- Page 1 ® XTENDEX Series ST-IPHD-L/R-2GOPOE HDMI Over Gigabit IP Extender with Power over Ethernet (POE) Installation and Operation Manual Front and Rear View of ST-IPHD-R-2GOPOE MAN304 Rev Date 1/18/2018...
- Page 2 TRADEMARK XTENDEX is a registered trademark of Network Technologies Inc in the U.S. and other countries. COPYRIGHT Copyright © 2018 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction..................................i MATERIALS ..................................1 Applications ..................................2 Connections- Point-to-Point............................4 Connections- Point-to-Many ............................4 Connections- Many-to-Many............................5 Technical Specifications..............................6 Warranty Information............................... 7... -
Page 4: Introduction
INTRODUCTION The XTENDEX® HDMI Over Gigabit IP Extender multicasts digital video and audio signals to one or more receivers up to 333 feet away over a 1000BASE-T Gigabit Network connected with CAT5e/6/7 cable. Each HDMI Over Gigabit IP Extender consists of a local unit that connects to an HDMI source, and a remote unit that connects to an HDMI display. -
Page 5: Materials
NTI HDMI Over Gigabit IP Extender MATERIALS Materials supplied NTI ST-IPHD-L or R-2GOPOE Transmitter or Receiver Materials Not supplied but REQUIRED: Cables Use HD-xx-MM cable to connect an HDMI source or display. Use DVI-HD-xx-MM cable to connect a DVI source or display. -
Page 6: Applications
NTI HDMI Over Gigabit IP Extender APPLICATIONS... - Page 7 NTI HDMI Over Gigabit IP Extender...
-
Page 8: Connections- Point-To-Point
NTI HDMI Over Gigabit IP Extender Connections- Point-to-Point 1. Connect a CAT5/6/7 cable up to 333 feet in length between the "1000BT LAN" ports of the Transmitter and Receiver. 2. Connect an HDMI-xx-MM cable (cables available in 3/6/10/15/20/30/50/75 foot lengths- sold separately) between the video source and the Transmitter. -
Page 9: Connections- Many-To-Many
NTI HDMI Over Gigabit IP Extender Connections- Many-to-Many Using the ST-IPHD-2GOPOE for a Many-to-Many configuration requires connection of all Transmitters and Receivers to a managed network switch and additional configuration software. For more information on the configuration of a Many-to-Many... -
Page 10: Technical Specifications
NTI HDMI Over Gigabit IP Extender TECHNICAL SPECIFICATIONS LAN Bandwidth: 180 to 500 Mbps Protocol: IP, UDP, TCP, ICMP, and IGMP Supports video wall installations from 1x2 to 16x16 screens. (See Control Methods for details.) Local Unit One female HDMI-A port for source connection. -
Page 11: Warranty Information
NTI HDMI Over Gigabit IP Extender Regulatory Approvals CE, RoHS Warranty Two years Control Methods Video Wall App Firmware provides video wall applications in sizes ranging from 1x2 to 16x16. Any combination is possible within those limitations (e.g. 2x4, 1x8, 5x5, 6x2).
