Computer Options - ABB MicroSCADA Pro SYS 600C 2.93 Product Manual

SYS 600C 2.93
5.3
34
MicroSCADA Pro
Product Guide
System option Description
and interface
OPC A&E Client The OPC A&E client is used to connect foreign devices
to SYS 600 by means of the OPC A&E interface.
You need one client for each server that is to be connec-
ted.
SQL Export The SQL Export option provides a tool and functions for
browsing the process database and exporting process
data to a relational database.
The export can be done either event based or cyclically.
Historian data- This option specify the number of Historian database the
bases system server will connect
Historian tags This option specify the total number of tags the system
server will write (in all databases together)
Historian worksta- This option specify the number of workplaces totally in all
tions Historian systems the system server will write data to

Computer options

The SYS 600C computer options are presented in the following tables.
Table 5.6: Hardware
Hardware
Power Supply: 88 - 132 VAC / 45 - 160 VDC (Single or redundant)
Power Supply: 176 - 264 VAC / 200 - 370 VDC (Single or redundant)
Ethernet ports: 2 RJ45 + 4 x LC (LC 1GB only) or 6 x RJ45
Memory Disk: 30GB SSD (default), 60GB SSD (optional)
Table 5.7: Operating systems
Operating system
Windows 7 32-bit, English version
Windows 7 32-bit, Chinese version
Windows Server 2008 R2 64-bit, English version
Windows Server 2008 R2 64-bit, Chinese version
1MRS757729
Value
0...4
Yes/No
0....10
0....200 000
0....20
