EXACT IDIP
TESTS & REAGENTS
®
RANGE
PARAMETER / TEST
PART #
ppm
Alkalinity, Total
486641
10 – 200
Alkalinity, Total Range Extender
486665
Each strip adds 130 ppm
2
Bromine, Total (DPD–1)
486636
0.08 – 17
Chloride (as NaCl)
486757
4 – 335
Chloride (as NaCl) High
2
486757
77 – 6700
Chlorine Dioxide (DPD-1)
486633
0.06 – 6
2
Chlorine, Free (DPD–1)
486637
0.01 – 12
3
Chlorine, Combined (DPD–3)
1,2
486638
0.01 – 12
Chlorine, Total (DPD–4)
3
486670
0.01 – 12
Chlorine, Total High
486672
1 – 200
Chromium (Cr
)
486614
0.01 – 2.00
+6
Copper (as Cu
+2
)
486632
0.06 – 9
Cyanuric Acid
481652–II
3 – 110
Hardness, Calcium (as CaCO
)
486629
3 – 700
3
Hardness, Calcium (Salt Pools)
486629
20 – 900
Hardness, Calcium (Marine Water)
486629
30 – 1200
Hardness, Total High (as CaCO
)
486656
60 – 600
3
Hardness, Total Conditioner
486666
Use when Alkalinity >200
2
Hardness, Total Low (as CaCO
)
486630
1 – 80
3
Hydrogen Peroxide
486648
1 – 130
Hydrogen Peroxide High (DPD-4)
486676
16 – 4200
Hydrogen Peroxide Low
486616
0.02 – 3.5
Iodine (DPD–1)
486627
0.08 – 21
Iron, Total (TPTZ)
2
486650
0.03 – 8
Manganese (as Mn
)
486606
0.03 – 2.6
+2
2
Metals (+2)
486604
0 – 1.75
Molybdate
486653
0.02 – 5
2
Nitrate (as NO
) (Fresh Water)
486655
0.25 – 32
3
Nitrate (as NO
) (Marine Water)
486655
4 – 100
3
Nitrite (as NO
)
486623
0.02 – 4
2
Ozone (DPD-4)
486634
0.01 – 2
Peracetic Acid Low (DPD-4)
486674
0.05 – 11
Peracetic Acid
486675
0 – 590
Permanganate (DPD–1)
486626
0.02 – 6
pH-II
486639-II
6.4 – 8.4 pH
pH, Acid
486624
3.5 – 6.2 pH
pH, Alkali
486609
7.5 – 10 pH
Phosphate (as PO
)
486814
0.02 – 4
4
Sodium Bromide, Total (as NaBr)
486659
19 – 400
Sulfate (as SO
)
486608
1 – 270
4
Sulfi de (as S
2–
)
2
486818
0.11 – 5.3
Turbidity
N/A
24 – 780 NTU
2
†
Value provided represents best possible accuracy under laboratory conditions, but may vary throughout the detection range.
For a complete list of accuracies throughout all ranges, please visit exactidip.com.
1
Combined Chlorine DPD-3 Test requires Free Chlorine DPD-1 (486637) to be run fi rst.
Test uses a non-standard test method. Visit exactidip.com for details.
2
Requires the use of 2 strips if reading is above 6 ppm.
3
EXACTIDIP
IDIP QUICK START GUIDE R032116
% BEST
# OF
†
TESTS
ACCURACY
7.5
100
100
3
100
5
25
5
25
5
100
5
100
5
100
5
100
5
50
8
50
2
50
9
60
5
50
5
50
5
50
12
50
50
15
100
5
50
8
100
7
50
4
100
8
50
6
24
6
25
10
50
8
50
14
50
3
50
10
100
4
100
5
100
5
100
0.2 pH
100
0.3 pH
50
0.3 pH
50
8
50
5
25
5
50
12
50
N/A
N/A
#iDipwatertester
SMART PHOTOMETER SYSTEM
®
with
®
QUICK START GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iDip 570 and is the answer not in the manual?

Questions and answers

Related Manuals for eXact iDip 570

Summary of Contents for eXact iDip 570

  • Page 1: 570 Hardness, Total Low 486630

    EXACT IDIP TESTS & REAGENTS ® RANGE % BEST # OF † PARAMETER / TEST PART # TESTS ACCURACY SMART PHOTOMETER SYSTEM ® Alkalinity, Total 486641 10 – 200 with Alkalinity, Total Range Extender 486665 Each strip adds 130 ppm Bromine, Total (DPD–1)

  • Page 2: Table Of Contents

    SPA Bromine, Total 486654 0.08 - 17 Carrying Case for eXact iDip ......® SPA Calcium Hardness (as CaCO...

