Elko RF Touch Installation Manual

Control touch unit
Hide thumbs Also See for RF Touch:
Table of Contents

Advertisement

Quick Links

Download this manual
RF Touch
Control touch unit
INSTALLATION MANUAL
Switching
Lighting
Heating
dimming
HVAC
Blinds,
Detectors
Shutters
www.inels.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RF Touch and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Elko RF Touch

Summary of Contents for Elko RF Touch

  • Page 1 RF Touch Control touch unit INSTALLATION MANUAL Switching Lighting Heating dimming HVAC Blinds, Detectors Shutters www.inels.com...
  • Page 2 RF Touch user manual We want to thank you for your purchase of the RF Touch control unit, which is an component of the wireless RF Control system. RF Touch allows: • you to control many devices through the touch screen...

  • Page 3: Table Of Contents

    • Overview of wireless RF Control devices - Display • Technical parameters - Holiday, Change password, System • Characteristics of RF Touch - Block keyboard, View of menu • Installation - Temperature regulation, Main screen • • Basic Steps for Successful Programming Main menu •...

  • Page 4: Overview Of Wireless Rf Control Devices

    4 button keychain controller with converter converter converter display (2 inputs) (4 inputs) (230V) SYSTEM UNITS RF Touch-B RF Touch-W eLAN-RF-003 eLAN-RF-Wi-003 RFGSM-220M RFPM-2M RFRP-20 Wireless touch unit, Wireless touch unit, Smart RF box Smart RF box with Multifunctional GSM...
  • Page 5 SWITCHES LIGHTING RFSA-11B RFSA-61B RFSAI-61B RFSA-62B RFSA-61M RF-RGB-LED-550 RF-WHITE-LED-675 Wireless switch unit Wireless switch unit Wireless switch unit Wireless switch unit Wireless switch unit, Wireless coloured (single-function), (multi-function), with the input (fl ush mounted), 1 output and white bulb 1 output 1 output (for a pushbutton) 2 outputs...
  • Page 6 DIMMERS TEMPERATURE CONTROL RFDA-11B RFDA-71B RFDAC-71B RFDA-73M/RGB RFSTI-11/G RFSTI-11B RFTI-10B R-L-C dimmer* Analog controller Dimmer for coloured Switch unit with Switch unit with Wireless (single-function, 0(1)-10V (RGB) LED strips a temperature sensor a temperature sensor temperature sensor multi-function) (fl ush mounted) RFDEL-71B RFDSC-71 RFDEL-71M...
  • Page 7 MONITORING UNITS DETECTORS RFSF-1B RFTM-1 JA-80P JA-81M JA-82M Wireless fl ood Wireless pulse Wireless motion Wireless magnetic Wireless magnetic detector converter detector contact contact, Flush mounting ACCESSORIES AN-I AN-E TELVA FP-1 Internal antenna External antenna Thermodrive Temperature Temperature Flood probe Telva 230 V sensors sensors...

  • Page 8: Technical Parameters

    175 g Power supply connector: A1 – A2 Standards: EN 60730-1 Control * adapter is included for RF Touch-W Range up to: 100 m ** weight includes the plastic frame and the intermediate frame Minimal range RF Touch – actuator:...

  • Page 9: Characteristics Of Rf Touch

    RF Touch-B: fi ts in the round installation box with a supply voltage of 100—230 V AC • RF Touch-W: for surface mounting with power supply from the back side: 100—230 V AC or from the side (via jack): 12 V DC •...

  • Page 10: Installation

    Installation RF Touch-B RF Touch-W Power supply Power supply With Power Adapter A2 A1 100-230V AC • adapter included with RF Touch-W Mounting into the installation box Fitting on the surface Adhesive mounting...

  • Page 11: Basic Steps For Successful Programming

    3. Set menus (create names) Create a list of names of the controlled device in the Settings / ☺ Menu (create name). 4. Programming ☺ Programming of the RF units with RF Touch is carried out in the ☺ Settings / Programming menu.

  • Page 12: Description Of Control Icons

    Blinds time setting* 00:00 Detectors Quick control RF Touch, control, by short slight touch (a length of about 0.5—1 s) at the appropriate point. * Holding down on the arrows leads to the accelerated speed of change of numerals.
  • Page 13 Dimming Heating Switching Blinds temperature switch ON switch ON raise blinds switch OFF switch OFF lower blinds Saving mode dimming Normal mode impuls time setting* 00:02 00:02 light inclination button Party mode time function light declination Anti-freeze mode - delayed switch on - delayed switch off 0-10V confi...

