 160 Soft Foot The Soft Foot calculation is equal to ((the magnitude of the movement of the foot) divided by (dimension C — Bracket to Sensor distance)) divided by the Soft Foot Tolerance. The default Soft Foot Tolerance = 0.5 mils / inch. If Soft Foot has been defined for the job, the data is evaluated as follows: •...
Page 161 Note Both the Soft Foot and FDI tolerance values can be changed in UltraMgr and transferred to the Advanced Laser Align program. Warning! The numbers displayed are not the required correction shims for this foot. Soft Foot and FDI corrections frequently require wedge shaped arrangements of shims to be installed.
Page 162: Acquiring Alignment Data
Foot Pre-Check Function Keys (after the Foot Pre-Check has been started) Accept Use the Accept key to accept and store the reading for the active foot. The Enter key can be used to do the same. Check Lasers Use the Check Lasers key to check the operational status of the heads. Refer to the Check Lasers section on page 3-30 for more information.
Page 163 The four point automatic mode is a more traditional style of acquiring data for alignment. The laser heads are mounted on a shaft, and the shaft is then rotated so that data can be taken when the laser heads are at the 12 o’clock (0 or 360°), 3 o’clock (90°), 6 o’clock (180°), and 9 o’clock (270°) positions.
Page 164 Sweep Methods - General Information The sweep modes use data acquired at several different angular positions. By using Emerson’s patented process, this data is translated into readings for the four clock positions. There are several advantages to the sweep method over the 4 point method of acquiring data.
Page 165: Auto Sweep
Auto Sweep If Auto Sweep has been defined as the laser alignment method for the job, the laser heads automatically acquire data using their built-in inclinometers while the shaft is rotated. The arc of rotation can vary from as little as 45° to a full 360° (one revo- lution).
Page 166 Standard Mode This mode of operation (sometimes referred to as the Unidirectional Mode) is the mode that is most often used during Auto Sweep alignments. In this mode, a direc- tion of rotation is automatically defined for data acquisition based on the first rota- tion to progress past the starting point by 20°.
Page 167 Averaging Mode This mode of operation is intended to allow multiple sampling of data in order to reduce the noise in the data by averaging all of the acquired values. In the Aver- aging Mode, a direction of rotation for the data acquisition is defined in the same manner as it is in the Standard mode.
Page 168 There are four basic steps when acquiring alignment data using Auto Sweep. Turn on and position the laser heads at the starting angle. Using the Laser Align program, initialize the laser heads. With the 2130 analyzer set aside, sweep the laser heads. Using the Laser Align program, get the acquired data from the laser heads.
Page 169 Positioning heads for Auto Sweep The first data acquisition screen for Auto Sweep, prompts you to turn on and posi- tion the laser heads at the starting angle. For this method, the position of the laser heads can be at any angular position you desire to start from.
Page 170 Foot Pre-Check key Use the Foot Pre-Check key to perform a Soft Foot or FDI check. Refer to the Foot Pre-Check section on page 3-76 for more information about performing a Foot Pre-Check. Check Lasers key Use the Check Lasers key on the Alt screen to check the operational status of the heads.
Page 171 Note A maximum of 20 reading sets (moves) can be stored on an align- ment job. If more than 20 reading sets are acquired a message is dis- played giving you the option of either discard the last reading set taken or overwriting the 20th reading set with the last reading.
Page 172 Note For the Auto Sweep and Dual Pass methods, if the laser heads have not yet been initialized and they have not been turned off since they last acquired the last set of data, the data stored in the heads can be transferred to the analyzer without having to re-sweep the laser heads.
Page 173 Note To prevent damage to the laser heads, make sure the antennas do not come into contact with obstacles (e.g. the ground or base plate) as they are being rotated. Getting data from heads During the data transfer, the previous screen shows the progress of the data transfer for each laser head.
Page 174: Manual Sweep
If the fit is unsatisfactory (less than 85%) a warning message will be displayed to inform you that the data is “Unfit”. At this point you should either repeat the data acquisition or try to manually condition or edit the data using the edit data func- tion.
Page 175 Note Both laser heads need to be turned on for this option to function properly. When setting the job up to use Manual Sweep as the Laser Align Method for acquiring data, you must also select the acquisition mode to be either Standard or Averaging and set the sample rate.
Page 176 Averaging Mode The Averaging mode of operation is intended to allow multiple sampling of data in order to reduce the noise in the data by averaging all of the acquired values. In this mode of operation, the last 20 readings are averaged. Starting Manual Sweep On the data acquisition screen for Manual Sweep, the current laser reading (in mils or mm, depending on the analyzer units) for each laser head is displayed in reverse...
Page 177: Accept Readings Key
Note A minimum of 3 data points over a 45°sweep arc are required, but Emerson recommends a minimum of 8 data points (samples) acquired over a sweep arc of at least 90°. Note For the greatest accuracy and repeatability, all readings should be acquired using the same direction of rotation.
Page 178 Foot Pre-Check key Use the Foot Pre-Check key to perform a Soft Foot or FDI check. If you choose to do one of the Foot Pre-Check procedures then the software returns a warning that any data, previously collected and contained in the current data set, is deleted by proceding with this operation.
Page 179 Note A maximum of 20 reading sets (moves) can be stored on an align- ment job. If more than 20 reading sets are acquired a message is dis- played giving you the option to either discard the last reading set taken or overwrite the 20th reading set with the last reading.
Page 180: Auto 4 Point
If the fit is unsatisfactory (less than 85%), a warning message displays to inform that the data is “Unfit”. At this point either repeat the data acquisition, or try to manually condition or edit the data using the edit data function. This built-in check helps alert you to a problem with the reliability of the colleted data..
Page 181 Note When using the Auto 4 Point method, an alternative option to increasing the number of samples (or increasing the data averaging beyond 25 samples per reading), would be to stop the laser fixtures at each of the four clock positions and allow the program to continu- ously average the data.
Page 182 In addition to the green background, the analyzer LED will flash each time a new reading is measured when the laser heads are within 5° of each other and 3° of the active cardinal position. If the Status Beeper option located under the 2130 ana- lyzer’s Home/General Setup screen is enabled you will also hear the analyzer beep each time a new reading is measured when the laser heads are within 5°...
Page 183 “Enter” is pressed after the third reading has been acquired. Using only three readings increases the likeli- hood of error and does not allow the instrument to check data validity. Emerson does not recommend using only three readings if four are available.
Page 184 Foot Pre-Check key Use the Foot Pre-Check key to perform a Soft Foot or FDI check. If you choose to do one of the Foot Pre-Check procedures, the software warns you that any previ- ously collected data in the present data collection set will be deleted. Refer to the Foot Pre-Check section on page 3-76 for more information about performing a Foot Pre-Check.
Page 185: Manual 4 Point
If the data validity is unsatisfactory a warning message displays to inform you that an unsatisfactory data validity condition exists. At this point you should repeat the data acquisition. This built-in check helps alert you to the data losing reliability in the misalignment calculations.
Page 186 When setting the job up to use Manual 4 Point as the Laser Align Method for acquiring data, you must also set the sample rate. The sample rate determines the number of data samples that are to be collected and averaged together to produce a single Laser PSD reading.
Page 187 Accept Readings key Use the Accept Readings key, when the laser head positions and data are as desired, to store the data at the active cardinal position. Each time a data point is stored the next cardinal position in the clockwise direction is selected (highlighted with the red box around it).
Page 188 Caution! To prevent damage to the laser heads, make sure the antennas do not come into contact with obstacles (e.g. the ground or base plate) as they are being rotated. Also, when performing an uncoupled alignment and the laser heads are mounted in close proximity to each other, make sure the antennas do not come into contact with each other as one laser head is rotated past the other.
Page 189 Enter is pressed and after the third reading has been acquired. Using only three readings increases the likelihood of error and does not allow the instrument to check data validity. Emerson does not recom- mend using only three readings if four are available.
Page 190 Enter key Use the Enter key to accept the data, after you have acquired it. At this point the data is checked for validity. Refer to the Data Quality section on page 3-127 for more information. If the data validity is satisfactory, and Review Results is enabled on the Alt Main screen, the software displays the Review Measurements screen.
Page 191: Dual Pass
Dual Pass If Dual Pass has been defined as the laser alignment method for the job, the laser heads automatically acquire data using their built-in inclinometers as each laser head passes by each other. Except for how the data is acquired, this method func- tions similar to Auto Sweep, but like Manual Sweep, it is useful for performing uncoupled or non-rotational alignments.
