6 EXACT IDIP
YOUR NEW EXACT IDIP
AND MAINTAINING DRINKING WATER, POOLS, SPAS, PONDS,
AQUARIUMS, FOOD PROCESS WATER, ENVIRONMENTAL
WATERS, BREWING, AND MORE!
SAMPLE CELL - 4 ML
Built-in plastic 4mL cell
for collecting your water
sample
BLUETOOTH
CONNECTED
LCD DISPLAY
LOW RESULT
BATTERY UNITS
BASE
Install/replace batteries here
(IP67 rated waterproof)
Part no. 486101
INSTALL "AAA" BATTERIES (NOT INCLUDED)
1. Use a #4 Phillips head screwdriver to remove the screw from
the base of your eXact iDip
2. Remove the base.
3. Install Four (4) new AAA batteries as illustrated inside your
iDip's battery compartment. We recommend using high
quality batteries.
4. Replace the base fi rmly with pressure while tightening the
screw. The meter will turn on automatically.
5. Tighten the screw with #4 Phillips head screwdriver. Be sure
not to over tighten.
©2017, Industrial Test Systems, Inc. Printed in USA
PHOTOMETER OVERVIEW
®
PHOTOMETER IS IDEAL FOR TESTING
®
AND MORE!
CELL COVER
Covers the cell for
mixing and bright
light situations
.
®
,
LIGHT SOURCE
Uses 525nm or
570nm wavelength,
depending on model
purchased, and
11mm path-length
for testing
LCD DISPLAY
Displays results
and test name
READ BUTTON
Starts test timer
ZERO/ON BUTTON
Powers on the
meter and creates
a baseline for your
water testing
Protected against the effects
of immersion in water to depth
between 15 cm and 1 meter
SCREW
Unscrew to
remove base
