Please read this instructions before operating the device and retain them for future reference.
19"/ 27.6"/ 28.6"/ 38"
Chassis Panel PC
Intel® Celeron® Bay Trail-M N2930 1.83 GHz
User Manual
Bar-Type
W19IB3S-CHA1
W27IB3S-CHC1
W28IB3S-CHA2
W38IB3S-CHA1
V1.1
Advertisement
Table of Contents
Related Manuals for Winmate W19IB3S-CHA1
Summary of Contents for Winmate W19IB3S-CHA1
- Page 1 Intel® Celeron® Bay Trail-M N2930 1.83 GHz W19IB3S-CHA1 W27IB3S-CHC1 W28IB3S-CHA2 W38IB3S-CHA1 User Manual V1.1 For more information on this and other Winmate products, please visit our website at: www.winmate.com Please read this instructions before operating the device and retain them for future reference.
-
Page 2: Table Of Contents
USER MANUAL CONTENTS Document Part Number: 9152111I101L CONTENTS PREFACE ......................- 4 - ABOUT THIS USER MANUAL ................ - 11 - CHAPTER 1: INTRODUCTION ................ - 13 - 1.1 Product Features ................- 13 - 1.2 Package Content ................- 14 - 1.3 Schematics and Dimensions ............ - Page 3 USER MANUAL CONTENTS 3.1 Operating System ................- 33 - 3.2 Multi-Touch for Windows ..............- 34 - 3.3 How to Enable Watchdog ..............- 35 - CHAPTER 4: AMI UEFI BIOS SETUP ............. - 38 - 4.1 When and How to Use BIOS Setup ..........- 38 - 4.2 BIOS Functions ................
-
Page 4: Preface
USER MANUAL PREFACE PREFACE Copyright Notice No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer. Trademark Acknowledgement Brand and product names are trademarks or registered trademarks of their respective owners. - Page 5 USER MANUAL PREFACE Customer Service We provide a service guide for any problem by the following steps: First, visit the website of our distributor to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance.
- Page 6 USER MANUAL PREFACE Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. The following is an example of each type of advisory.
-
Page 7: Safety Information
USER MANUAL PREFACE Safety Information WARNING! / AVERTISSEMENT! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. - Page 8 USER MANUAL PREFACE Safety Precautions For your safety carefully read all the safety instructions before using the device. Keep this user manual for future reference. Always disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth.
- Page 9 USER MANUAL PREFACE CAUTION/ATTENTION Use the recommended mounting apparatus to avoid risk of injury. Utiliser l’appareil de fixation recommandé pour éliminer le risque de blessure. WARNING! / AVERTISSEMENT! Only use the connection cords that come with the product. When in doubt, please contact the manufacturer. Utiliser seulement les cordons d’alimentation fournis avec le produit.
-
Page 10: Important Information
USER MANUAL PREFACE Important Information Federal Communications Commission Radio Frequency Interface Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received including ... -
Page 11: About This User Manual
ABOUT THIS USER MANUAL This User Manual provides information about using the Winmate® Bar-Type Panel PC. This User Manual applies to Bar-Type Panel PC W19IB3S-CHA1, W27IB3S-CHC1, W28IB3S-CHA2 and W38IB3S-CHA1. The documentation set for the Bar-Type Panel PC with Intel® Celeron® Bay Trail-M N2930 1.83 GHz provides information for specific user needs, and... -
Page 12: Chapter 1: Introduction
USER MANUAL PREFACE INTRODUCTION This chapter gives you product overview, describes features and hardware specification. You will find all accessories that come with the panel PC in the packing list. Mechanical dimensions and drawings included in this chapter. - 12 -... -
Page 13: Product Features
Intel® Celeron® Bay Trail-M N2930 processor and capable of running demanding signage and multimedia applications. Depending on different applications, Winmate® Bar-Type can be used in both horizontal and vertical installation to show different content with one single image or split screens in different places. Bar-Type can be a perfect choice to replace traditional LED digital signage for applications where the space is limited such as public transportation, elevators and other public places. -
Page 14: Package Content
USER MANUAL CHAPTER 1 IINTRODUCTION 1.2 Package Content Carefully remove the box and unpack your device. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately. Standard factory shipment list: User Manual Bar-Type Panel PC... -
