ABB MicroSCADA Pro SYS 600C 2.93 Product Manual page 26

SYS 600C 2.93
26
MicroSCADA Pro
Product Guide
Figure 4.5: SYS 600C as Control System HSI
To reduce the number of devices at the substation level, SYS 600C Control System HSI
and the Communication Gateway function can be combined in the same computer as
shown in Figure 4.6.
Figure 4.6: SYS 600C as combined Control System HSI and Communication Gateway
For increased availability, SYS 600C can be con gured as a redundant Control System
HSI and integrated Communication Gateway with redundant communication lines to
Remote Control Center as shown in Figure 4.7.
Figure 4.7: SYS 600C as redundant Control System HSI and integrated Communication Gateway
SYS 600C can also be utilized as an HSI for station RTU as shown in Figure 4.8.
1MRS757729