  • Page 14: Basic Information

    21. 3. 2010 15:00 Sunday After power connection the RF Touch logo appears on the screen (fig. 1) After approximately 3 s the icon indicating the status of the component scan appears (fig. 2) On completion of the scan the default screen displays automatically.

  • Page 15: Date And Time

    Setting / Language Setting Language Český jazyk Language Selection of required Language (fig. 10—11). Date and time English Save setting by pressing Menu (create menu) Slovenčina Programming Język polski Display Magyar nyelv Holiday mode Limba romana fig. 10 fig. 11 Setting / Date and time Setting Date...

  • Page 16: Menu (Create Menu)

    Setting / Menu (create menu) / Add Menu Add (fig. 16) to show a selection of selections (fig. 17): Temperature regulation Press the Switching • Temperature regulation Dimming Edit • Blinds Switching Detectors • Remove Dimming Quick control • Blinds Add next •...

  • Page 17: Display

    Setting / Menu (create menu) / Remove Menu Remove Remove Remove button can delete unit name. Temperature regulation room 1 heater Switching room 2 heater Press the Remove icon (fig. 24) following menu appears, select Dimming room heater Edit the section from which you want to remove the name (fig. 25). Pick Blinds kitchen heating the device you want to delete by touching it (fig.

  • Page 18: Temperature Regulation

    Division of RF components and their function in programming RF Touch Temperature regulation Measures the temperature by using the Measures temperature with internal sensor Switch unit with internal relay. and can also control the while using the internal relay to control the...

  • Page 19: Switching

    Switching Component 1 output channel used to control The switched socket with 1 output channel Wireless appliances, sockets, lights and lighting is used to control fans, lamps, heaters Switching socket switch unit RFSA-11B RFSC-11 circuits. and appliances, which are connected by (single-function) (single-function) Single-function design −...

  • Page 20: Dimming

    Dimming This dimmer is used to regulate halogen light Dimmer for LED strips used for independent R-L-C dimmer RFDA-11B sources: R, L, C. control of one RGB LED strip. (single-function) Single-function - dimming, ON/OFF. Function RGB: RFDA-73M • colored light scenes This dimmer is used to regulate halogen light -RGB •...