  • Page 3: Welcome

    ® in our convenient carrying case! Thank you for your eXact iDip purchase! This guide will quickly ® walk you through the technical details of your new eXact iDip CARRYING CASE FOR EXACT IDIP IDIP KIT ® ® This guide includes initial set-up, downloading the app, test Made of sturdy material lined with procedures, and tips.

  • Page 4: Warranty (2 Years)

    Each case comes with a neoprene armband and battery corrosion damage, or improper use. If the meter is faulty lanyard making it easy to use with your eXact iDip ® or otherwise defective contact ITS by phone (1-803-329-9712 Ext.

  • Page 5: For Best Accuracy

    ABOUT FOR BEST ACCURACY All tests that begin with 570 are for use with the eXact iDip ® EXACT IDIP ACCURACY ® photometer only. Combined with your smart device, the eXact iDip photometer is ® designed to test your water for multiple water quality parameters.

  • Page 6: Exact Idip Photometer Overview

    UNITS same wavelength and delivers the same chemicals in the same meter and creates a baseline for your proportions as AWWA method 3500-Cr B. The eXact iDip ® water testing photometer cannot be used for compliance monitoring because the photometer wavelength of 570nm is outside of the required 490nm–530nm range.

  • Page 7: Getting Started

    ® to communicate with each other wirelessly. The eXact iDip ® download the latest update to ensure you are using the comes standard with the latest Bluetooth 4.0 technology...

  • Page 8: 570 Chlorine, Free (Dpd-1) 3 486637 0.06 - 15

    “Er1” on No result sent to Close & restart app. Galaxy Grand Duos One Mini eXact iDip eXact iDip from app Reconnect to eXact iDip ® ® ® Galaxy Grand Neo One Mini 2 “Er2” on No connection Connect eXact iDip ®...

  • Page 9: Compatible Smart Devices

    LENOVO G Pad Xperia Tablet Z Nexus 7 (2013) Xperia Tablet Z2 Nexus 9 The eXact iDip ® photometer requires the use of a smart device with Bluetooth h Bluetooth ® 4.0 and Android 4.3 or greater. VIEW EXACT IDIP COMMERCIAL ®...

  • Page 10: Exact Idip App Overview

    EXACT IDIP APP OVERVIEW MANAGING DATA ® SAVE TO RESULTS MENU: In 'Results' screen, tap 'Save' to store into 'History'. A Opens HOME SCREEN 'Saving Results' screen appears, tap 'OK'. Your result is slide-out for easy access to now successfully saved.

  • Page 11: Using The Exact Idip ® App

    'Results' at the HOW TO CHANGE THE TIMEOUT DURATION bottom of the screen. The timeout setting is used to turn off the eXact iDip ® photometer. The default setting is 5 minutes, however this can be adjusted. To do this, tap 'Settings' in the Menu slide-out and tap either '+' or '–'.

  • Page 12: History

    USING THE EXACT IDIP AUTO-CALCULATED METHODS ® Visit exactidip.com or exactidip570.com for complete test instructions. HISTORY LANGELIER SATURATION INDEX (LSI) The History stores all your saved test result Use the STANDARD STRIP METHOD as illustrated on page 18 information and allows you to sort by date, to perform tests for Total Alkalinity, Calcium Hardness, and customer name, or test type.

  • Page 13: Calendar

    AUTO-CALCULATED METHODS USING THE EXACT IDIP ® Visit exactidip.com or exactidip570.com for complete test instructions. CALENDAR MAGNESIUM HARDNESS Never miss an appointment! With the app’s Use the STANDARD STRIP METHOD, as illustrated on page Calendar feature, you can access your device’s 18 to perform tests for Total Hardness and Calcium calendar directly from the app.

  • Page 14: Select Customer

    For helpful tips regarding test procedures, Tilt meter to discard about 0.2mL water in order to leave refer to tips “FOR BEST ACCURACY” on page 5. room for liquid reagent. Shake the bottle of eXact ® SELECT CUSTOMER Reagent (e.g.

  • Page 15: Select Bluetooth ® Test

    If not, ® select your eXact iDip from the bottom of the screen. ® Note : Ensure you always connect your eXact iDip photometer ® via the Bluetooth ® connection within the app. To verify connection DIP STRIP AND PRESS READ look for the Bluetooth icon in the upper right corner of your photometer.

  • Page 16: Fill Cell

    STRIP METHOD FILL be tested and to the top to begin test. The STANDARD STRIP METHOD (page 18) applies to both the eXact iDip ® photometer and the eXact iDip ® 570 photometer unless otherwise stated (some tests require a count-up time, listed below).