Page 15: Schematics And Dimensions
USER MANUAL CHAPTER 1 IINTRODUCTION 1.3 Schematics and Dimensions This section describes mechanical dimensions of Bar-Type Panel PC. Notice that this is a simplified drawing and some components are not marked in detail. Please contact our sales representative if you need further product information. 1.3.1 Schematics and Dimensions 19”... -
Page 16: Schematics And Dimensions 27.6
USER MANUAL CHAPTER 1 IINTRODUCTION 1.3.2 Schematics and Dimensions 27.6” No Description Description ① ⑤ Power On button USB 3.0 x 1, USB 2.0 x 1 ② ⑥ Reset Button HDMI 1.4a x 1 9-36V DC Terminal Block ③ ⑦ RJ-45 (LAN) x 2 (Phoenix Type) ④... -
Page 17: Schematics And Dimensions 28.6
USER MANUAL CHAPTER 1 IINTRODUCTION 1.3.3 Schematics and Dimensions 28.6” Unit: mm No Description Description ① ⑤ Power On button USB 3.0 x 1, USB 2.0 x 1 ② ⑥ Reset Button HDMI 1.4a x 1 9-36V DC Terminal Block ③... -
Page 18: Schematics And Dimensions 38
USER MANUAL CHAPTER 1 IINTRODUCTION 1.3.4 Schematics and Dimensions 38” Unit: mm No Description Description ① ⑤ Power On button USB 3.0 x 1, USB 2.0 x 1 ② ⑥ Reset Button HDMI 1.4a x 1 9-36V DC Terminal Block ③... -
Page 19: Phycical Buttons And Led Indicators
USER MANUAL CHAPTER 1 IINTRODUCTION 1.4 Phycical Buttons and LED Indicators OSD Panel is located on the rear side of the Panel PC. Physical Buttons Icon Button Description Reset Press to reset the system Power On/ Off Press to power on or power off the device LED Indicators Icon LED Indicator... -
Page 20: Chapter 2: Installation
USER MANUAL CHAPTER 2 INSTALLATION INSTALLATION This chapter provides hardware installation instructions and mounting guide for all available mounting options. Pay attention to cautions and warning to avoid any damages. -
Page 21: Safety Precautions
USER MANUAL CHAPTER 2 INSTALLATION CHAPTER 2: INSTALLATION This chapter provides information on how to connect the Panel PC to the source of power, connector pinouts and the guideline to turn on/off the device. 2.1 Safety Precautions Observe the following common safety precautions before installing any electronic device: •... -
Page 22: Vesa Mounting Guide
USER MANUAL CHAPTER 2 INSTALLATION 2.3 VESA Mounting Guide Bar-Type Panel PC supports VESA Mount suitable for most of the industrial and commercial applications. The device supports flexible mounting in both horizontal and vertical installations. Refer to sub-sections below for more details. CAUTION/ ATTENTION Follow mounting instructions and use recommended mounting hardware to avoid the risk of injury. -
Page 23: Powering On
USER MANUAL CHAPTER 2 INSTALLATION 2.4 Powering On 2.1.1 AC Adapter Components 3 Pin Terminal Block to Power Cord AC Adapter DC Jack Safety Precautions: Do not use the adapter in a high moisture environment Never touch the adapter with wet hands or foot ... -
Page 24: Power Considerations
USER MANUAL CHAPTER 2 INSTALLATION ALTERNATING CURRENT / MISE À LE TERRE! This product must be grounded. Use only a grounded AC outlet. Install the additional PE ground wire if the local installation regulations require it. *If you do not use a grounded outlet while using the device, you may notice an electrical tingling sensation when the palms of your hands touch the device. -
Page 25: Connecting The Power
USER MANUAL CHAPTER 2 INSTALLATION 2.1.3 Connecting the Power Bar-Type Panel PC operates on external power. Follow the instructions below to connect the device to the source of power. To connect the Panel PC to the source of power: Connect a 3-pin terminal block to the connector on the Panel PC. Connect the other side of the terminal block to the AC adapter. -
Page 26: Connector Pinouts
USER MANUAL CHAPTER 2 INSTALLATION 2.5 Connector Pinouts 2.2.1 DC Input Connector The Bar-Type Panel PC uses 3-pin terminal block connector that accepts 9-36V DC power input. The connector secured to the enclosure with two screws. Minimum Voltage 9.0V Maximum Voltage 36V Maximum Current 4.2A Voltage 2.2.2 Serial Port Connector... - Page 27 USER MANUAL CHAPTER 2 INSTALLATION 2.2.3 Serial Port Connector The Bar-Type Panel PC uses D-SUB 9pin connector to connect serial interfaces. The connector secured to the enclosure with two screws. RS232 Pin № RS-232 RS232/422/485 Pin № RS-232 RS-422 RS-485 TxD- TxD+ RxD+...
