ABB MicroSCADA Pro SYS 600C 2.93 Product Manual page 37

1MRS757729
Issued: 16.11.2012
Version: A/16.11.2012
MicroSCADA Pro
Product Guide
Table 6.3: IEEE Std 1613-2003 standard compliance
Type test
IEEE C37.90.1
IEEE C37.90.3
IEEE C37.90.1
IEEE C37.90
IEEE C37.90
IEC 60870-2-1-1995
IEC 60870-2-1-1995
IEEE C37.90
IEEE C37.90
Table 6.4: Environmental standard compliance
Type test
IEC 60068-2-1
IEC 60068-2-2
IEC 60068-2-30
IEC 60068-2-3
IEC 60870-2-2-1996
IEC 60870-2-2-1996
IEC 60068-2-29-1987
IEC 60068-2-29-1987
Description
EFT
ESD
Oscillatory Wave
Dielectric Strength
Impulse Voltage
DC Voltage Ranges
Voltage Ripple of DC
Nonoperational Temperature
Range
Operational Temperature
Range
Description
Cold Temperature
Dry Heat Temperature
Humidity (Damp heat, Cyclic)
Humidity (Damp heat, Steady
state)
Vibration
Shock
Bump (Packed)
Bump (Unpacked)
SYS 600C 2.93
Severity level
Level 4- ±4KV 5KHz All ports
Level 4 -±8KV Contact/±15KV
Air
Level 3-2.5KV common/Differ-
ential 1.25KV for Substation
2000Vrms
5000V
-20%~+15%
Level VR3- ≤5%
-40°C~+75°C
-30°C (Start Up)~+65°C
Severity level
-30°C Start Up for 16 hours
+65°C Start Up for 16 hours
Test Db 6 cycles +25°C/+55°C
93%/95% (1 cycle=24hrs)
95% (non-condensing) 40°C 2d
10-200-500-200-10Hz (1g/1.5g)
X/Y/Z axes
10g 11ms X/Y/X axes
10g, repeat 1000 times X/Y/Z
axes
10g, repeat 1000 times X/Y/Z
axes
37