Page 192 Note The Model 800001 direct connect cable can be used to enable the laser heads to communicate with the analyzer except when using the Dual Pass method. When setting the job up to use Dual Pass as the Laser Align Method for acquiring data, you must also set the Target Window percentage.
Page 193 Note If a lower percentage (smaller valid window) is selected, a slower rota- tional speed may be required especially with a smaller PSD (e.g. with the 10x10mm PSD on the 8215). For example, a 10% Target Window would define a 2mm wide window on an 8225 and a 1mm wide window on an 8215 centered around the PSD's vertical center- line in which data will be acquired as the laser beam passes across the window.
Page 194 Initialize Lasers key Use the Initialize Lasers key to initialize the laser heads and advance to the next step in the procedure. The Enter key can be used to do the same. Foot Pre-Check key Use the Foot Pre-Check key to perform a Soft Foot or FDI check. If you choose to do one of the Foot Pre-Check procedures, the software warns you that any previ- ously collected data in the present data collection set will be deleted.
Page 195 Note A maximum of 20 reading sets (moves) can be stored on an align- ment job. If more than 20 reading sets are acquired a message is dis- played giving you the option to either discard the last reading set taken or overwrite the 20th reading set with the last reading.
Page 196 Note For the Auto Sweep and Dual Pass methods, if the laser heads have not yet been initialized and they have not been turned off since they acquired the last set of data, the data stored in the heads can be trans- ferred to the analyzer without having to re-sweep the laser heads.
Page 197 The following scenario will more clearly illustrate how the Dual Pass method oper- ates. When the analyzer initializes the laser heads, all data is cleared. The laser heads then begin detecting the presence of the other laser head’s laser beam on its PSD. If a laser beam is not on a PSD, the laser head's LED will be flashed solid yellow.
Page 198 Note A minimum of 3 data points over a 45° sweep arc are required, but Emerson recommends a minimum of 8 data points be acquired over a sweep arc of at least 90°. Note Depending on the model, make sure either the Model 821510 or 8215C2-PM cable is connected to the laser fixtures prior to initializing them.
Page 199 During the data transfer, the previous screen shows the progress of the data transfer for each laser head. When the data transfer is complete, the data is analyzed and a sine wave is fit to the data.. If the fit is satisfactory (85% and above), the program will mark the Sweep Laser Heads step back on the Main screen completed and advance you to the next step in the procedure.
Page 200 To connect the 8215C2-PM Dual Pass cable to the laser fixtures, complete these steps: Connect the Lemo connector on one end of the Dual Pass cable to the mating straight Lemo connector of the extension cable, if applicable. Connect the Lemo connector on one end of the cable to the Lemo port under the nose of one of the laser fixtures.
Page 201: Review Results
Extension cables are 8 feet (2.4 m) long. With one extension cable and the Dual Pass cable, the total length is 10 feet (3 m) allowing a 9 feet 8 inch (2.9 m) span to be aligned. Note For similar information on connecting the 821510 direct connect cable when using the Dual Pass method for direct connect communi- cation between the analyzer and the laser fixtures, refer to Direct Connect (All Models) section for more information.
Page 202 Note If you exit the Review Measurements screen before saving the aver- aged reading set, you can return to it using the Review Results key on the Alt screen of the data acquisition screens. Review Measurements Screen The Review Measurements screen contains the alignment condition, the acquisi- tion date and time, and a symbol representing the acquisition method used for each of the readings acquired.
Page 203 If the Tolerance Type is Standard, alignment angle and offset data are displayed for both the vertical and horizontal directions. If the Tolerance Type is Jackshaft, align- ment left machine angle and right machine angle data are displayed. Angle Icon Offset Icon An icon depicting the alignment method and data condition displays just to the far right of each data reading.
Page 204: Review Results (Measurements) Function Keys
Enter key Use the Enter key to save the average reading set and advance to the tolerance plot screens where graphical representations of the alignment condition can be reviewed. Note If any reading used to calculate an average reading set was acquired using Auto Sweep, Manual Sweep, or Dual Pass, the associated sine fit data will not be saved once the average reading set is saved.
Page 205 Select/Unselect Use the Select/Unselect key to select the highlighted reading (place a check mark just to the left of the reading), or if the reading has already been selected, to unse- lect the reading (remove the check mark). The selected readings are used to calcu- late the average reading set displayed at the bottom of the screen.
Page 206: Sweep Mode Curve Data
Y- axis and the rotational position as the X-axis), a sine wave would be formed. Even when only part of the sine wave data is collected, Emerson’s Alignment software can still curve fit a sine wave to this limited data. Called curve fitting, all values used to determine the machine moves can be obtained from the completed sine waves.
Page 207: Data Quality
If the data correlation can not be brought into the acceptable level but the peak- peak amplitude is too high, then a message will be displayed advising you to check the system for looseness and then repeat the measurement. Another possible reason for this condition could be due to data points lying too far away from the sine fit curve.
Page 208 When using any 4 point method the data is always checked for validity. In theory, subtracting any third measurement from the sum of two opposing measurements will give the value of the 4th measurement (the one opposite the third measure- ment).
Page 209: Move Machine
Move Machine Once all required data has been acquired, the screen automatically advances to the Move Machine step. From the Main screen, the Move Machine step is reached by pressing the Move Machine key. Main screen after acquiring alignment data From the Move Machine step, you can review the machine moves for the vertical and horizontal directions.
Page 210: Vertical Move
To provide assistance for varying applications and circumstances, a couple of addi- tional options are provided. These additional options include: • An Extra Foot Calculation This option provides a calculation of the vertical and horizontal machine moves at machine foot locations other than those defined for the job. Refer to the Extra Foot Calculation section on page 3-143 for more information.
Page 211 The amount of movement at the machine feet (expressed in either mils or millime- ters (mm), depending on the analyzer units) is displayed in the upper section of the screen. If the movement is positive (upward) it will be displayed above the machine.
Page 212: Vertical Move Function Keys
The alignment condition of the machine with respect to the machine components defined for the job is displayed in the upper section of the screen while the align- ment condition of the machine with respect to the machine centerlines (repre- sented by dashed lines) is displayed in the lower section of the screen.
Page 213 From the Enter Dimensions screen, once the required dimensions have been entered, the Enter key will advance you back to the Move Machine screen. • If only the RPM and D, E, C, and F dimensions have been entered, then no alter- nate solutions will be available for the left machine.
Page 214 Data Detail Use the Data Detail key to advance to the tolerance plot screens where graphical representations of the alignment condition can be reviewed. Refer to the Data Detail (Tolerance Plots) section on page 3-162 for more information. In addition, if the data was acquired using the Auto Sweep, Dual Pass, or Manual Sweep methods you can manually condition or edit the sine curve data using the edit data function.
Page 215: Horizontal Move
Horizontal Move From the Horizontal Move screen review the machine moves for the horizontal direction. Horizontal Move Screen The amount of movement at the machine feet (expressed in either mils or millime- ters (mm), depending on the analyzer units) is displayed in the upper section of the screen.
Page 216 The bull’s-eye target displayed in the lower section of the screen represents the alignment condition with respect to the tolerances defined for the job. If the toler- ance condition is greater than 2 times the acceptable tolerance, then the outer band will be red.
Page 217: Horizontal Move Function Keys
Left and Right Arrow keys Use the Left and Right Arrow keys to toggle the machine move sets between the alternate pairs of feet. The Alternate Move key can be used to do the same. Refer to the Horizontal Move Function Keys: Alternate Move section (below) for more information.
Page 218 • If only the RPM and D, E, C, and F dimensions have been entered, then no alter- nate solutions will be available for the left machine. In this case, a warning message will be displayed when this key is selected. The warning message will prompt you to verify whether or not you want to input the missing dimensions required.
Page 219 Data Detail Use the Data Detail key to advance to the tolerance plot screens where graphical representations of the alignment condition can be reviewed. Refer to the Data Detail (Tolerance Plots) section on page 3-162 for more information. In addition, if the data was acquired using the Auto Sweep, Dual Pass, or Manual Sweep methods you can manually condition or edit the sine curve data using the edit data function.
Page 220: Dual Move
Dual Move From the Dual Move screen, you can review the machine moves for both the ver- tical and horizontal directions at the same time. Dual Move Screen (machine view) 3-140 Horizontal Alignment...
