- Page 1 TW PTO/100G WOOD CHIPPER INSTRUCTION MANUAL timberwolf-uk.com...
- Page 2 © Copyright Entec Industries Ltd 2015 The content of this publication may not be copied, reproduced, republished, posted, broadcast, transmitted or used in any way in any medium without the written permission of Entec Industries Ltd.
-
Page 3: Table Of Contents
TIMBERWOLF CONTENTS TW PTO 100G Section Page No. INTRODUCTION PURPOSE OF MACHINE MACHINE DIMENSIONS & SPECIFICATIONS PARTS LOCATION DIAGRAMS SAFE WORKING Operator’s Personal Protective Equipment Required Basic Woodchipping Safety General Safety Matters - Do’s and Dont’s Noise Test OPERATING INSTRUCTIONS Safe Transportation Delivery Operator’s Personal Protective Equipment Required... -
Page 4: Introduction
- EqUIPMENT DAMAGE - DAMAGE TO PROPERTY - 3RD PARTY INjURIES This manual covers the operation and maintenance of the Timberwolf TW PTO/100G. All information in this manual is based on the latest product information available at the time of purchase. -
Page 5: Purpose Of Machine
100mm in diameter. The Timberwolf PTO/100G brushwood chipper is required to be securely coupled to the pin hitch of an 18 - 40hp compact tractor unit with 540rpm PTO when in use. Power from the attached compact tractor unit is to be supplied to the chipper via PTO drive shaft. -
Page 6: Parts Location Diagrams
TIMBERWOLF TW PTO 100G PARTS LOCATOR DISCHARGE BUCKET ROTOR HOUSING FEED FUNNEL BELT GUARD DISCHARGE TUBE DISCHARGE CLAMPS PTO SHAFT STAND TOW HEAD PTO SHAFT FRONT GUARD SUPPPORT... - Page 7 TIMBERWOLF TW PTO 100G PARTS LOCATOR FAN SECTION (X2) ROTOR CUTTER BLADE (x2) FRONT BEARING ROTOR DRIVE PULLEY BELTS GEARBOX REAR BEARING BREATHER PIPE...
-
Page 8: Safe Working
TIMBERWOLF SAFE WORKING TW PTO 100G WARNING The chipper will feed material through on its own. To do this, it relies on sharp blades both on the feed rollers and the chipper rotor. To keep the blades sharp, only feed the machine with clean brushwood. DO NOT put muddy/dirty wood, roots, potted plants, bricks, stones or metal into the chipper. -
Page 9: General Safety Matters - Do's And Dont's
TIMBERWOLF SAFE WORKING TW PTO 100G GENERAL SAFETY MATTERS D O ’ S A N D D O N ’ T S ALWAYS stop the tractor engine, remove ignition DO NOT operate chipper unless available light is key and disconnect the PTO shaft before making sufficient to see clearly. -
Page 10: Noise Test
TIMBERWOLF SAFE WORKING TW PTO 100G NOISE TEST MACHINE: TW PTO/100G NOTES: Tested chipping green conifer 25 mm-40 mm Noise levels above 80dB (A) will be experienced at the working position. Wear ear protection at all times to prevent possible damage to hearing. All persons within a 4 metre radius must also wear good quality ear protection. -
Page 11: Operating Instructions
TW PTO/100G DELIVERY All Timberwolf TW PTO/100G machines have a full pre - delivery inspection before leaving the factory and are ready to use. Read and understand this instruction manual before attempting to operate the chipper. In particular, read pages 5-7 which contain important health and safety information and advice. -
Page 12: Connecting Pto Shaft
TIMBERWOLF OPERATING INSTRUCTIONS TW PTO 100G CONNECTING PTO SHAFT ALWAYS ENSURE THE TRACTOR IS TURNED OFF BEFORE FITTING OR REMOVING PROP SHAFT. When fitting a PTO shaft it should always be remembered that 100 mm of overlap is required between the two sections of the shaft. -
Page 13: Blade Wear
TW PTO 100G BLADE WEAR The most important part of using a wood chipper is keeping the cutter blades sharp. Timberwolf chipper blades are hollow ground to an angle of 40 degrees. When performing daily blade checks ensure blade edge is sharp and free from chips, if there is any evidence of damage, or the edge is “dull”... -
Page 14: Service And Maintenance
MAINTENANCE THAT SHOULD BE APPLIED TO ANY PIECE OF MECHANICAL EQUIPMENT AND THE CHASSIS TO WHICH IT IS MOUNTED. AUTHORISED TIMBERWOLF SERvICE AGENTS ARE FULLY TRAINED IN ALL ASPECTS OF TOTAL SERvICE AND MAINTENANCE OF TIMBERWOLF WOOD CHIPPERS. YOU ARE STRONGLY ADvISED TO TAKE YOUR CHIPPER TO AN AUTHORISED AGENT FOR ALL BUT THE MOST ROUTINE MAINTENANCE AND CHECKS. -