-
Page 28: Usb Connector
USER MANUAL CHAPTER 2 INSTALLATION 2.2.3 USB Connector USB 2.0 and USB 3.0 Connector The Bar-Type Panel PC has one USB2.0 Type A and one USB 3.0 connectors. Use USB connectors to connect external devices such as mouse or keyboard to the Panel PC. -
Page 29: Hdmi Connector
USER MANUAL CHAPTER 2 INSTALLATION 2.2.7 HDMI Connector The Bar-Type Panel PC has one HDMI 1.4a connector. Use HDMI cable to connect the display to the PC system. Pin № Signal Name Signal Name № TMDS_DATA2+ TMDS_DATA2- TMDS_DATA1+ TMDS_DATA1- TMDS_DATA0+ TMDS_DATA0- TMDS_CLOCK+ TMDS_CLOCK-... -
Page 30: Turning On And Off
USER MANUAL CHAPTER 2 INSTALLATION 2.6 Turning On and Off This section describes how to turn on / off the Panel PC. To turn on the Panel PC: 1. Connect the device to the source of power 2. The unit is configured to Power ON when is connected to the power source. -
Page 31: Configuring Serial Port Settings
USER MANUAL CHAPTER 2 INSTALLATION 2.7 Configuring Serial Port Settings Jumpers are located on the motherboard. It is required to open the unit to access the jumpers. Follow instructions in this section to configure serial port settings. A pair of needle nose pliers may be helpful when working with jumpers. -
Page 32: Chapter 3: Operating The Device
USER MANUAL CHAPTER 3 OPERATING THE DEVICE OPERATING THE DEVICE This chapter provides detailed information on how to operate the device. If you have been using touch-screen Panel PCs before, the interface may look familiar. Sections include system settings parameters. - 32 -... -
Page 33: Operating System
USER MANUAL CHAPTER 3 OPERATING THE DEVICE CHAPTER 3: OPERATING THE DEVICE In this chapter you will find instructions on how to operate the Panel PC with Hot Tab. 3.1 Operating System Flat Stainless P-CAP Panel PC support several versions of Windows OS: Windows 10 IoT Enterprise, Windows Embedded 8.1 Industry Pro, Windows Embedded 8 Standard, Windows 7 Pro for Embedded Systems, and Windows Embedded Standard 7 –... -
Page 34: Multi-Touch For Windows
USER MANUAL CHAPTER 3 OPERATING THE DEVICE 3.2 Multi-Touch for Windows The touchpad supports the core gestures for Windows. Gesture Windows Gesture Action Action Usage Tap/ Click / Click or double- Double-tap Double-click click Panning Scrolling Drag one or two with Inertia fingers up and down... -
Page 35: How To Enable Watchdog
CHAPTER 3 OPERATING THE DEVICE 3.3 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download Ch.7, “Technical from Winmate Download Center or File Share. Refer to the Support”... - Page 36 USER MANUAL CHAPTER 3 OPERATING THE DEVICE Settings Description The system automaticity restarts when this Watchdog countdown time reaches zero. Countdown Time Default: 10 min To set a cycle time to automatically reset watchdog Periodically Feed timer. Time Default: 9 min Enable or disable watchdog.