Page 221 Dual Move Screen (centerline view) Show Center Lines key Use the Show Center Lines key to view the alignment condition of the machine with respect to the machine centerlines. When viewing the alignment condition of the machine with respect to the machine centerlines, the amount of movement and direction of movement (represented by arrows) are displayed at the machine feet where machine moves will be made while black squares are displayed at the machine feet where machine moves will not to be...
Page 222 Live Move Use the Live Move key to observe machine movement while making machine moves. Refer to the Live Move section on page 3-149 for more information. If the Live Move option on the Alt Main screen is set to Horizontal Only, then the live move can only be performed in the horizontal direction.
Page 223: Extra Foot Calculation
Extra Foot Calculation From the Extra Foot Calculation screen you can calculate the vertical and hori- zontal machine moves for up to four machine foot locations in addtion to those defined for the job. The Extra Foot Calculation screen is reached by pressing the Extra Foot key on the machine move screens.
Page 224 Up, Down, Left, and Right Arrow keys Use the Up, Down, Left, and Right Arrow keys to select the field you want to modify (highlighted with the red box around it). Refer to the following table for a description of each dimension. Measure Dimension Measurement Description...
Page 225: Predict Mode
Note Extra Foot dimensions and calculations are stored temporarily in ana- lyzer memory. Enter key Use the Enter key to advance back to the move screen this option was accessed from. Predict Mode From the Predict Mode screens you can calculate the resulting alignment condi- tion based on the current alignment condition and having moved the machine the amount specified in the program.
Page 226 The Predict Mode Vertical screen functions similarly to the Predict Mode Horizontal screen described below. Predict Mode Horizontal Screen Selecting the Predict Mode option from the Horizontal Move screen displays the Predict Mode Horizontal screen. This screen displays the movement calculated by the align program to align the machine horizontally.
Page 227 The foot pair for which movement is shown corresponds to the foot pair selected on the machine move screen when the Predict Mode option is selected. The amount of movement at the machine feet (expressed in either mils or millimeters (mm), depending on the analyzer units) which the align program calculates in order to bring the machine into alignment is displayed in the upper section of the screen.
Page 228 Once you have selected a foot, enter a number corresponding to the proposed move for that foot. For vertical moves, upward is positive and downward is negative. For horizontal moves, left is positive and right is negative. The range of values that can be entered is -1000 to 1000 mils or -25.4 to 25.4 mm.
Page 229: Prediction Function Keys
Prediction Function Keys Repeat Predict Mode Use the Repeat Predict Mode key to return to the Predict Mode screen. It may be necessary to repeat the process before a suitable solution is found that will bring the alignment condition within tolerance. Predict Vertical Use the Predict Vertical key to advance to the Predict Mode Vertical screen.
Page 230 Note If a live move has been done in say the vertical direction, and fol- lowing this you then go directly to the Horizontal Move screen (or visa versa) and try to start the live move there, a warning message will be displayed to inform you that a live move may have been done since alignment data was last acquired.
Page 231 The Vertical Live Move screen functions similarly to the Horizontal Live Move screen described below. Horizontal Live Move Screen Selecting the Live Move option from the Horizontal Move screen displays the Hor- izontal Live Move screen. This screen displays the movement required to align the machine horizontally.
Page 232 Caution! Do not loosen the machine feet hold down bolts until after the live move has been started. Loosening the hold down bolts prior to starting the live move can cause the move to be incorrect. The amount of movement at the machine feet (expressed in either mils or millime- ters (mm), depending on the analyzer units) is displayed in the upper section of the screen.
Page 233 If the Status Beeper option located under the 2130 analyzer’s Home/General Setup screen is enabled and the Enable Alert option is enabled, the audible tone will be generated as described above, but if the Status Beeper option located under the 2130 analyzer’s Home/General Setup screen is disabled and the Enable Alert option is enabled, the audible tone will not be generated as described above.
Page 234 Left and Right Arrow and Alternate Move keys Use the Left and Right Arrow and Alternate Move keys to toggle the machine move sets between the alternate pairs of feet. Alignment condition is greater than 2 times the acceptable tolerance 3-154 Horizontal Alignment...
Page 235 Once the live move has been started loosen the machine feet hold down bolts then move the machine(s) until they are within tolerance. Alignment condition is 1 to 2 times the acceptable tolerance Laser Address Selection 3-155...
Page 236 Alignment condition is less than the acceptable tolerance, but greater than the excellent tolerance 3-156 Horizontal Alignment...
Page 237 Live Move option. Caution! Do not use a hammer to move machines. These impacts may move either sensor head, causing improper machine positioning. Emerson recommends that you use jack bolts (permanent or portable). Laser Address Selection...
Page 238 Caution! On completion of a live move, always acquire a new set of alignment data to verify and finalize the machine’s alignment condition. 3-158 Horizontal Alignment...
Page 239 Caution! Never rely on a live machine move for the final alignment condition of the machine. Since there is always some variability introduced into the alignment data due to shaft clearances, bearing faults, base deterioration, etc. Refer to the Data Quality section on page 3-127 for more information. Dual Live Move Screen (machine view) Laser Address Selection 3-159...
Page 240 Dual Live Move Screen (centerline view) Selecting the Live Move option from the Dual Move screen displays the Dual Live Move screen. This screen displays the movement required to align the machine ver- tically and horizontally at the same time. When viewing the alignment condition of the machine with respect to the machine centerlines, the amount of movement and direction of movement (represented by arrows) are displayed at the machine feet where machine moves are to be made...
Page 241 Show Center Lines key Use the Show Center Lines key to view the alignment condition of the machine with respect to the machine centerlines. This key is only active when the Live Move option on the Alt Main screen is set to Vertical and Horizontal. Show Machine key Use the Show Machine key to view the alignment condition of the machine with respect to the machine components defined for the job.
Page 242: Data Detail (Tolerance Plots)
Data Detail (Tolerance Plots) From the Data Detail (Tolerance Plot) screens you can review the graphical repre- sentation of the alignment condition. In addition, if the data was acquired using the Auto Sweep, Dual Pass, or Manual Sweep methods you can manually condition or edit the sine curve data using the edit data function.
Page 243 Dual Tolerance Plot On the dual tolerance plot screen, the alignment data is plotted similarly to the four quadrant tolerance plot, except in this case the absolute value of each of the read- ings is plotted. Laser Address Selection 3-163...
Page 244 Single Tolerance Plot (Vertical) Single Tolerance Plot (Horizontal) On the single tolerance plot screens, alignment data is plotted similarly to the dual tolerance plot, except in this case the data plotted is either for the vertical or hori- zontal direction only. 3-164 Horizontal Alignment...
Page 245 For all plot types • Alignment reading sets will be plotted on the x-y graph with lines connecting each of the data points for a given direction. Vertical data points display in blue while hor- izontal data points display in red. •...
Page 246: Data Detail (Tolerance Plot) Function Keys
Data Detail (Tolerance Plot) Function Keys Display Sine Fit Use the Display Sine Fit key to advance to the sine fit data plot where you can review and manually condition or edit the sine curve data. This key is only active if the data was acquired using the Auto Sweep, Dual Pass, or Manual Sweep methods.
Page 247 Cursor Home Use the Cursor Home key to advance the cursor to the “Home” or newest data point displayed. In this case, this is the last data point acquired. Clear Cursor Use the Clear Cursor key to deactivate (clear) the cursor from the plot. This key is only active when a cursor is active.
Page 248 Display Sine Fit From the Sine Fit (Sine Curve Data) plot screen you can review and manually con- dition or edit the sine curve data. This screen is reached by pressing the Display Sine Fit key on the tolerance plot screens. This option is available only when the alignment data was acquired using the Auto Sweep, Dual Pass, or Manual Sweep methods.
Page 249 • Point This variable indicates the number of the selected point. • Angle This variable indicates the angular position (in degrees) of the selected point. • Vert This variable indicates the actual vertical position (in mils or mm, depending on the analyzer units) of the selected point.
Page 250 Emerson does not recommend making moves based on sine fit percentages of less than 70%. Although sine fits less than 70% can be used, Emerson recommends another set of readings be made to try and improve the accuracy. Sine fits above 90% provide the highest repeatability.
Page 251 45° of the rotation of the laser heads. Emerson recommends you sweep at least 90°; however accuracy still may be reduced even at 90°.
