User Manual

Color video door phone CDV-40QM
• Thank you for purchasing COMMAX products.
• Thank you for purchasing COMMAX products.
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
instructions to use a product exactly.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDV-40QM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Commax CDV-40QM

Summary of Contents for Commax CDV-40QM

  • Page 1: User Manual

    User Manual Color video door phone CDV-40QM • Thank you for purchasing COMMAX products. • Thank you for purchasing COMMAX products. • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.

  • Page 2: Table Of Contents

    Greetings ● Thank you for choosing COMMAX. ● Please read this manual carefully before you use the product. Table of contents Greetings ........................1 Contents table ......................1 1. Warnings and caution ...................2 2. Part names and functions ..................4 3. How to use the products ..................6 4.

  • Page 3: Warnings And Caution

    1. Warnings and caution Please follow the things described below in order to prevent any danger or property damage. Prohibition. Warning No disassembly It may cause a serious damage or injury if violated. No touch Caution Must follow strictly. Shows plugging out the power cord It may cause a minor damage or injury if violated.
  • Page 4 Warning If an abnormal sound, burning Please don’ t disassemble, Please don’t insert any Please use only the designated repair or rebuild this product smell or smoke is coming out metallic or burnable materials batteries for the products of arbitrarily (please contact the of the product, please plug out into the ventilation hole.

  • Page 5: Part Names And Functions

    2. Part names and functions Contents Contents Contents Micro SD Card MENU button Monitor [T-FLASH] slot SELECT Button Monitor button Open Door Button UP button Mike Talk Button DOWN button Interphone button External Connections Power switch Call Volume Speaker Tones Volume 1.
  • Page 6 ※ Caution • 2 Door cameras and 2 CCTV cameras • To avoid noise on the LCD , please keep Max. space among each video line of camerasTo avoid noise on the LCD, put 5 lines of UTP cable together and use it for GND when UTP[CAT.5] is used for door camera.

  • Page 7: How To Use The Products

    3. How to use the products •If you on of the power switch, it will be displayed COMMAX logo with ring sound. When the call came from the door camera (on time monitor 30±5sec) ① When you press the call button in the door camera, it will be displayed the visitors images and sound tones.
  • Page 8 - If not set CCTV mode - Camera 1  Camera 2  OFF  Camera 1 .... - If you press the monitor button, It will be process as below. - (If set CCTV mode) - Camera1  Camera2  CCTV 1  CCTV2  OFF  Camera1 .... If you connect call, CCTV is not case.