-
Page 37: Chapter 4: Ami Uefi Bios Setup
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP AMI UEFI BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. -
Page 38: When And How To Use Bios Setup
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP CHAPTER 4: AMI UEFI BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. 4.1 When and How to Use BIOS Setup To enter the BIOS setup, you need to connect an external USB keyboard, press <Del>... - Page 39 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP The following Keys can be used after entering the BIOS Setup. Function General Help Previous Values Optimized Defaults Save & Exit Exit Change Opt. Enter Select or execute command Cursor ↑ Moves to the previous item Cursor ↓...
-
Page 40: Main Menu
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.1 Main Menu When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date. Immediately after the [DEL] key is pressed during startup, the main BIOS setup menu appears: BIOS Setting... -
Page 41: Advanced Menu
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2 Advanced Menu The advanced menu also uses to set configuration of the CPU and other system devices. There are sub menus on the left frame of the screen. IMPORTANT: Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer. - Page 42 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP BIOS Setting Description Setting Option Effect ACPI Settings Configures ACPI Enter Opens submenu settings F81866 Super IO Configures IO Enter Opens submenu Configuration settings Hardware Monitor Configures Enter Opens submenu Hardware Monitor settings S5 RTC Wake Configures RTC...
- Page 43 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.1 ACPI Settings Advanced Configuration and Power Interface (ACPI) settings allow to control how the power switch operates. The power supply can be adjusted for power requirements. You can use the screen to select options of ACPI configuration. A description of the selected items will appear on the right side of the screen.
- Page 44 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.2 F81866 Super IO Configuration You can use the screen to select options for Super IO Configuration, and change the value of the option selected. A description of the selected item appears on the right side of the screen.
- Page 45 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.2.3 GPI0 Port Configuration You can use the screen to change GPI0 Port setting. Use these items to set parameters related to PIN3-PIN14 Control. 4.2.2.3 Hardware Monitor You can check PC Health Status parameters such as system temperature, fan speed etc.
- Page 46 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.4 S5 RTC Wake Settings Wake system from S5 enables or disables system wake on alarm event. It allows you to wake up the system in a certain time. 4.2.2.4.1 Wake System from S5 with fixed time setting Select Fixed Time to set the system to wake on the specified time.
- Page 47 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.4.2 Wake system from S5 after dynamic time setting Select Dynamic Time to set the system to wake on the current time + increase minute (s). - 47 -...
- Page 48 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.5 CPU Configuration BIOS Setting Description Setting Option Effect Socket CPU This item contains Enter Open sub-menu Information socket specific CPU information. CPU Thermal Thermal control Enter Open sub-menu Configuration Limit CPUID Limits CPIID Disabled/Enabled Enable/Disable...
- Page 49 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.6 PPM Configuration BIOS Setting Description Setting Option Effect CPU C State Shows CPU C Enabled/ Enable or Disable Report State Report Disabled CPU C state report to OS Max CPU C- Allows to enter C1E, C3, C6, C7, Enable or Disable...
- Page 50 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.7 Thermal Configuration This menu allows controlling thermal settings of the computer. Refer to the descriptions on the top right side of the screen for detailed information about each setting. BIOS Setting Description Setting Option Effect...
- Page 51 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.8 IDE Configuration BIOS Setting Description Setting Option Effect Serial- ATA Responsible for Enabled/ Enable or (SATA) supporting chipset Disabled disable this drives with SATA function interface. SATA Speed Allows forcing the Gen1 The maximum Support...
- Page 52 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP SATA Mode This option [AHCI] Selecting this specifies the option allows operation mode of you to take full modern IDE / advantage of SATA-controller the extended chipset host controller SATA II [IDE] SATA controller will operate in a mechanism...
- Page 53 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.9 Miscellaneous Configuration 4.2.2.9.1 OS Selection This item allows users to select the proper Operating System. BIOS Setting Description Setting Option Effect Windows 8.X Allows user to Enter Use Windows choose the proper OS.
