OPERATION & MAINTENANCE MANUAL
Height
Height #: Applies to Custom 3 and Custom 8 Tank Types. For Custom 3, Heights 1-3 are
calculated by the TMS from the Tank Radius and are NOT editable. The corresponding Volumes
from the Tank Manufacturer's calibration chart should be entered in the Volume # menu item
that follows. For Custom 8, Heights must be entered from lowest (1) to highest (8) with volumes
entered in the corresponding Volume # menu item. Evenly spacing the heights may result in
accurate readings for tank with minor symmetry problems. For more substantial differences,
contact Pneumercator for guidance.
Entry Type: 5-digit numeric
Range Limits: 0 – 1999.9 inches [0 – 49,999 millimeters]
Default/Initialized value: 0. 0 [0]
VOLUMe Volume #: Applies to Custom 3 and Custom 8 Tank Types. The Volumes entered must
correspond to the Height # from the previous menu item.
Entry Type: 6-digit numeric
Range Limits: 0 – 999,999 gallons [0 – 999,999 liters]
Default/Initialized value: 0
theft En Theft Enable: Enables Theft monitoring for the specified Tank Channel. The Hours of Operation
for the Site must be defined in the Thefts submenu within the Configuration menu. A Theft is
defined as a loss of Product during a time when the facility should be Closed. Thefts meeting
the Logged Minimum Volume requirement defined in the Probe submenu of the Configuration
menu will be recorded in the Thefts Log.
Entry Type: select list
Range Limits: No, Yes
Default/Initialized value: no
UnUsEabLe Unusable Volume: Excluded from the Total Tank Volume to create Usable Fuel Volume used
in the Product Reordering (Orders) Log.
Entry Type: 6-digit numeric
Range Limits: 0 – 999,999 gallons [0 – 999,999 liters]
Default/Initialized value: 0
UngageabL Ungaugeable Level: The amount of liquid that remains in the tank after the Product float has
dropped to the bottom of the probe stem. In most cases this would be a minimal amount of liquid
below the siphon which is typically considered to be of no consequence. In cases where this
point would be above the siphon, the TMS can provide an Low Product Information Message
at the bottom of the Product Float travel.
Entry Type: 5-digit numeric
Range Limits: 0 – 9,999.9" [0 – 99,999 millimeters]
Default/Initialized value: 0. 0 [0]
gen tank
Generator Tank Leak Test Mode: Enables monitoring of a Generator Tank for a Sudden Loss.
This is performed via a static In-Tank Leak Test comparable to Auto Leak Test Mode except
that testing continues throughout the month regardless of whether a Leak Test has been
successfully completed for the month. The generator would be monitored for activity via CC
Input and the In-Tank Leak Test would be performed during periods of inactivity. Typical Leak
Test settings include 2 hour Test Length and 0.7 GPH [2.8 LPH] Leak Limit.
Entry Type: select list
Range Limits: No, Yes
Default/Initialized value: no
LL SeLeCt LS300 Line Leak Select: Provides the means for a LS300 Line Leak Channel to be associated
with a Tank Channel for the purpose of reporting Line Leak statuses properly.
Entry Type: select list
Range Limits: No. 1 – 8
Default/Initialized value: no
return
Return: Press EDIT (TEST) to exit Tank submenu.
Note: Press STEP (MODE) to return to top of Tank submenu showing
TMS Operations and Maintenance Manual.docx
PAGE 44
TMS2000/3000
tank En (Tank Enable)
February 12, 2018