Page 252: Display Sine Fit Function Keys
If enough data points were acquired, but they are displayed in a randomly scattered pattern across the screen the measured misalignment amplitudes will decrease while the ratio of noise to the signal increases. In this case, problems (e.g. a bearing fault, a loose coupling, a rub, etc.) can distort the sine fit curve.
Page 253 Chng Active Plot Use the Chng Active Plot key to change the active plot (marked with a red box around it). When most of the functions, available on this screen, are selected they are applied to the active plot. Switch Plot Type Use the Switch Plot Type key to toggle the plot type between the left and right laser head data plots together, the left laser head data plot only, or the right laser head data plot only.
Page 254: View Data
View Data From the View Data screen you can review the alignment data in the traditional car- dinal positions (0°, 90°, 180°, and 270°). The View Data screen is reached by pressing the View Data key on the tolerance plot screens. View Data Screen This data cannot be edited and is simply provided for the convenience of those who are accustomed to recording the data in this manner or who wish to use this data...
Page 255: C-Face Alignment
Display Actual Data key Use the Display Actual Data key, to see the “raw data,” (the position of the beam on each target). If the top reading for both machines is zero (such as the case would be if the saved reading set was the averaged result from multiple acquisitions) this key is not available.
Page 256 This option is available by selecting the Align C-face Machine option after viewing the tolerance plot(s) for a Quick Spec job. Refer to the Quick Spec section on page 3-53 for more information. C-Face setup screen The C-face Setup screen allows you to enter the dimensions for the flange location where moves are to be made.
Page 257 When entering any of the machine dimensions, the flange dimensions should be measured and extended to the nearest 1/8 inch (3 mm). Refer to the Entering Fractions section on page 3-51 for information about entering fractions. Up, Down, Left, and Right Arrow keys Use the Up, Down, Left, and Right Arrow keys to select the field you want to modify (highlighted with the red box around it).
Page 258 Measure Dimension Measurement Description to the Nearest Center of flange to be moved to the laser head face on the upper 1/8 inch machine. To enter a measurement for a flange that falls inside (3 mm) the laser face, place a negative sign (–) in front of it. 1/8 inch The bolt pattern diameter.
Page 259 The alignment condition is displayed just below the machine graphics. Depending on the analyzer units, since the tolerance type can only be Standard when per- forming a C-face alignment the alignment angle data displayed will be in mils/inch or milliradian (mrad) while offset data displayed will be in mils or millimeters (mm).
Page 260: Notes
Notes From the Notes screen notes can be assigned to the current job. In addition to pre- defined notes user defined notes can also be created and assigned to the current job from under this option. The Notes screen is reached by pressing the Notes key on the Alt Main screen.
Page 261 User Defined Notes Use the User Defined Notes key to advance to the User Defined Notes screen where you can then select a user defined note from that list. If you have no user defined notes, you can use this screen in order to create them. Select Create User Note, type in the note (32 characters maximum), and then press the Enter key to create the note and add it to the list.
Page 262 Add to Job Use the Add to Job key to add the highlighted note to the job. Notes allow you to record specific comments about the equipment that you might not be able to remember later. You can record observations about the equipment that you are monitoring.
Page 263 Prev Group Use the Prev Group key to display the previous group of predefined notes. Defined Notes Use the Defined Notes key to advance to the predefined Notes screen where you can then select a predefined note from that list. Some predefined notes will use the machine names defined for the job.
Page 264: Transferring Alignment Job Data And Tolerances
Transferring Alignment Job Data and Tolerances The option to transfer alignment jobs and tolerances is only available in the Advanced Laser Align program. Alignment jobs can be transferred to and from the Personal Computer (PC) while alignment tolerances can only be transferred from the PC to the analyzer.
Page 265 Connect for Transfer The Connect for Transfer option is available from the Job Manager screen. PC Communications Screen When the Connect for Transfer option is selected the PC Communications screen is displayed. From this screen you can select between loading alignment jobs from the PC, dumping alignment jobs to the PC, and loading an alignment tolerance table from the PC.
Page 266 Note RBMcom must be launched before the Connect for Transfer option is selected. If it hasn’t been launched, a warning message displays when the Connect for Transfer option is selected. Set Storage Location, Load Jobs, and Dump Data keys Refer to the RBMcom and Other Communications with the Analyzer section of the Model 2130 analyzer Machinery Analyzer User’s Guide (P/N 97017) and Machinery Health Manager’s RBMcom Help file for information about con- necting to a host computer or network in order to set the storage location, to load...
Page 267 Load Tolerance Table key Use the Load Tolerance Table key to load an alignment tolerance table from the PC into the analyzer without loading an alignment job. The alignment tolerance table contains the tolerance values for standard, jackshaft, and vertical alignment jobs, as well as soft foot and FDI tolerance values.
Page 268 Load Tolerance Table key Use the Load Tolerance Table key to load the default tolerance table for the selected (highlighted) database into the analyzer. After the new set of alignment tolerance values are loaded into the analyzer's memory, any new job created from that point will use the new set of alignment tolerance values.
Page 269 RBMcom Since most of the options available in RBMcom function similarly for all Model 2130 analyzer programs refer to the RBMcom and Other Communications with the Analyzer section of the Model 2130 Machinery Analyzer User’s Guide (P/N 97017) and Machinery Health Manager’s RBMcom Help file for additional infor- mation.
Page 270 Before any alignment jobs and the alignment tolerance table option will show up in the tree, the Show Alignment Jobs option under the User Preferences General tab must be selected (checked). User Preferences Note The analyzer must have the Advanced Laser Align program enabled in order to transfer alignment jobs and tolerances between the PC and analyzer.
Page 271 The options for transferring alignment jobs from the analyzer to the computer are handled in the same manner supported for other transferable entities (e.g. routes and jobs). That includes the ability to transfer jobs via drag and drop or using the “Data Dump”...
Page 272 The options for transferring alignment jobs and the alignment tolerance table to the analyzer from the computer are done in the same manner supported for other transferable entities (e.g. routes and jobs). That includes the ability to transfer jobs and the alignment tolerance table via drag and drop or using the “Data Load” button option.
Page 273: Tolerances
Note In Machinery Health Manager, the same recommended alignment tolerance values used as defaults in the analyzer are used as the data- base's default alignment tolerance values until changed by the user. The Load Defaults option on the Alt Main screen can be used to delete any alignment tolerance values loaded into the analyzer from the PC.
Page 274: Ultramgr/2130 Laser Align Overview
UltraMgr/2130 Laser Align Overview The figure below illustrates how jobs can be moved in and out of various areas of UltraMgr’s database and the analyzer. Definitions of the job types follow. Analyzer - (Slave/Master) UltraMgr (PC) - (Master/Slave) UltraMgr Database Store Activate Assigned Job(s) Area...
Page 275: Case Studies
Definitions of the four job types illustrated in the UltraMgr/2130 Laser Align figure are: • Assigned jobs — jobs that have been assigned to a machine. • Unassigned jobs — jobs that have been moved from the Stored Jobs area of the analyzer into the UltraMgr database but have not been assigned to a machine.
Page 276 Note You may not be able to edit all fields, depending on the state of the job. Case 2 Begin with an activated job from the Stored Job area. If you change a job in the Current Job area, that change affects the job in the stored job area. Case 3 This case is referred to as job “cloning”...
Page 277 Modifications to change the Job Type to these fields Unassigned Modified Alignment Data Alignment Method Coupling Mach Desc Mach ID Machine Dimension: A & E (between feet) Machine Dimension: B, C, D, & F Machine View (also called machine configuration) Notes Station Thermal Growth...
Page 278 Unassigned Jobs — If you create a new job or make change(s) to an existing job that causes it to be Unassigned, when dumped, it will be placed in the Unassigned Area of the alignment database. From there, you can use UltraMgr to assign it to a machine within the database.
Page 279: Ultramgr
UltraMgr UltraMgr is a versatile, PC-based, database software package that is used to manage corrective technologies data. The storage of alignment information in a database provides many advantages which include: • The ability to quickly retrieve and review the alignment status of all equip- ment in an entire plant to help plan the maintenance priorities and sched- uling.
