2.4.3.7 SYSTEM CONFIGURATION – RELAY LLP (LS300 Line Leak Panel)
Config
Header
tank
Probe
ReLy tank
ReLy cc
ReLy Sens
ReLy LLP
ReLy Site
ReLy Mode
cc input
Sensr inp
Inventory
tHeft
Modem
diaL out
tank LEAk
AnaLogout
Relay – LS300 Line Leak Test Failure Triggers: Each failed line leak test reported by the external
ReLy LLP
LS300 Line Leak Panel (LLP) can affect up to three relay outputs. The TMS3000 currently supports
up to 32 Relay Outputs and the TMS2000 systems currently support up to 18 Relay Outputs. The
Group ID shown corresponds to the hardware channel for the LS300 Line Leak Panel.
faiL 0. 1 LS300 Line Leak Test Failure Trigger: Any of the three possible LS300 Leak Rates can have
faiL 0. 2
its failure affect up to three relays. The LS300 supports Leak Rates of 3.0 GPH, 0.2 GPH,
FaiL 3. 0
and 0.1 GPH [12.0 LPH, 0.8 LPH, 0.4 LPH].
Entry Type: numeric list
Range Limits: Each Relay: No (No Relay Assignment), 1-32 (TMS3000), 1-18 (TMS2000)
Note: Each assignment separated by decimal point.
Default/Initialized value: no. n o. n o
Return
Return: Press EDIT (TEST) to exit Relay LLP submenu.
Note: Press STEP (MODE) to return to top of Relay LLP submenu showing faiL 0. 1
(Fail 0.1 GPH)
TMS Operations and Maintenance Manual.docx
Header – General System Settings
Tank – Tank Channel specific including geometry and SetPoints
Probe – Level Gauging Probe settings
–
Relay Tank Relay Assignments to Tank Channel Specific conditions
Relay CC – Relay Assignments to individual Non-Hazardous CC Inputs
Relay Sensor – Relay Assignments to individual Leak/Point Level Sensor Inputs
Relay LLP – Relay Assignments to external LS300 Line Leak failures
Relay Site – Relay Assignments to Site-Specific conditions
Relay Mode – Relay-specific behavior settings
Non-Hazardous Contact Closure (CC) Inputs
Leak/Point Level Sensor Inputs
Shift Inventory Report Schedule
Theft – Detection (Hours of operation)
Modem/Serial C Communications
Auto-Dial out - Setup for selected Alarms or Tank information
In-Tank Leak Test – Setup
Analog Outputs