  • Page 9: Settings

    4. Settings • Products settings need the following 4 buttons Start Menu / Go Back : MENU Button (Monitor Button) When you enter the menu principal you should be used side menu. select / input : SELECT button (the button of open door) Back to top/Move right : △(UP button) (Interphone button) Move Down/Move left : ▽(DOWN button) (talk button) Screen set (Brightness/Contrast/Color adjustment function)
  • Page 10 RESET : initializing screen set How to set up ① In the configuration mode of 3-1, move to RESET icon with △/▽(Interphone button/Talk button). ② Press the SELECT(Unlocking button) button to choose an icon. ③ Select YES with △/▽(Interphone button/Talk button). ④...
  • Page 11 60seconds, click monitor button more than 1 second again to restart video saving. Managing folder and file ⇨ Making basic folder CDV-40QM\VIDEO\ ( Video storage folder ) CDV-40QM\PICTURE\ ( Capturing storage folder) ⇨ When the icon is displayed please built in data or backup.
  • Page 12 ⇨ The name of saved file and form 110516_130502_D1.jpg Still image 110516_130502_C2.jpg 110516_130502_D1.mp4 Video 110516_130502_L1.mp4 Explanation Date Time Video Type File Type 11/5/16 13hr5min2sec D1,D2 = Lobby 1,2 Still image (*.jpg) of file C1,C2 = CCTV 1,2 Video (*.mp4) ⇨ It is necessary memory or minimum space of Micro SD Card. Minimum space : Built in Flash –...
  • Page 13 ⇨ The number of saving for capacity Internal Flash Micro SDHC Card Capacity 100 MByte 4 GByte 8 GByte 16 GByte Stop Image The number of Video saving max 100 cuts max 400 cuts max 1,000 cuts max 1,000 cuts (60 Second) Video storage time 8 min...
  • Page 14 (1) Saving route and play/deletion of data (Video and (image/CAPTURE)) PLAY/ DELETE SELECTED FILE / DELETE ALL/ PREVIOUS PAGE How to set up ① In the configuration mode of 3-2, move to MEDIA icon and after press the SELECT (Unlocking button) button, move to relevant icon with △/▽(Interphone button/Talk button) ②...
  • Page 15 ③ Select the record (movie/still image) or not with △/▽(Interphone button/Talk button). ④ After choosing, complete the set with SELECT (Unlocking button) button. ⑤ After selecting record or not with △/▽(Interphone button/Talk button), complete the set by pressing SELECT (Unlocking button) button. (3) FORMAT (data format): format the capture data and movie saved in a product.
  • Page 16 UTILITY (1) LED DIMMING : Stand-by status of the product on ① No.1 mode : Call LED repeats bright status and dark status. ② No.2 mode : All LED change bright status to dark status repetitiously. ③ No.3 mode : In consecutive order from monitor button to Talk button, it changes bright status to dark status repetitiously.
  • Page 17 (2) CHIME-BELL MUTE : Setting mute sound. How to set up ① In the configuration mode of 3-2, move to UTILITY icon and after press the SELECT(Unlocking button)button, move to CHIME-BELL Mute icon with △/▽ (Interphone button/Talk button). ② Press the SELECT(Unlocking button) button to choose an icon. ③...
  • Page 18 (4) CCTV setting : Users can set CCTV on or off up to 2, if not activating, CCTV can not be connected. How to set up ① In the configuration mode of 3-2, move to UTILITY icon and after press the SELECT(Unlocking button) button, move to CCTV activation icon with △/▽...

  • Page 19: Installation

    5. Installation 1. Installation Method of camera monitor Note ① Avoid the range of direct sunlight ② Recommended height is pertinent from 1450 ~ 1500mm ③ Avoid the installation near magnetic activity, humid temperatures and gas 2. Installation Method of camera Note ①...

  • Page 20: Wiring

    6. Wiring For better picture quality, We recommend using 5 lines for GND if UTP CABLE[CAT.5] is used Camera connector polarity ① RED : Audio ② BLUE : GND ③ YELLOW : POWER(+12V) ④ WHITE : VIDEO CCTV CAMERA 1 CCTV CAMERA 2 Caution on the Wiring Be sure to use a separate wiring for each connect 2 UTP CABLE[CAT.5] are...
  • Page 21 DOOR Camera Wiring  If UTP CABLE[CAT.5] is used, use 5 lines for GND line. CCTV Camera Wiring  CCTV CAMERA requires additional power  Please choose the appropriate coaxial cable according to the distance #1 : RED--(Video) #2 : Blue-(GND) UTP CABLE Wiring.

  • Page 22: Parts List

    INTERPHONE WIRING  If UTP CABLE[CAT.5] is used, use 5 lines for GND line. 7. Parts list Monitor (CDV-40QM) Wall Bracket User Manual 본체 (CDV-43Q) 본체 (CDV-43Q) POWER CORD 480 장원형단 벽걸 이 브라 켓 본체 ( C DV-40Q) 본체 (CDV-43Q) 벽걸이브라켓...

  • Page 23: Specification

    1. Turn on the power switch. 2. Please contact your local agent for product maintenance when you have a problem in use of CDV-40QM 3. For your safety, power switch with a safety device must be used in your building.
  • Page 24 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com PM0740QM0011 Printed In Korea / 2011.10.104...
