Summary of Contents for Elko iNELS VIA RF TOUCH
- Page 1 HEATING WITH SAVINGS WIRELESS KIT TO CONTROL HEATING VIA RF TOUCH UNIT PERFECT TEMPERATURE IN EACH ROOM WITHOUT THE UNNECESSARY EXPENSE. www.inels.com/kits User´s manual 2.0...
- Page 2 HEATING WITH SAVINGS HEATING CONTROL VIA WIRELESS TOUCH UNIT Includes 3 wireless thermovalves that are installed instead the stan- dard radiator valves. They measures the room temperature and send it to the RF Touch control unit. RF TOUCH compares it with the tempe- rature set along with time schedule and sends a command to open or close the valve.
-
Page 3: Table Of Contents
USER´S MANUAL CONTENT KIT CONTENT Kit content ............................................WIRELESS How does it work? ........................................THERMOVALVE The range of RF signal ......................................3× Installing a wireless thermovalve ................................RFATV-1 Installing a wireless touch unit ..................................Default screen ........................................... Settings ............................................. Wireless thermovalve measures the room temperature and sends it to the Heating modes ......................................... -
Page 4: How Does It Work
HOW DOES IT WORK? THE RANGE OF RF SIGNAL Wireless thermovalve measures the room temperature and based on the value set in The range of RF signal is up to 200 m in the free open air. wireless touch unit it sends a command to open/close a thermovalve. TRANSMISSION OF RADIOFREQUENCY SIGNALS IN VARIOUS MATERIALS Each wireless unit is numbered 1,2,3, it corresponds to the name in Wireless touch unit (Heating 1, Heating 2, Heating 3). -
Page 5: Installing A Wireless Touch Unit
INSTALLING A WIRELESS THERMOVALVE INSTALLING A WIRELESS TOUCH UNIT Power supply Surface mounting Power supply via terminals 1. Open battery cover 2. Insert batteries (keep in mind the polarity) 3. Close the cover -> your RFATV-1 is ready to install Mounting Wireless thermovalve can be quickly and easily mounted on all common valves. -
Page 6: Settings
THE DEFAULT SCREEN SETTINGS Setting the clock Date and time Touch the icon in the upper-right corner of the screen and enter a password (default settings - 1111). Touch the top right corner to select the type of clock to display on the screen. An ANALOG (Fig. 2) or DIGITAL (Fig. -
Page 7: Temperature Adjustment
HEATING MODE TEMPERATURE ADJUSTMENT To change the temperature in the heating circuit, click the button Settings (Fig. 3) and then click on The menu Temperature regulation (Fig. 1) is used to control and set the heating mode. Touch on Temperature regulation and then you will see the list of Heating Circuits (Fig. - Page 8 TIME PROGRAM ADDITIONAL SETTINGS Holiday mode Click the Settings and then click on for the chosen Heating circuit (Fig.1, Fig.2). You can change a time AUTO by touching on the time interval (hours/minuts). Using the arrow keys you will set the ON time and Holiday mode is used for temporary interruption of the heating program.
- Page 9 ADDITIONAL SETTINGS ADDITIONAL SETTINGS Edit title of heating circuit Open window detection The function of Open window detection (Fig.4) monitors the sharp temperature drop and close Wireless Click on the „Settings“ and then on the „Menu“ (create a title) to edit the title of the heating circuit thermovalve to a preset time.
- Page 10 ADDITIONAL SETTINGS ADDITIONAL SETTINGS Others Pairing / removing Wireless thermovalves Fig. 1 Fig. 1 Fig. 2 Fig. 2 Click on the Setting / Others and other settings of Used to pair wireless thermovalves with switching unit, that controls the heating source (mainly boiler). Wireless touch unit will displayed.
- Page 11 ADDITIONAL SETTINGS ADDITIONAL SETTINGS Indication of a low-battery condition of Wireless thermovalve Change password Low battery indicator of Wireless thermovalve appears on the screen (Fig.1). Press the battery to Change Password (PROG.): used to change a password which allows you to go to a programming display the unit name.
- Page 12 ASSIGN OTHER UNITS ASSIGN OTHER UNITS Menu (create names) Click on the Add/Assing new (Fig. 3). A list of units from selected section will be shown (Fig. 4). Click and select the actuator which you want to assign to Wireless RF Touch. Enter the address of actuator Fig.
-
Page 13: Technical Parameters Of Rfatv-1
TECHNICAL PARAMETERS TECHNICAL PARAMETERS RFATV-1 RF TOUCH Display Supply voltage: 2 x 1,5V batteries Battery life: 1 year Type: color TFT LCD Resolution: 320 x 240 pixels / 262 144 colors Control Frequency: 868 MHz Side proportion: RF command from the transmitter: Visible surface: 52.5 x 70 mm RF Touch... -
Page 14: Other Rf Units
OTHER OTHER RF UNITS RF UNITS CONTROLLER SWITCHES PICTURE DEVICE DESCRIPTION PICTURE DEVICE DESCRIPTION TYPE/CODE TYPE/CODE WIRELESS SWITCH UNIT - 6 OUTPUTS WIRELESS WALL CONTROLLER RFSA-66M RFWB-20/G 6-channel switching actuator intended to be installed in the swit- Each of the 2 independent push-buttons can control any chboard contains 6 independent 8A contacts, that can switch any number of wireless units (switches, dimmers, shutters). - Page 15 OTHER OTHER RF UNITS RF UNITS LIGHTING TEMPERATURE CONTROL PICTURE DEVICE DESCRIPTION TYPE/CODE PICTURE DEVICE DESCRIPTION TYPE/CODE WIRELESS TEMPERATURE SENSOR RFTI-10B COLOURED RGB LED STRIP, 5 METERS 7,2W, RGB, 30LED/M Internal or external sensor measures the temperature starting Coloured RGB strip, 7.2W/m (30 LED chips / m), length 5 m, width from -20 up to 50°C.
-
Page 16: Overview Of Other Kits
THE OVERVIEW OF OTHER KITS THE OVERVIEW OF OTHER KITS THE GAME OF LIGHTS ORDER CODE: 5159 EASY HEAT REGULATION ORDER CODE: 5160 SMART RF 1× TEMPERATURE × CONTROLLER COLORED WIRELESS SWITCHING 3× × BULB SOCKET KIT TO CONTROL LIGHTS VIA SMARTPHONE KIT FOR WIRELESS TEMPERATURE REGULATION IN THE HOME This kit enables convenient and quick control of heater, oil heater, panel heater or portable air It has never been easier to set the appropriate ambience for reading a book, watching a movie... -
Page 17: Virtual Kits
THE OVERVIEW OF OTHER KITS VIRTUAL KITS The virtual kit is a set of wireless units that are packed individually (as an individual product), but on the other hand they are preset together (they are meant to work together) to ensure simple installa- ONE CONTROLLER FOR ALL ORDER CODE: 5163 tion. - Page 18 NOTIFICATION AND THEIR SOLUTIONS NOTIFICATION AND THEIR SOLUTIONS RF TOUCH UNIT NOTIFICATIONS Notification is displayed in case of incomplete, inaccurate or incorrect entry information. Upozornění Notifi cation Postup Procedure Procedure Notifi cation Switch-ON date may not be the same as the New settings required.
- Page 19 Manufacturer: ELKO EP, Ltd. / Palackeho 493 Holešov - Všetuly 769 01 / Czech Republic phone: +420 800 100 671 / e-mail: elko@elkoep.com www.elkoep.com...