  • Page 21: Blinds

    The flood detector immediately sends 24V DC gates, blinds, awnings, etc. for shutters RFSF-1B a signal to the RF Touch. Reacts instantaneous Contactless quiet switching. BLOCK to flooding, while flooding remains the programmed switching component remains Wireless closed until a button on the RFSF Prog-1B fl...
  • Page 22 Select the name of the actuator which you want to associate with receivers RFSTI-11/G KOMBI the RF Touch. Enter the address of actuator you want to assign − RFSTI-11G IN fig. 32 as indicated on the actuator (see page 11). Confi rm with From the menu you created, select the name to which the actuator fig.
  • Page 23 RF Touch. A single heating component Assigned Assigned Temperature regulation can be paired with up to 10 switches. room 1 heater RFTI-10B EXT Note: Assing room 2 heater • the attached actuator RFTI-10B can be used in two ways:...
  • Page 24 46). Select the name of the actuator which you want to associate receivers RFSC-61 with the RF Touch. Enter the address of actuator you want to assign RFUS-61 − fig. 47 as indicated on the actuator (see page 11). Confi rm with From the menu you created, select the name to which the actuator fig.
  • Page 25 − Enter the address of actuator you want to assign − fig. 61 (as indicated on the actuator, see page 11). Confi rm with − When programming the RF Touch unit the detector may not be battery powered. fig. 59 fig.
  • Page 26 Change of Address Pair with ... The above method can be used to assign additional detectors. Paired with ... The RF Touch can be programmed with up to 30 detectors. Note: the shortest distance to assign a detector is 1.5m). fig. 68...
  • Page 27 • Paired with... (fig. 74—75) Detectors Remove RFSOU-1 − This menu will lists switching actuators, which are paired with the Insert address Do you really detectors. By touching the name you can remove paired actuator. want to remove? Assing detector RFSOU-1 Note: •...
  • Page 28 Setting / Programming / Quick control / Assing new Programming Quick control Quick control Quick control is used for creating a group command, where one- Temperature regulation dreem light Assing Switching cinema scene touch control multiple actuators. Dimming kitchen For each name of group command you can assign a combination of Blinds first floor heater Assigned...
  • Page 29 (15 s, 30 s, 1 min, 3 min). • Sleep mode: set the time after which RF Touch screen unit goes to sleep - the screen goes dark (0 min, 10 min, 15 min, 20 min).
  • Page 30 Status Status Restore settings Done Touch units or the RF Touch and RFAF. First, press the Start button on Reset the device which is receiving the backup then press the Start button Factory default on the device from where the backup is being sent. You can interrupt during the data transfer by pressing Running...
  • Page 31 System • Factory default: Factory default: Enter the password 1234 confi rm Block keyboard View of menu command YES to return the RF Touch unit to factory settings Lock and Unlock is performed by double Temperature regulation (password can not be changed).
  • Page 32 500 VA 1000 VA 1500 VA 2000 VA settings are done in the RF Touch device, for a given heating circuit, to power which the device RFSTI-11/G is assigned. Off set in Off set is set directly on the RFTC-10/G unit.
  • Page 33 AUTO mode. Saving Normal Party mode The required temperature may be set manually on the RFTC-10/G unit. This adjustment is valid until the subsequent change of the Anti-freeze mode heating programme in RF Touch.
  • Page 34 Daily overview 00:00 - 06:30 Weekly overview Weekly overview are paired to one switching actuator through RF Touch unit, the RF Touch 06:30 - 07:30 sends the command "to turn off the heating ” after the desired temperature 06:30 07:30...
  • Page 35 temperatures for the entire week. kitchen heating kitchen heating Touch-hour time interval (or minutes) to indicate the information you want to change. Arrows set time for switching − On and 18.00 °C − Off . Arrows can adjust desired temperature. 25.50 °C 20.00 °C Touch of Mo-Sun activate the schedule for desired day of the week.
  • Page 36 Quick control for information only and may be infl uenced by the amount of information processed or combining multiple control units RF Touch and RF Pilot. fig. 133 RFSFH-1 can not be manually operated, it is designed to be paired with temperature control components.
  • Page 37 In the section Setting time all times for Delay on and Delay off . Time hall light delay can be set in the range from 2s to 60 minutes. Touch-hour time interval (or minutes) to indicate the information you want Delay 00:00 then change (fig.
  • Page 38 Note: Graphical representation of the contact / devices (Green -on, Red -off ) is for information only and may be infl uenced by the amount of information processed or combining multiple control units RF Touch and RF Pilot. fig. 149...
  • Page 39 Touch the desired name to displays basic functions*: room lamp 1 room lamp 1 room lamp1 Switch on • Switch off • Switch on Switch off Switch on Switch off Dimming Dimming • Dimming − A short touch on the arrows beside icon Dim up Dim down...
  • Page 40 • Settings RFDA-73M-RGB and RF-RGB-LED-550 Main menu The Dimming menu (fig. 155) in the displayed list, select the name Temperature regulation to which you have paired components RFDA-73M-RGB or RF-RGB- Switching LED-550 (fig. 156). Dimming Touch the required name, it will be displayed (fig. 157): Blinds •...
  • Page 41 Note: Graphical display of device status (green − closed blinds, red – open blinds) it is only for information and may be infl uenced by the amount of information processed or combining multiple control RF Touch and RF Pilot fig. 162 fig.
  • Page 42 The time set for Up / Down can not be less than the measured time window kitchen window kitchen “t” + 2s longer than 4 minutes. The adjusted time for Up and Down may vary. Daily overview Daily overview Weekly overview Weekly overview Up / Down can control the devices in the...
  • Page 43 • Detectors OASIS − Double State (JA-81M - doors; JA-82M − Detectors garage lighting windows) There is a graphic display of the contact* (green − on, red − off ). terrace doors By on-state (calm) window room lighting Switch off Detectors may be used in two ways: garage Delay off...
  • Page 44 Do not expose to extreme temperature changes. In case of extreme temperature changes allow approx. 2 hours prior to installation for the RF Touch to adjust to the temperature of the installation location. This will prevent condensation of moisture in the device and the occurrence of a potential short circuit.

  • Page 45: Quick Control

    RF Touch Unit Warnings Warning is displayed in case of incorrect or incomplete entry. Warning Procedure In each group (temperature control, switching, dimming, blinds) the na- It is possible to defi ne a maximum 40 rooms. mes of up to 40 rooms can be entered The same room has already been included in this group.
  • Page 46 Warning Procedure To pair with the unit only 6x actuator series can be selected. Pair only with multifunction switch To pair with the detector only 6x actuator series can be selected. Pair only with multifunction switch Time, switch ON , cannot be set later than , Time, switch OFF! Enter new settings It was not selected day! Enter new settings...

  • Page 47: Installation From

    Installation from Serial Description / Actuator Actuator Serial Description / Actuator Actuator name of the controlled device name address name of the controlled device name address...
  • Page 48 ELKO EP, s. r. o. Palackého 493 | 769 01 Holešov – Všetuly | Czech Republic phone.: +420 573 514 211 | e-mail: elko@elkoep.com | www.elkoep.com 02-93/2016 rev.3...
