1MRS757729
Issued:
16.11.2012
Version:
A/16.11.2012
5.2.2
MicroSCADA Pro
Product Guide
Slave protocol
F4F Westinghouse, No gateway support
Modbus RTU (CPI)
HSI features
The following table lists the SYS 600C HSI features.
Table 5.3: User interface options
User interface
Description
option
Nr of Pro work-
This is the number of workplaces that are in use simultan-
places
eously. The number of workplaces needed is defined in
the following way: - A workplace means a computer (PC,
Laptop, PDA, ThinClient), which can have one or several
physical screens from where ONE person at a time can
operate. - Several Application Windows can be used in
one workplace.
Process displays
Select this option, if you want to use Process Displays in
the workplaces. Process Displays means displays with
zooming, panning, and decluttering functions typically
used to present the primary process, for example, single-
line diagram.
Network coloring
Select this option, if you want to use dynamic network
coloring in the Process Displays.
Trends
Select this option, if you want to use the Trend displays
in the Workplaces.
Event list
Select this option, if you want to use the Event List dis-
plays in the Workplaces.
Alarm list
Select this option, if you want to use the Alarm List dis-
plays in the Workplaces.
Blocking list
Select this option, if you want to use the Blocking List
displays in the Workplaces.
Measurement re-
Select this option, if you want to use the Measurement
ports
Report displays in the Workplaces.
This option requires the History Data Logging option.
PCM600 interface
Select this option, if you want to integrate PCM600 Tools
in the Process Displays.
LIB 510/542 IED
Select this option, if you want to integrate LIB 510/542
Tools
IED Tools in the Workplace.
If you use only the IED tools in the Workplace, no other
LIB license in needed.
SYS 600C 2.93
Value
0...10
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
Yes/No
31