Page 280: Ultramgr Software And Firmware Prerequisites
UltraMgr Software and Firmware Prerequisites Note Your AMS™ Suite: Machinery Health™ Manager software and Model 2130 RBMC must have compatible software. ONSULTANT Requirements Model 2130 RBMC firmware version v.6.3.8.0 or later. ONSULTANT The following, 4.90 or later, AMS™ Suite: Machinery Health™ Manager files - dated 08/08/2005 or later: •...
Page 281: Tolerances
Tolerances The amount of offset and angular misalignment displayed is based upon the last full set of alignment readings. All shaft misalignment is a combination of offset and angular misalignment (See “Alignment Application Notes” on page A-3.). This screen breaks down the misalignment into each component. The amount of each type of misalignment is shown for both the horizontal and vertical direc- tions (for horizontal machines).
Page 282 Optimum alignment occurs when offset and angle are zero. In most cases, that degree of accuracy is not practical. For that reason, tolerances are used to set an achievable goal. Emerson’s recommended tolerances (referenced to RPMs) are listed in the table below.
Page 283 Excellent Acceptable Offse Speed Offset Angle Angle (RPM) (mm) (mrad) (mrad) (mm) < 500 0.13 0.15 501 - 1250 0.1 0.13 1251 - 0.08 2000 2001 - 0.05 0.08 3500 3501 - 0.03 0.25 0.05 7000 > 7000 0.01 0.03 0.25 Metric Data Units Values in the table are assumed to be pure offset or pure angle.
Page 284 The curves at the lower left are the tolerances to shoot for. Depending on RPM, they can be modified in UltraMgr and then transferred to the analyzer. See “UltraMgr” on page 3-199 for more information. The alignment condition (with respect to the tolerances) can be monitored by observing the tolerance target during the live move.
Page 285 The chart above shows the Angle and Offset for a machine that operates at 2000 — 3500 RPM plotted together. A pure angle reading of 0.45 mils/inch (0.44 mrad) and a pure Offset reading of 2.5 mils (0.06 mm) are marked by the arrows. These readings are clearly in the acceptable range when looked at individually.
Page 286 Emerson’s recommended tolerances are listed in the following table. Excellent Acceptable Angle Angle Speed (mils/inch or (mils/inch or (RPM) mrad) mrad) < 500 501 - 1250 1251 - 2000 2001 - 3500 3501 - 7000 > 7000 3-206 Horizontal Alignment...
Page 287: Chapter 4 • Vertical Alignment
Chapter Vertical Alignment The vertical alignment feature of the Advanced Laser Align application is used to collect and display alignment data for machines in which the machine moves are done at the machine flange (e.g. C-face mounted motors). These consist of one machine component mounted on another, bolted together at a flange.
Page 288 Measurements should be taken with the laser system set up across the coupling to determine the offset and angle between the two shafts. Correct the angle by shim- ming in the vertical direction. The offset is corrected by sliding the machine at the flange.
Page 289: Help
Help Depending on where you are within the program, an alignment helper may be available at the bottom of the screen to provide you with a brief explanation of the highlighted step or screen. In addition to the alignment helper, a more detailed explanation of the highlighted step is available for the highlighted step by pressing the 2130 Help key once and for the screen by pressing 2130 Help key twice.
Page 290 Vertical Main Screen The vertical main Laser Align Application screen (sometimes referred to as the Main Menu) lets you monitor your progress throughout the alignment job. When a vertical alignment job is active, the Main screen will look as shown below. Vertical Main screen at job start The application defaults to a predefined setup when a new job is created.
Page 291: Three Step Alignment
The steps required to perform an alignment are displayed in the center portion of the main screen. The 2130 Laser Align program leads you through each step of a routine alignment procedure starting with the Enter Dimensions selection at the Main screen.
Page 292: Vertical Main Screen Function Keys
Vertical Main Screen Function Keys Enter Dimensions Use the Enter Dimensions key to advance to the Edit Dimensions screen where the dimensions for the machine being aligned can be entered. This is the first step of the three-key operation used in performing an alignment job. Refer to the Vertical Enter Dimensions section on page 4-17 for more information.
Page 293: Vertical Alt Main Screen
Vertical Alt Main Screen The vertical Alt Main screen (also known as the Main Menu Alt2 screen) allows you to setup alignment job parameters. The Alt Main screen is reached by pressing the Alt key on the Main screen. Vertical Alt Main Vertical Alt Main Screen...
Page 294: Vertical Alt Main Screen Function Keys
Vertical Alt Main Screen Function Keys Note Use the Notes key to advance to the Notes screens where notes can be assigned to the current job. In addition to the predefined notes, user defined notes can also be created and assigned to the current job from under this option.
Page 295 Laser Sample Rate Use the Laser Sample Rate key to set the number of samples (in the range 1 to 25) to be averaged together to generate a single reading. Two samples (default) are typ- ically sufficient, but for example, if too much background vibration is present, you may want to increase the number of samples to 25.
Page 296: Job Reset
Print Job The Print Job key prints a summary report of the current job to the Virtual Printer, if the Virtual Printer is enabled under the General Setup screen of the System Firm- ware. A summary report includes job information, notes, soft foot data, and reading set data (machine feet moves and Angle/Offset data).
Page 297: Vertical Machine Configuration
Vertical Machine Configuration From the Machine Configuration screen you can select the machine components for the current vertical alignment job. The Machine Configuration screen is reached by pressing the Machine Config key on the Alt Main screen. Vertical Machine Configuration Screen When this option is first selected, the machine type defined for the upper machine will be highlighted by a red box around the machine type by default.
Page 298: Vertical Machine Configuration Function Keys
When “Other” is selected as the machine type you can enter a machine name (up to 7 characters in length). The following machine types can be defined for the job: Vertical Machine Types Vertical Machine Configuration Function Keys Select Upper Machine Use the Select Upper Machine key to set the upper machine component to the machine type highlighted by the red box.
Page 299: Laser Angle Advance
Laser Angle Advance From the Laser Angle Advance subwindow you can define the fine and coarse incremental adjustments to be applied to the angular position of the laser heads during the data acquisition and live move operations. The Laser Angle Advance subwindow is reached by pressing the Laser Angle Advance key on the Alt Main screen.
Page 300: Laser Angle Advance Function Keys
Laser Angle Advance Function Keys Fine Use the Fine key to define the fine incremental adjustment (in degrees) to be applied to the angular position of the laser heads during the data acquisition and live move operations. The range of values that can be entered for the fine adjust- ment is 1 to 5 degrees.
Page 301: Vertical Laser Configuration
Vertical Laser Configuration From the Laser Configuration screen you can configure the location for each of the laser heads during the alignment, check and set the heads and analyzer address, and check the operational status of the heads. The Laser Configuration screen is reached by pressing the Laser Config key on the Alt Main screen.
Page 302: Vertical Laser Configuration Function Keys
Although both Head A and Head B of the older version of Model 8215/8225 laser heads have gray front panels with black grid lines, A and B are marked on the front panel of the laser head. The newer version of Model 8215/8225 laser heads have A and B marked on the front panel, and additionally can be identified by their dif- ferent colored front panels.
Page 303: Vertical Enter Dimensions
Note Both laser heads need to be turned on for this option to function properly. • Show Laser Angle Use the Show Laser Angle key on the Alt screen to display the laser angle. This option is useful when performing alignments on horizontally mounted machinery where the movement is at the flange instead of at the feet.
Page 304 Note This section assumes that the fixtures are set up to the point that the laser heads are mounted. Vertical Enter Dimensions Screen Note Unlike a horizontal job, when a machine has been configured as a “Fixed” machine for a vertical job the program will require all dimen- sions to be entered for that machine.
Page 305 The machine RPM should be unique for each coupling that is defined for this job. If you have a variable speed machine, enter the highest RPM at which the coupling will be operated. Also, if a coupling design has shafts operating at different speeds enter the larger of the two.
Page 306 Note The dimensions are the same for both the Model 8215 and the Model 8225 laser heads. Up, Down, Left, and Right Arrow keys Use the Up, Down, Left, and Right Arrow keys to select the field you want to modify (highlighted with the red box around it).
Page 307: Define Flange
Define Flange The Define Flange screen, allows you to enter the dimensions for the flange loca- tion where moves are to be made. Define Flange Screen (circular flange) Vertical Alt Main Screen 4-21...
Page 308 Define Flange Screen (rectangular flange) Enter key Use the Enter key to advance to either the Sweep Laser Heads step or the Custom Pattern screen. If the custom pattern option is not enabled, once all required dimensions have been entered, the Enter Dimensions step back on the Main screen will be marked completed and you will advance to the Sweep Laser Heads step.
