OPERATION & MAINTENANCE MANUAL

2.4.1.9 LS300 LINE LEAK TEST LOG

Log
Inventory
deLivery
SALES
tHEFtS
Orders
Water
tank Leak
Leak Hist
LIne Leak
ALArMS
Events
return
LIne Leak LS300 Line Leak Test: Contains the Date and Time of the latest Pass and Fail for each of the three
supported Line Leak Rates. The TMS does NOT perform the Line Leak Test. An external LS300 Line
Leak Console connects to the TMS via RS-232 in support of this Log.
Record Storage Capacity: 8
TMS Configuration Prerequisites:
Configuration menu, Header submenu, Serial Format settings: Selects RS-232 port for LS300 support.
Group ID: LS300 Line Leak Channel Number.
Record Identification Data:
Prod Name Product Name: Tank Name assigned by user to the associated Tank Channel.
Captured Data:
Pass 3gPH Pass 3 GPH: Date and Time of the latest passing 3 GPH [12 LPH] test.
FaiL 3gPH Fail 3 GPH: Date and Time of the latest failing 3 GPH [12 LPH] test.
Pass . 2 gPH Pass 0.2 GPH: Date and Time of the latest passing 0.2 GPH [0.8 LPH] test.
FaiL . 2 gPH Fail 0.2 GPH: Date and Time of the latest failing 0.2 GPH [0.8 LPH] test.
Pass . 1 gPH Pass 0.1 GPH: Date and Time of the latest passing 0.1 GPH [0.4 LPH] test.
FaiL . 1 gPH Fail 0.1 GPH: Date and Time of the latest failing 0.1 GPH [0.4 LPH] test.
Exit Line Leak submenu:
Return Return: Press EDIT (TEST) to exit Line Leak submenu.
Note: Press STEP (MODE) to return to top of Line Leak submenu showing mm-dd
(Month-Day)
TMS Operations and Maintenance Manual.docx
Inventory
Deliveries
Bulk Sales
Thefts
Product Reordering Report
Bottom Water Removal
In-Tank Leak Test – Detailed Results
In-Tank Leak Test – History
LS300 Line Leak Test
Alarms
Events
Return
PAGE 25
TMS2000/3000
February 12, 2018
