1MRS757729
Issued:
16.11.2012
Version:
A/16.11.2012
6
6.1
MicroSCADA Pro
Product Guide
Hardware characteristics
Hardware
The following tables lists the SYS 600C hardware speci cations.
Table 6.1: Hardware specifications
CPU
Intel® Core 2 Duo 2.2GHz (T7400)
Chipset
Intel® 82945GM and ICH7R
Memory
2GB DDR2
VGA
Intel® 82945 chipset integrated graphic controller
BIOS
Award BIOS
Storage device
30GB SSD (default), 60GB SSD (optional)
Expansion slot
3 x PCI v2.3 slots
Serial ports
16 x RS232 at rear panel
LAN ports
Option 1: 2 x RJ45 + 4 x LC (LC 1GB only)
Option 2: 6 x RJ45
USB 2.0
2 x USB at rear panel
1 x USB at front panel
1 x USB internal
Audio
AC97 2.1
Keyboard/Mouse
PS/2
LC module data
SYS 600C uses the optical industrial grade SFP connector module FTM-
8012C-SLiG from Source Photonics (Fiberxon).
Module details: Data rate 1250Mb/s, wavelength 850nm, multimode,
temperature range -40°C ~ +85°C (-40°F ~ 185°F)
Power supply
88 - 132 VAC / 45 - 160 VDC
176 - 264 VAC / 200 - 370 VDC
AC Power supply frequency range is 47-63Hz
Redundant power supply is optional
Power supply supervi-
110VDC, 0.3A
sion contact
220VDC, 0.1A
Power consumption
60W max.
Heat production
60W max.
SYS 600C 2.93
35