Page 309: Define Flange Function Keys
Define Flange Function Keys Change Flange Type Use the Change Flange Type key to toggle the displayed flange type between a circle (default) and a rectangle. Custom Pattern Use the Custom Pattern key to enable or disable (default) the custom bolt pattern option for the flange.
Page 310 Pattern X Width When a circular or rectangular flange is defined, use the Pattern X Width key to define the X dimension width of the flange. Dimensions can be expressed in either inches or millimeters (mm), depending on the analyzer units. The range of values that can be entered for the pattern X Width is 1 to 1000 inches or 25.4 to 25400 mm.
Page 311: Custom Pattern
Custom Pattern The Custom Pattern screen, allows you to customize the flange (e.g. move the shaft center away from the flange center or move one or more bolts to a nonsymmetrical location). The Custom Pattern screen is reached by pressing the Enter key on the Define Flange screen, when the Custom Pattern option is enabled.
Page 312 Up and Down Arrow keys Use the Up and Down Arrow keys to select the item (e.g. the shaft center or bolt) you want to modify. When the shaft center is selected it will be highlighted in red while a selected bolt will be highlighted with the red circle around it. The Item to Edit key can be used to do the same.
Page 313: Custom Pattern Function Keys
Custom Pattern Function Keys Insert Bolt Use the Insert Bolt key to insert an additional bolt at the selected bolt location. This in turn moves the bolt originally at that location to the flange center. This key is only active when the item selected for modification is a bolt. Delete Bolt Use the Delete Bolt key to delete the selected bolt.
Page 314 Angle Use the Angle key to define the angle (in degrees) for the selected item. The range of values that can be entered is 0° to 360°. This option is not available when the method is set to X/Y Offset. Radius Use the Radius key to define the radius for the selected item.
Page 315: Vertical Sweep Laser Heads
Vertical Sweep Laser Heads Once all required machine dimensions have been entered, you are automatically advanced to the Sweep Laser Heads step. From the Main screen, the Sweep Laser Heads step is reached by pressing the Sweep Laser Heads key. Main screen after entering vertical dimensions The Manual Sweep method is used to acquire vertical alignment data.
Page 316 Although a complete sweep is recommended, it is not needed. The arc of rotation can vary from as little as 45° to a full 360° (one revolu- tion); however, Emerson does recommend a minimum of 90°. Starting Manual Sweep...
Page 317 The defined flange is displayed graphically in the bottom of the screen. The data acquisition angular location corresponding to the actual angular location of the laser heads is displayed just below the flange. A graphical representation of the data acquisition angular location is displayed in the center of the flange. The data acqui- sition line starts at the 0°...
Page 318 Review Results key Use the Review Results key on the Alt screen to return to the Review Measurements screen where you can continue reviewing and averaging together the results from multiple acquisitions. This key is available only when the Review Results option is enabled on the Alt Main screen and the Review Measurements screen has been exited before the averaged reading set was saved.
Page 319 Note A minimum of 3 data points over a 45° sweep arc is required, but Emerson recommends a minimum of 8 data points (samples) acquired over a sweep arc of at least 90°. Note For the greatest accuracy and repeatability, all readings should be acquired using the same direction of rotation.
Page 320 Clear key Use the Clear key to clear the displayed data average, when the Laser Mode is set to Averaging. When the Laser Mode is set to Standard, this key is not available. Enter key Use the Enter key to accept the data, after you have acquired enough data (sam- ples).
Page 321 Get Laser Angle key Use the Get Laser Angle key on the Alt screen to automatically get the angle posi- tion of the laser heads. This option is useful when performing alignments on hori- zontally mounted machinery where the movement is at the flange instead of at the feet.
Page 322 Manually Locate Angle key Use the Manually Locate Angle key on the Alt screen similarly as you would the Get Laser Angle key except this key is used to manually locate the data acquisition angular location corresponding to the actual angular location of the laser heads. Since the angle sensors do not operate properly in the vertical orientation you will have to hide them and manually enter this information.
Page 323 Vertical Review Results From the Review Results (Measurements) screen, you are able to review and average together the results from multiple acquisitions. This option is useful when the repeatability of the data is a concern. Refer to the Sweep Mode Curve Data sec- tion on page 3-126 and Data Quality section on page 3-127 for more information.
Page 324: Vertical Move Machine
The Review Measurements screen contains the alignment condition (angle and offset), the acquisition date and time, and a symbol representing the Manual Sweep acquisition method used for each of the readings acquired. Note A maximum of 20 reading sets (moves) can be stored on an align- ment job.
Page 325: Angular Move
(mm), depending on the analyzer units) is displayed in the table just to the right of the flange. Emerson recommends that the flange bolts be loosened and the shims be added (or removed) as suggested in the table. When correcting angular misalignment keep the flange offset movement to a minimum.
Page 326: Angular Move Function Keys
Enter key Use the Enter key to advance to the next step in the Offset Move screen. Angular Move Function Keys Raise Machine Use the Raise Machine key to display the shim values equivalent to raising the machine. In this case, all shim values will be positive. Median Use the Median key to display the shim values equivalent to making the smallest moves.
Page 327: Offset Move
Offset Move From the Offset Move screen, you can review the offset alignment condition. Offset Move Screen (dual move) Vertical Alt Main Screen 4-41...
Page 328 Offset Move Screen (single move) The bull’s-eye target displayed just above the flange represents the alignment con- dition with respect to the tolerances defined for the job. If the tolerance condition is greater than 2 times the acceptable tolerance, then the outer band will be red. If the tolerance condition is 1 to 2 times the acceptable tolerance, then the middle band will be yellow.
Page 329 Enter key Use the Enter key, once you have viewed the machine moves, to advance to the Main screen where the Move Machine step is marked completed and the Sweep Laser Heads step is highlighted. Main screen after viewing machine moves Vertical Alt Main Screen 4-43...
Page 330: Offset Move Function Keys
Offset Move Function Keys Switch Move Type Use the Switch Move Type key to toggle the displayed move type between Angular Move and Offset Move. Data Detail Use the Data Detail key to advance to the tolerance plot screens where graphical representations of the alignment condition can be reviewed.
Page 331: Vertical Data Detail (Tolerance Plots)
Vertical Data Detail (Tolerance Plots) From the Data Detail (Tolerance Plot) screens you can review the graphical repre- sentation of the alignment condition. In addition, you can manually condition or edit the sine curve data using the edit data function. Refer to the Display Sine Fit section on page 3-168 for more information.
Page 332 On the four quadrant tolerance plot screen, if the Tolerance Type is Standard, alignment angle versus offset data is plotted. In this plot, both the positive and neg- ative values for the reading sets are plotted. Vertical Single Tolerance Plot On the single tolerance plot screen, alignment data is plotted similarly to the four quadrant tolerance plot, except in this case only the absolute values for the reading sets are plotted.
Page 333 Vertical Alignment Live Move The Live Move option allows you to observe machine movement while making machine moves. The Live Move option is initiated by pressing the Live Move key on the Offset Move screen. Note Both laser heads need to be turned on for this option to function properly.
Page 334 Note If you try to start another live move after stopping a live move opera- tion and before a new set of data has been acquired, a warning mes- sage will be displayed to inform you that a live move may have been done since alignment data was last acquired.
Page 335 The Live Move screen prompts you to position the laser heads before starting the live move. The defined flange is displayed graphically at the bottom of the screen. The data acquisition angular location corresponding to the actual angular location of the laser heads is displayed just below the flange. A graphical representation of the data acquisition angular location is displayed in the center of the flange.
Page 336 Caution! Do not loosen the flange hold down bolts until after the live move has been started. Loosening the flange hold down bolts prior to starting the live move can cause the move to be incorrect. Alignment condition is greater than 2 times the acceptable tolerance Once the live move operation is started, the offset movement required to align the machine is displayed just to the right of the flange.
Page 337 Live Move option. Caution! Do not use a hammer to move machines. These impacts may move either sensor head, causing improper machine positioning. Emerson recommends that you use jack bolts (permanent or portable). Vertical Alt Main Screen...
Page 338 Caution! On completion of a live move, always acquire a new set of alignment data to verify and finalize the machine’s alignment condition. Caution! Never rely on a live machine move for the final alignment condition of the machine. Since there is always some variability introduced into the alignment data due to shaft clearances, bearing faults, base deterioration, etc.
