Page 1: User Manual
User Manual Color Video Door Phone CDV-43N • Thank you for purchasing COMMAX products. • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly. -
Page 2: Table Of Contents
Table of Contents 1. Warnings and Cautions................2 Part Names ....................3 Package Contents ..................3 Wiring and Connection Instructions............4 Installation ....................Operation ......................6 Settings ....................Specifications and Features..............7 1. W arning and Cau tion Prohibition. Warning It may cause a serious damage or No disassembly injury if violated. -
Page 3: Part Names
3. Package Contents Parts Names TFT-LCD POWER LED MONITOR BUTTON I NTERPHONE BUTTON WALL BRACKET DOOR RELEASE MOUNTING CDV-43N HANDSET BUTTON SCREW(2EA) MONITOR FIXING SCREW(1EA) COLOR ADJ. BRIGHTNESS ADJ. HANDSET VOLUME CONTROLLER CONNECTION POWER SWITCH CONNECTOR... -
Page 4: Wiring And Connection Instructions
2. Blue: GND 2. Blue: GND 3. Yellow: Power (+12V) 3. Yellow: Power (+14V) 4. White: Video 4. White: Call signal CDV-43N Each device should be connected by CAMERA 1 separated cables. If you use UTP CABLE[CAT.5] for DOOR #1(RE) -
Page 5: Installation
. Installation Note SCREW M3X6(1EA) ① Avoid the range of direct sunlight ② Recommended height is pertinent SCREW T4X18(2EA) from 1450 ~ 1500mm ③ Avoid the installation near magnetic activity, humid temperatures and gas ▷ Extension of monitors Extendable When adding a second monitor, visual and audio quality of video may deteriorate... -
Page 6: Operation
6. Operation 1. Calling of visitor The visitor Open the door The visitor’ s presses the image appears call button on A chime Dialog begins on the monitor T T h h e e d d o o o o r r r r e e l l e e a a s s e e f f u u n n c c t t i i o o n n the camera sounds o o p p e e r r a a t t e e s s o o n n l l y y w w h h e e n n t t h h e e v v i i s s i i t t o o r r ’... -
Page 7: Settings
7. Settings Setting screen mode to select the proportion of image marked in the screen. - By pressing INTERPHONE BUTTON (screen setting button) repeatedly during monitoring mode or calling door entrance mode, the screen ratio will be changed as following in order.(You cannot adjust during talking mode) ZOOM →... - Page 8 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com PM0743N00010 Printed In Korea / 2016.07.104...
