OPERATION & MAINTENANCE MANUAL
********************************************************************************************************
The next group of settings pertain to 6 Product SetPoint Firmware Only (Vxx01xx) and are used to configure the
numbered Product SetPoints.
Crit High Product SetPoint Activation Thresholds: A Product SetPoint represents a range defined as a
SP HiHi combination of two values: (1) the threshold is a numeric value that defines the percent volume
SP High
that must be met or exceeded to be considered in alarm and (2) the direction implied by the
SP Lo
base name of High and Low. A base name of High includes the range at and above the defined
LoLo
threshold while the base name of Low includes the range at and below the defined threshold.
Crit Lo
Setting the threshold to zero disables the SetPoint.
Entry Type: 3 digit numeric as a percent of total Tank Capacity.
Range Limits: Over, Under 0.0-99.9%
Default/Initialized value: Critical High: 98. 0
CritHHorn SetPoint Horn: Indicates whether the integrated horn activates for the specified Product
HiHi Horn SetPoint. The Horn will only activate if the Product SetPoint is assigned to an SP Alarm LED.
High Horn See above setting regarding mapping Product SetPoints to an SP Alarm LED. Logging and
Lo Horn
Printing are unaffected by this setting.
LoLo Horn Entry Type: select list
CritLHorn Range Limits: Yes, No
Default/Initialized value: Critical High: no
This ends the group of settings that pertain to 6 Product SetPoint Firmware Only (Vxx01xx). All settings that follow
pertain to all firmware versions unless otherwise noted.
********************************************************************************************************
h2o EnabL H2O Enable: Bottom water may be monitored using a dual float probe. If this setting is disabled,
the Bottom Water Level displayed will be fixed at zero inches/millimeters.
Entry Type: select list
Range Limits: No, Yes
Default/Initialized value: no
SP h2o
Water Setpoint: A Bottom Water SetPoint represents a range defined as a combination of two
values: (1) the threshold is a numeric value that defines the level that must be met or exceeded
to be considered in alarm and (2) the direction of over (>) or under (<) determines whether the
range includes everything above or below the threshold. For example, a value of Over 2
inches/50 mm means the alarm will activate when the product level increases to 2 inches/50
mm and remains in alarm when above 2 inches/50 mm. Setting the threshold to zero disables
the SetPoint.
Entry Type: 5-digit numeric
Range Limits: Over, Under 0 – 1999.9 inches [0 – 49,999 millimeters]
Default/Initialized value: >0000. 0
TMS Operations and Maintenance Manual.docx
95. 0
High High:
90. 0
High:
20. 0
Low:
Low Low: 15. 0
Critical Low: 12. 0
yes
High High:
yes
High:
yes
Low:
Low Low: no
Critical Low: no