Page 339 Show Shim Table Use the Show Shim Table key to display the last shim table and values selected back on the Angular Move screen. If Raise Machine was last selected, then the shim values are equivalent to raising the machine. In this case, all shim values will be pos- itive.
Page 340 Get Laser Angle key Use the Get Laser Angle key on the Alt screen to automatically get the angle posi- tion of the laser heads. This option is useful when performing alignments on hori- zontally mounted machinery where the movement is at the flange instead of at the feet.
Page 341 Angles automatically collected (After Start) The current laser head positions are displayed just below the flange. The back- ground of the angle positions will be white if the laser heads are not within 2° of each other and green when the laser heads are within 2° of each other. The average angle position (represented by a red line or red hash mark) is displayed on the inside or outer most part of the flange, depending on the screen.
Page 342 Manually Locate Angle key Use the Manually Locate Angle key on the Alt screen similarly as you would the Get Laser Angle key except this key is used to manually locate the data acquisition angular location corresponding to the actual angular location of the laser heads. Since the angle sensors do not operate properly in the vertical orientation you must hide them and manually enter this information.
Page 343: Chapter 5 • Straightness Measurements
Chapter Straightness Measurements The straightness feature found in the Advanced 2130 Laser Align application is used to determine surface profiles. This profile can be of a motor baseplate or checking the crown on a rolling application. You must use a set of laser sensor heads and mounting fixtures (CSI model 8AA50) to acquire surface profile read- ings.
Page 344 Help Depending on where you are within the program, an alignment helper may be available at the bottom of the screen to provide you with a brief explanation of the highlighted step or screen. In addition to the alignment helper, the functionality of any soft key is available.
Page 345: Straightness Main Screen
Straightness Main Screen The straightness main Laser Align Application screen (sometimes referred to as the Main Menu) lets you monitor your progress throughout the straightness job. When a straightness job is active, the Main screen will look as shown below. Straightness Main screen at job start The application defaults to a predefined setup when a new job is created.
Page 346: Three Step Straightness Measurements
The steps required to acquire straightness measurements are displayed in the center portion of the main screen. The 2130 Laser Align program leads you through each step of a routine straightness procedure starting with the Enter Dimensions selection at the Main screen. Once a straightness job has started the next uncompleted step in the recommended procedure is highlighted.
Page 347: Straightness Main Screen Function Keys
Straightness Main Screen Function Keys Enter Dimensions Use the Enter Dimensions key to advance to the Edit Dimensions screen where the dimensions for the profile being measured can be entered. This is the first step of the three-key operation used in performing a straightness job. Refer to the Straight- ness Enter Dimensions section on page 5-11 for more information.
Page 348: Straightness Alt Main Screen
Straightness Alt Main Screen The straightness Alt Main screen (also known as the Main Menu Alt2 screen) allows you to setup straightness job parameters. The Alt Main screen is reached by pressing the Alt key on the Main screen. Straightness Alt Main Straightness Alt Main Screen Function Keys Note Use the Notes key to advance to the Notes screens where notes can be...
Page 349 Laser Mode Use the Laser Mode key to define the mode of operation for the alignment method defined. When selected, the mode is toggled between Standard (default) and Averaging. The Standard mode of operation is the mode that is most often used when acquiring straightness data.
Page 350 Job Reset The Job Reset key allows the operator to "Clear Job Data" or "Load Default Values". Clear Job Data Use the Clear Job Data function to clear all stored data and notes from the active job. Before any data is cleared, a warning message will be displayed asking the oper- ator if this is truly the operation to be performed.
Page 351: Straightness Laser Configuration
Straightness Laser Configuration From the Laser Configuration screen you can configure the location for each of the laser heads during the profile measurements, check and set the heads and ana- lyzer address, and check the operational status of the heads. The Laser Configura- tion screen is reached by pressing the Laser Config key on the Alt Main screen.
Page 352: Straightness Laser Configuration Function Keys
Note The program automatically knows whether the Model 8215 or the Model 8225 laser heads are being used. Straightness Laser Configuration Function Keys Change Laser Config Use the Change Laser Config key to togglethe configuration of the laser heads. The display must be set to match the actual location for each of the laser heads based on how the machines are to be viewed during the alignment.
Page 353: Straightness Enter Dimensions
Straightness Enter Dimensions The Enter Dimensions screen allows you to enter the dimensions for the profile being measured. The Enter Dimensions screen is reached by pressing the Enter Dimensions key on the Main screen. Note This section assumes that the fixtures are set up to the point that the laser heads are mounted.
Page 354 The configuration shown above is for the left fixture (Head A in this case) to be fixed (represented by a dashed line/arrow pointing in the direction of the moved fixture) while the right fixture (Head B in this case) is to be moved (identified with position numbers).
Page 355 If the last segment displayed is not the last measurement location for the moveable laser head defined, the reference line will extend beyond the last laser head dis- played to indicate that more measurement locations are defined (as illustrated above). Six Measurement locations defined A graph representing the overall setup is displayed at the bottom of the screen.
Page 356 Dimensions can be expressed in either inches or millimeters (mm), depending on the analyzer units. The range of values that can be entered is 0.01 to 3600 inches or 0.254 to 91440 mm. Each dimension should be measured and extended to the nearest 1/8 inch (3 mm).
Page 357: Straightness Move Laser Heads
Straightness Move Laser Heads Once all required machine dimensions have been entered, you are automatically advanced to the data acquisition screen. From the Main screen, the data acquisition screen is reached by pressing the Move Laser Heads key. Main screen after entering profile dimensions Laser communications with the moveable head must be established to collect data at the defined segments.
Page 358 In general this alignment method is most easily accomplished by having the sleep- mode of the laser heads disabled. Note To disable the sleep mode on each laser head, with the laser heads powered off, press and hold down the Power Buttons. This will cause the laser heads and their corresponding LED’s to power on for approximately 2 seconds.
Page 359 The current laser reading (in mils or mm, depending on the analyzer units) is dis- played for the selected segment (highlighted with the red box around it). Dashed lines displayed just under a segment indicate that no data has been accepted for that segment.
Page 360: Straightness Surface Profile
Last key Use the Last key to move to the last segment (furthest from the fixed head). Left and Right Arrow keys Use the Left and Right Arrow keys to move to the next segment to the left and right. Clear key Use the Clear key to delete a reading stored on the selected segment.
Page 361 From the surface profile plot screen, you can review the results of the profile mea- surements. Surface Profile Plot Segment readings will be plotted on the x-y graph with lines connecting each of the readings. Readings will be either in mils or millimeters (mm), depending on the analyzer units.
Page 362 • Segment number This variable indicates the segment number of the selected reading. • Distance This variable indicates the segment distance from the fixed laser head. • Measured value This variable indicates the measured reading value for the segment. • Height This variable indicates the height of the segment reading from the laser reference line (dotted line).
Page 363 Enter key Use the Enter key, once you have reviewed the surface profile, to advance to the Main screen where the Surface Profile step is marked completed and the Move Laser Heads step is highlighted. Main screen after viewing surface profile 5-21...
Page 364 5-22 Straightness Measurements...
Page 365: Chapter A • Application Information
Appendix Application Information Machinery Shaft Alignment – General Overview Poor shaft alignment can cause the following problems: • Bearing failure • Shaft deflection fatigue • Seal leakage and failure • Coupling failure • Internal heating • High energy consumption • Excessive vibrations (studies have shown that almost 50% of excessive vibra- tion in direct-coupled rotating equipment is due to misalignment) Proper machine alignment will result in: •...
Page 366 These types of errors are even more likely to occur when you have pressure to com- plete the job quickly. The Emerson CSI alignment equipment can help you avoid these kinds of mis- takes. Our adjustable brackets are designed to fit most machines. Since there are no axial projecting arms, bracket sag is zero.
Page 367: Alignment Application Notes
Alignment Application Notes To achieve ideal machine alignment, the shaft centerline of one machine element (such as a motor) must coincide with the centerline extension of another machine shaft (such as a pump) during operation. In more complex applications, three or more elements may be aligned in a train.
Page 368 Misalignment can occur both horizontally and vertically. Most misaligned machines have a combination of offset and angular misalignment (see following figure). Alignment Examples...