- Page 54 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.10 CSM Configuration - 54 -...
- Page 55 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP BIOS Setting Description Setting Effect Option CSM Support The Compatibility Enabled/ Enable or disable Support Module (CSM) Disabled the Compatibility is a component of the Support Module UEFI firmware that provides legacy BIOS compatibility by emulating a BIOS environment, allowing...
- Page 56 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.11 USB Configuration BIOS Setting Description Setting Option Effect Legacy USB User can enable Disable Will keep USB Support or disable USB devices port. available only for EFI applications. Enable Enable all the USB devices USB 3.0 User can enable...
- Page 58 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP XHCI Hand‐ off This is a Disable Disables this workaround for function OSs without XHCI Enable Enables this hand‐ off support. function EHCI Hand‐ off This is a Disable Disables this workaround for function OSs without ECHI Enable...
- Page 59 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.12 Platform Trust Technology BIOS Setting Description Setting Option Effect fTPM Trusted Platform Enabled/Disabled Enables or Module disables this parameters function - 59 -...
- Page 60 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.2.13 Security Configuration BIOS Setting Description Setting Option Effect Trusted Execution Enabled/Disabled Enables or Technology disables this parameters function TXE HMRFPO TXE HMRFPO Enabled/Disabled Enables or parameters disables this function TXE Firmware TXE Firmware Enabled/Disabled Enables or...
-
Page 61: Chipset Menu
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.3 Chipset Menu For items marked with ►, please press <Enter> for more options. BIOS Setting Description Setting Option Effect High Precious Allow to set up Enabled/ Enables/Disables Timer High Precious Disabled this function Timer settings Restore AC... -
Page 62: Security Menu
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.4 Security Menu In the Security menu, users can set administrator password, user password, and HDD security configuration. BIOS Setting Description Setting Option Effect Administrator Displays Enter Enter password Password whether or not an administrator password has been set. -
Page 63: Boot Configuration
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.5 Boot Configuration The Boot menu sets the sequence of the devices to be searched for the operating system. The bootable devices will be automatically detected during POST and shown here, allowing you to set the sequence that the BIOS uses to look for a boot device from which to load the operating system. - Page 64 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP Fast Boot Enables or Disabled Disables this disables Fast function Boot to shorten Enabled Enables this the OS boot function process. (Default: Disabled). Boot Mode Select Specifies which Legacy Only Legacy mode will be used option is booted for booting UEFI...
-
Page 65: Save & Exit
USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP 4.2.6 Save & Exit The Exit menu displays a way how to exit BIOS Setup utility. After finishing your settings, you must save and exit for changes to be applied. BIOS Setting Description Setting Option Effect... - Page 66 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP Discard Changes Reset system Enter <YES> Saves the and Reset setup without changes saving any Enter <NO> Return to the changes BIOS Setup Main Menu Save Changes Save changes Enter <YES> Saves the done so far to any changes of the setup...
-
Page 67: Using Recovery Wizard To Restore Computer
User Manual Chapter 4 Software Installation 4.3 Using Recovery Wizard to Restore Computer Note: Before starting the recovery process, make sure to backup all user data. The data will be lost after the recovery process. To enable quick one-key recovery procedure: ... - Page 68 USER MANUAL CHAPTER 4 AMI UEFI BIOS SETUP Wait the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process complete. The system will restart automatically after recovery completed. - 68 -...
-
Page 69: Chapter 5: Driver Installation
USER MANUAL CHAPTER 5 DRIVER INSTALLATION DRIVER INSTALLATION This chapter describes how to install all necessary drivers. - 69 -... -
Page 70: Chipset Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION CHAPTER 5: DRIVER INSTALLATION This chapter provides guideline to driver installations. 5.1 Chipset Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Chipset Driver” and click “infinst_auto.exe” to install driver. Step 2 Click Next to continue. - Page 71 USER MANUAL CHAPTER 5 DRIVER INSTALLATION Step 3 Click Yes to agree the license terms. Step 4 Click Next to install the driver. Step 5 Software setup progress window will appear, click Next to continue. Step 6 Click “Yes, I want to restart this computer now” to finish the installation. - 71 -...
