OPERATION & MAINTENANCE MANUAL

2.3 VIEW MODE DETAILS

Looking at the names assigned to the console front panel pushbuttons and display field, note that some appear in
white lettering, others in orange. Only the black or white-lettered name assignments apply to the VIEW mode.
The seven-segment data display is formatted so that the currently selected data item appears on the right-hand side,
with the corresponding tank ID to the left, as indicated on the front panel. The LED annunciators on the left-hand side
indicate alarm conditions. An alarm indicator corresponds to the displayed tank when the particular LED is on steady.
If the LED is blinking, this indicates that an alarm has occurred on a tank other than the one being displayed.

Pushbutton Operation:

MODE: The MODE pushbutton functions both as a Display Mode Select (i.e. STEP) and a Product Name Recall. If
the user depresses and holds MODE until an Audible beep is heard, the display will STEP to the next display item.
See following page for examples of the TMS Display showing varied information. Display items include, in order of
appearance:
Display Item
Gross Volume (uncompensated)
Net Volume (temperature compensated)
Percent Volume
90% Ullage
Product Level
Water Level
Product Temperature
To recall the name of the product stored in the selected tank, depress and immediately release MODE. The product
name will appear for two seconds, then the display will revert back to displaying the currently selected data item.
TANK SELECT: The TANK SELECT pushbutton is used to select a desired tank for display. Each time TANK
SELECT is depressed, the console advances to the next enabled tank and its corresponding tank ID appears on the
data display. This is called MANUAL tank selecting. An automatic tank select or AUTO SCAN mode is also available.
In the AUTO SCAN mode, the display automatically and continuously scans through each enabled tank, holding the
display for five seconds before advancing to the next tank. This mode is useful for hands-free operation. AUTO SCAN
is enabled by depressing and holding TANK SELECT until an audible beep is heard. To turn off the AUTO SCAN
feature, again depress and hold TANK SELECT until an audible beep is heard. The system is now in the manual
mode.
TEST: Test mode allows visual verification of display operation, audible verification of the audible annunciator, and
self-verification of critical system hardware.
PRINT: Depressing the PRINT pushbutton while in the VIEW mode generates an on-demand inventory report
followed by an alarm status report for Tanks and Sensors.
PAPER FEED: The PAPER FEED pushbutton is used to advance paper through the printer mechanism.
NOTE: Alarms, errors or warning conditions, which occur during VIEW mode, will activate the front panel visual and
audible annunciators. The user can silence the audible annunciator by momentarily pressing any front panel
pushbutton. The visual annunciator will remain active until the alarm or error condition is eliminated. If subsequent
alarms, errors, or warnings occur, the audible annunciator will again be activated.
TMS Operations and Maintenance Manual.docx
English
Units Resolution
Gallons x1
Gallons x1
% Gallons x0.1
Gallons x1
Inches x0.1
Inches x0.1
°F x+/-0.1
PAGE 9
TMS2000/3000
Metric
Units Resolution
Liters x1
Liters x1
% Liters x0.1
Liters x1
Millimeters x1
Millimeters x1
°C x+/-0.1
February 12, 2018
