Panel Description - Icom IC-V8 Instruction Manual

1

PANEL DESCRIPTION

D Key pad
KEY
[name]
Access to secondary function
[A• ]
FUNC
Select the call channel. (p. 19)
[B• ]
CALL
Selects a memory mode. (p. 19)
[C• ]
MR
Selects VFO mode, aborts direct frequency input,
or cancels scanning, etc. (pgs. 16, 31)
[D• ]
CLR
Input digit "1" during frequency input, memory chan-
nel selection, etc. (pgs. 16, 19)
[1• ]
TONE
Input digit "2" during frequency input, memory chan-
nel selection, etc. (pgs. 16, 19)
[2• . ]
P BEEP
Input digit "3" during frequency input, memory chan-
nel selection, etc. (pgs. 16, 19)
[3• . ]
T SCAN
Input digit "4" during frequency input, memory chan-
nel selection, etc. (pgs. 16, 19)
[4• ]
DUP
Input digit "5" during frequency input, memory chan-
nel selection, etc. (pgs. 16, 19)
[5• ]
SCAN
Input digit "6" during frequency input, memory chan-
nel selection, etc. (pgs. 16, 19)
[6• ]
SKIP
3
FUNCTION SECONDARY FUNCTION (After [A•
No function.
No function.
Entering into memory programming/editing mode. (p. 25)
Programs/transfers VFO/memory or call channel contents into
memory channel/VFO when pushed for 1 sec. (pgs. 25, 26)
No function.
Selects a subaudible tone function. (pgs. 21, 35)
Turn the pocket beep function ON and OFF. (p. 37)
Starts the tone scanning. (pgs. 23, 38)
Selects a duplex function (–duplex, +duplex, simplex). (p. 21)
Starts scanning. (p. 31)
Sets and cancels skip setting for memory skip scan during mem-
ory mode. (p. 32)
1
PANEL DESCRIPTION
] is pushed)
FUNC
4