Page 15: Service Instructions
SPARES Only fit genuine Timberwolf replacement blades, screws and chipper spares. Failure to do so will result in the invalidation of the warranty and may result in damage to the chipper, personal injury or even loss of life. -
Page 16: Safe Maintenance
NOTE: There will normally be a rapid drop in tension during run-in period for new belts. When new belts are fitted, check the tension every 2 - 3 hours and adjust until the tension remains constant. Belt failures due to lack of correct tensioning will not be covered under your Timberwolf warranty. Remove the belt guard. -
Page 17: Change Blades
TIMBERWOLF SERVICE INSTRUCTIONS TW PTO 100G CHANGE BLADES Wear riggers gloves for the blade changing operation. WARNING 6. Before fitting a new blade ensure the Remove the feed funnel. seating surface on the rotor is spotlessly Insert M10 screw into rotor to stop it turning. -
Page 18: 15 Warranty Statement
Industries Ltd as a hire chipper or long term demonstrator – in these situations they are duly authorised to transfer any remaining warranty period to their first end user. Any warranty offered by the Timberwolf Dealer beyond the original 36-month period will be wholly covered by said Dealer. -
Page 19: Ec Declaration Of Incorporation Certificate
TIMBERWOLF TW PTO 100G CERTIFICATE OF CONFORMITY... -
Page 20: Identification Plate
TIMBERWOLF TW PTO 100G IDENTIFICATION PLATE... -
Page 21: Decals
DECALS TIMBERWOLF TW PTO 100G Decal Description Decal Description 2949 Lifting eye is designed to lift the machine’s weight only. Do not use hoist hook directly on lifting eye. Use correctly rated High velocity discharge - safety shackle only through lifting keep clear eye.Lifting eye to be inspected... - Page 22 TIMBERWOLF TW PTO/100G 1363 1849 3012 3013 P*161...
-
Page 23: V-Belt Tensioning Table
5. Take the reading from the deflection scale of the tension meter (read at the lower edge of the 'o'-ring) & compare this value with that given in the table. 6. Tighten or loosen belts as required following procedure given in this operator's manual. Tension gauges are available from Timberwolf spares, quoting part no. 18091 Rotor Pulley Engine Pulley... - Page 24 (blank page)
-
Page 25: Parts Lists
TIMBERWOLF TW PTO 100G PARTS LISTS The following illustrations are for parts identification only. The removal or fitting of these parts may cause a hazard and should only be carried out by trained personnel. Page No. CHASSIS / ROTOR HOUSING DECALS See pages 18 &... - Page 26 23 CHASSIS/ROTOR HOUSING TIMBERWOLF TW PTO 100G 15 14 Item Part No Part Name q’ty Item Part No Part Name q’ty 1096FO Front Plate 0524P Access Cover 18454FO Rotor Housing 0371 M10/70 Bolt 0644 M12 P Nyloc Nut 0701 M10 A Washer...
- Page 27 DISCHARGE TIMBERWOLF TW PTO 100G...
- Page 28 25 DRIVE TRAIN TIMBERWOLF TW PTO 100G Item Part No Part Name q’ty Item Part No Part Name q’ty 18947M Rear Shaft 0644 M12 P Nyloc Nut 18961M Key 10x8x80 1531FS Gear Box Bracket 1533 Belt 900 SPA 0701 M10 A Washer...
- Page 29 FUNNEL/BELT GUARD TIMBERWOLF TW PTO 100G Date Last Modified: 24th Oct 14 Item Part No Part Name q’ty Item Part No Part Name q’ty 0693 Feed Tray 0391 M6 T Nyloc Nut 0691O Funnel 0712 M8 C Washer 1013FO Belt Guard...
- Page 30 TIMBERWOLF 125PH T IMBERWOLF ROTOR TW PTO 100G Item Part No Part Name q’ty Item Part No Part Name q’ty 0959 Plastic Cap 1571 Fan Section 0884MS Front Bearing Housing 0386 M10/30 Caphead 0318 M12/20 Hex Set 0071H Blade 0415...
-
Page 31: Warranty Service Check Record
TIMBERWOLF 125PH TIMBERWOLF WARRANTY SERVICE CHECK RECORD TW PTO 100G 50 HOUR SERVICE Authorised dealer stamp Date: Hours: Invoice number: Signature: Next service due: 11 MONTH WARRANTY SERVICE CHECK Authorised dealer stamp Date: Hours: Invoice number: Signature: Next service due:... -
Page 32: Service Record
