SYS 600C 2.93
40
MicroSCADA Pro
Product Guide
Modbus TCP
Nr of IEDs
Nr of IEDs / line
DNP serial
Nr of IEDs
Nr of IEDs / line
DNP LAN
Nr of IEDs
Nr of IEDs / line
Table 7.2: Impact on process communication
Function
Local process database
Mirroring
Hot Stand-by redundancy
Gateway / NCC connections
Process display Workplace
Trends Workplace with data
logging
Reports Workpace with data
logging
The following list shows some examples when IEDs are connected to SYS 600C with
the following Gateway or NCC connections and with Local process database:
• NCC connection with one DNP LAN communication including 84 IEDs resulting
in 1 000 process updates per second sent to one NCC
• NCC connection with two DNP LAN communications including 67 IEDs resulting
in 1 600 process updates per second sent to two NCCs
• NCC connection with one IEC 104 LAN communication including 158 IEDs
resulting in 1 900 process updates per second sent to one NCC
200
15 Limited mostly by maximum response time
200
15 Limited mostly by maximum response time
200 If I/O count is small, number of IEDs can be
bigger
15
Impact on pro- Comments
cess communica-
tion
- 0% Always included
- 2%
- 2%
- 25% - 0% - 25% when total data update rate to all NCCs
is 50% from the process data update rate
- 24% - 1% - 24% when Process display with 1 050 meas-
urement objects in Workplace
- 18% when Process display with 1 050 switch-
ing device objects in Workplace
- 4% when Process display with 150 measure-
ment objects in Workplace
- 2% when Process display with 150 switching
device objects in Workplace
- 1% Per Workplace with Trends with 10 curves on
30 seconds interval logging
- 1% Per Workplace with Measurement Reports with
15 min report
Total of 900 objects data logged by Measure-
ment Reports
1MRS757729
*)
*)