-
Page 72: Graphics Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.2 Graphics Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “Graphics Driver” and click Setup to execute the setup. Step 2 Setup Welcome Window will appear, click Next to continue the process. Step 3 Carefully read the license terms and click Yes to agree. -
Page 73: Intel Sideband Fabric Device (Intel Mbi) Driver (Windows 8)
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.3 Intel Sideband Fabric Device (Intel MBI) Driver (Windows 8) Step 1 Insert the CD that comes with the motherboard. Open the file document “MBI” and click “Setup.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 74: Intel Trusted Engine Interface (Intel Txe) Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.4 Intel Trusted Engine Interface (Intel TXE) Driver Step 1 Insert the CD that comes with the motherboard. Open the file document “TXE” and click “Setup TXE.exe” to install the driver. Step 2 Welcome to the setup program window will appear, click Next to start the installation. -
Page 75: Intel Network Connections
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.5 Intel Network Connections User must confirm the type of operating system is being used before installing Intel Network Connections. Follow the steps below to complete the installation. Step 1 Click “PROWin64.exe” Step 2 Click Yes to start the installation. Step 3 Welcome window will appear, click Next to install the driver. -
Page 76: Audio Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.6 Audio Driver The ALC886 series are high-performance 7.1+2 channel high definition audio codecs that provide ten DAC channels for simultaneous support of 7.1 sound playback, plus 2 channels of independent stereo sound output (multiple streaming) through the front panel stereo outputs. -
Page 77: Usb 3.0 Driver (Windows 7)
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.7 USB 3.0 Driver (Windows 7) NOTE: If your operation system is Windows Embedded 8.1 Industry or Windows Embedded 8 Standard, you should skip the USB 3.0 driver installation. This Panel PC features Intel Celeron Bay Trail-M N2930CPU with the Intel® USB 3.0 extensible Host Controller. -
Page 78: Watchdog Driver
USER MANUAL CHAPTER 5 DRIVER INSTALLATION 5.8 Watchdog Driver For more details about Winmate Watchdog, please download Watchdog Guide from Winmate Downloads Center: http://dc.winmate.com.tw/_downloadCenter/2017/Embedded%20Computing/Watch dog%20Guide_IB_IH_IV_IK.pdf Follow instructions below to install Watchdog driver. 1. Open the Driver CD (included in the package) and select Watchdog driver. -
Page 79: Chapter 6: Technical Support
USER MANUAL CHAPTER 6 TECHNICAL SUPPORT TECHNICAL SUPPORT This chapter includes the directory for technical support. - 79 -... -
Page 80: Introduction
Utility Watchdog Utility To find the Drivers and SDK, please refer to the Driver CD that comes in the package or contact us. Also, you can download drivers from Winmate Download Center or Winmate File Share. Winmate Download Center Go to http://www.winmate.com/... -
Page 81: Product Specifications
USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS Product Specifications This section includes product specifications. Appendix - 81 -... -
Page 82: Appendix A: Product Specifications
USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS APPENDIX A: PRODUCT SPECIFICATIONS Model Name W19IB3S-CHA1 W27IB3S-CHC1 W28IB3S-CHA2 W38IB3S-CHA1 Display 19” 27.6” 28.6” 38” Size/ Type Resolution 1680x342 1920×360 1920 x 540 1920 x 540 Brightness 300 nits 1000 nits 1000 nits 1000 nits Contrast 2000:1 (typ.) - Page 83 USER MANUAL APPENDIX A PRODUCT SPECIFICATIONS Software Support – Drivers Item Driver Windows 7 Windows 8 Windows Chipset Driver ☑ ☑ ☑ Graphics Driver ☑ ☑ ☑ Audio Driver ☑ ☑ ☑ Ethernet Driver ☒ ☑ ☑ Intel MBI Driver ☒...
- Page 84 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C Tel: 886-2-8511-0288 Fax: 886-2-8511-0211 Email: sales@winmate.com.tw Official website: www.winmate.com...
