OPERATION & MAINTENANCE MANUAL

2.4.1.2 DELIVERY LOG

Log
Inventory
deLivery
SALES
tHEFtS
Orders
Water
tank Leak
Leak Hist
LIne Leak
ALArMS
Events
return
DeLivery
Deliveries: A Transaction Log representing the addition or delivery of the primary liquid or Product to the
tank. All transactions depend on the TMS Clock functionality to be recognized.
Record Storage Capacity: 12. 1 Tank Channel per record.
TMS Configuration Prerequisites:
Configuration menu, Probe submenu, Motion Height Band: Defines Transaction recognition
Configuration menu, Probe submenu, Minimum Logged Volume: Defines Transaction Logging
Group ID: Record Number.
Record Identification Data:
mm-dd
Date (Month-Day): Date the Delivery was recorded.
Note: an empty record will show 00-00.
Time (Hour' Minute): Time the Delivery was recorded.
HH'nn
Note: time stored in 24 hr. format
Examples: 12'00 = 12 Noon
tank Name Tank Name: As Assigned in the Configuration menu, Tank submenu.
Prod type Product Type: As Assigned in the Configuration menu, Tank submenu.
tank id
Tank ID Number: As Assigned in the Configuration menu, Tank submenu.
Captured Data:
Begin Ht
Beginning Height: Total Liquid Level at the Beginning of the Delivery.
End Ht
Ending Height: Total Liquid Level at the End of the Delivery.
Beg temp
Beginning Temperature: Average Product Temperature at the Beginning of the Delivery.
End tEmP
Ending Temperature: Average Product Temperature at the End of the Delivery.
Gr End Gross Ending Volume: Total Gross Volume at the End of the Delivery.
Gr Begin
Gross Beginning Volume: Total Gross Volume at the Beginning of the Delivery.
Gr diFF
Gross Difference: Total Gross Volume Delivered to tank. Calculated as:
(Gross Ending Volume) – (Gross Beginning Volume).
Net End
Net End Volume: Total Net Volume at the End of the Delivery.
Net Begin Net Begin Volume: Total Net Volume at the Beginning of the Delivery.
Net diFF
Net Difference: Total Net Volume Delivered to tank. Calculated as:
(Net Ending Volume) – (Net Beginning Volume).
Exit Delivery submenu:
Return Return: Press EDIT (TEST) to exit Delivery submenu.
Note: Press STEP (MODE) to return to top of Delivery submenu showing mm-dd (Month-Day)
TMS Operations and Maintenance Manual.docx
Inventory
Deliveries
Bulk Sales
Thefts
Product Reordering Report
Bottom Water Removal
In-Tank Leak Test – Detailed Results
In-Tank Leak Test – History
LS300 Line Leak Test
Alarms
Events
Return
23'59 = 11:59 PM
PAGE 18
TMS2000/3000
00'00 = Midnight
February 12, 2018