Page 369: Pre-Job Preparation And Setup
Pre-job Preparation and Setup Before starting any alignment job, the history of alignments performed on this machine(s) should be reviewed. Were any special problems found during the pre- vious alignment; if so, what were they (soft foot, piping strain, coupling problems, etc.)? How well was the machine aligned and who performed the alignment? Answering these questions along with having a predefined job setup reduces the pre-job preparation time and decreases the total time to do the job.
Page 370: Changes That Occur During Operation
Coupling Considerations Emerson’s alignment system is not affected by axial float and the effects from tor- sional play (backlash) in the coupling are minimal. However, you should ensure that the coupling is properly installed and not in such poor condition that it adversely affects the alignment process.
Page 371 Different Thermal Expansion Rate Examples The Model 2130 Laser Align program allows you to input the amount of vertical and horizontal thermal growth at each machine foot. There are several methods that can be used to calculate this growth. Alignment Application Notes...
Page 372: Alignment Pitfalls
Alignment Pitfalls Some pitfalls to good alignment are: • Improperly or not correcting for soft foot • Thermal growth • Excessive shaft play or radial clearances • Bent shafts • Damaged bearings • Torsional play...
Page 373: Appendix B • Foot Pre-Check Types
Appendix Foot Pre-Check Types Foot Pre-Check Measurement Methods – Soft Foot and Frame Distortion Index (FDI) Soft foot is a condition where all feet (typically four) of a machine component (such as a motor or gearbox) will not rest on the same plane. This condition also exists if the machine baseplate pads (where the machine foot rests) are not on that same plane.
Page 374 This method assumed that a parallel soft foot existed. However, a large percentage of problem feet are angular soft feet (similar to Fig 2). Correcting this type of problem with a full shim can make the condition worse (see Fig 3). Correction should be determined with a set of thickness gauges (feeler gauges).
Page 375 Soft Foot Evaluation The Soft Foot evaluation provides you with a sense of severity without showing numbers. Numbers are not used because, most of the time, they are mistaken for the value of the shims (totally wrong). When the numbers are calculated, they are compared against the tolerance (usually 0.5 mils/inch).
Page 376 Note The tolerance can be changed in UltraMgr and downloaded to the analyzer. See “Tolerances” on page 3-193 for more information on loading tolerances to the analyzer. The number is evaluated by measuring the vertical angle and applying it to an old millwright’s “rule of thumb”.
Page 377: Appendix C • Technical Specifications
Appendix Technical Specifications Model 8215/8225 Laser Alignment Fixtures Specifications Specification Description Laser Diode In-Ga-Al-P, Class II (CDRH) / Class2 (IEC), Visible Wavelength 670 nm (typical) Output power Pulsed, <1.0 mW (average) Laser Safety Class Class II (CDRH) / Class2 (IEC) FDA 21CFR 1040.10 and 1040.11 <225 µrad (8215), <30 µrad (8225), Beam Divergence...
Page 378 Model 8215/8225 Laser Alignment Fixtures Specifications (continued) Specification Description Humidity 10 to 95%, non-condensing Power management Auto “sleep” and “power down” modes Battery Nickel cadmium RF Operating Frequency 916.5 MHz Models 821500 and 822500 Only RF Operating Range 0 - 50 ft (0 - 15 m), typical Models 821500 and 822500 Only Battery life...
Page 379: Mounting Posts (Part Number D23465) For Alignment Brackets
Mounting Posts (part number D23465) for Alignment Brackets The mounting post, used to secure the laser fixture to the mounting bracket (refer to “Installing a Post” on page 2-27 for more information), can be used on the fol- lowing brackets: Carbon Steel (B821007), Soft Mount/non-Rotational (A800052), Narrow Mount (A8AA54), Quick Mount Narrow (A8AA55), Magnetic Mount (A800056), and Magnetic Base for Straightness Measurements (A8AA50).
Page 380 Note If possible, use extension blocks instead of longer mounting posts since extension blocks offer a more stable bracket configuration, resulting in more accurate, repeatable data. Extension blocks are available only for B821007 and A800052 mounting brackets.
Page 381: Appendix D • Accessories And Optional Products
Appendix Accessories and Optional Products Optional Items for Laser System Part No. Description A832001 ....Mounting Chain extension, 2 ft (660 mm), A800052 soft-mount base D22773 ....Mounting Chain extension, 2 ft (660 mm), B821007 standard mounting base 800002 ....Direct Connect extension cable, 8 ft (2.4m), with one straight and one right-angle Lemo connectors 800003 ....
Page 382: Recommended Spare Parts
Recommended Spare Parts* Part No. Description D22745....Chain Clip for B8221007 and A800052 mounting bases 8AA10....CSI Tape Measure, 6 ft (2 m) * Other spare parts are available upon request. Analyzer Travel/Carrying Cases Part No. Description D24492....Hard shell case (locking) for analyzer and laser fixtures Batteries/Analyzer Chargers Part No.
Page 383: Customer Support
(865) 671-4274 (4CSI). To reach the Sales Support department, dial (865) 675-2110 and ask our receptionists to direct your call. To extend the level of support to Emerson customers, we have an electronic mail system which is connected through the Internet directly to the Customer Support group.
Page 384: Reliability Services
Support for the username and password. Reliability Services Emerson provides a broad range of in-plant services including startups, database troubleshooting and diagnostics. Our Machinery Health Services Group consists of qualified individuals with experience in a variety of technologies and industries.
Page 385 Glossary Accuracy How close a measurement is to the absolute quantity being measured. Alignment Positioning two or more machines so that the rotational centerlines of their shafts are co-linear under operating conditions. Anchor Bolts (or Hold-down Bolts) Bolts use to anchor or hold the machine to the base or foundation. Angularity The angle between two machine shaft centerlines;...
Page 386 Brackets (or Fixtures) Components that mount to machine shafts or couplings to measure the relative position of the centerlines of two machines. Coefficient of Thermal Expansion The constant value or factor of expansion of a metal for a given increase in temper- ature per length of the metal.
Page 387 Face-rim Method (or Rim-face Method) A method of shaft alignment measurement where the indicators are mounted radi- ally and axially on one machine or the other (not both). Fixtures See Brackets. Foundation The surface, often made of concrete, to which the machine baseplate is mounted, often with grout between the baseplate and foundation to provide even support.
Page 388 Jackshaft A long shaft used as a spacer between two machines. Usually identified with a number and description; represents data accumulated during an individual alignment session. Machinery Train Three or more machines that must be aligned to one another. Master When used as a communications term, it is the unit that controls and determines when data will be transferred.
Page 389 Off-line to On-line Running Condition Movement of shaft centerlines associated with (or due to) a change in pressures, temperatures and other forces between the static and operating condition. Offset Distance between rotational centerlines at any given normal plane, usually mea- sured at the coupling midpoint.
Page 390 Rim and Face Method See Face-rim Method. Rise/Run For smaller angles, the ratio obtained when the change in offset between two cen- terlines is divided by the distance along either centerline (between the points of offset measurement). In effect, it is the slope of one line in a plane compared to another line in the same plane.
Page 391 Spacers A generic term for any coupling that has two flex planes separated by a connecting shaft without bearings or other supports (between the flex points). Sometimes called an insert or spider. Spool Piece Any piece of pipe or shafting which can be removed from a line of piping or shafting without disturbing or disassembling any other components.
Page 392 Tolerance The maximum permissible deviation from a specified alignment position, defining the limits of offset at the coupling center and angularity. UltraMgr Machinery Health Manager’s database management software package used to store technology specific information, such as alignment or balance job details. Unassigned Job A job that has not been assigned to stations and machines in the UltraMgr data- base.
Page 393: Index
Index Numerics operating temperature 2-18 setup overview 2-18 8000-I, connecting 2-34 to 2-35 LED Functionality 2-9 Auto Sweep 2-33, 2-44 machine alignment, causes of changes in A-6 machine coupling checking A-6 battery correct A-6 usage, laser heads 2-16 machine foundation preparation A-5 block manual, organization of the 1-1 adding 2-inch 2-48...
Page 394 A-2 examples A-3 major steps in A-1 overview A-1 pre-job preparation A-5 shaft misalignment types of A-4 spare parts D-2 thermal growth A-6 different expansion rates A-7 Tolerances 3-193, 3-201 tolerances, Emerson recommended 3-202 types of shaft misalignment A-4 UltraMgr...
