Icom IC-V8 Instruction Manual page 31

11
OTHER FUNCTIONS
D D Squelch delay
Selects squelch delay from short and long to
prevent repeated opening and closing of the
squelch during reception of the same signal.
• Sqt. S: The squelch closes in short delay.
(default)
• Sqt. L: The squelch closes in long delay.
D D DTMF speed
The rate at which DTMF memories send indi-
vidual DTMF characters can be set to accom-
modate operating needs.
• 1: 100 msec. interval; 5.0 cps speed
• 2: 200 msec. interval; 2.5 cps speed
• 3: 300 msec. interval; 1.6 cps speed
• 5: 500 msec. interval; 1.0 cps speed
D D Dial assignment
Selects [VOL] control action from AF volume
and tuning dial.
• tOP.VO : AF volume
(default)
• tOP.dI : Tuning dial
D D Display type
Selects LCD indication type from frequency,
channel number and channel names.
• dSP.FR : Shows frequency (default)
• dSP.CH : Shows channel number*
• dSP.Nm: Shows channel names
*Memory channels can only be selected.
51
F
TX
MR
F
TX
MR
(default)
(cps=characters/sec.)
F
TX
MR
F
TX
MR
F
TX
MR
F
TX
MR
F
TX
MR
D D LCD contrast
Selects LCD contrast from auto and low.
• LCd.AT : Automatic (default)
• LCd.LO : Low contrast
D D Power save
Selects duty cycle for power save function
from auto, 1:32, 1:16, 1:8, 1:2 and OFF.
• P–S.At : Duty cycle changes automatically.
(default)
• P–S.32 : 1:32
(62.5 msec. standby: 2 sec.
duty cycle;
power saved)
• P–S.16 : 1:16 (62.5 msec. standby: 1 sec.
power saved) duty cycle
• P–S. 8 : 1:8
(62.5 msec. standby: 500 msec. power saved)
• P–S. 2 : 1:2
(62.5 msec. standby: 125 msec. power saved)
• P–S.OF : The power save function turned OFF.
D D Tuning speed acceleration
The tuning speed acceleration automatically
speeds up the tuning speed when pushing
and holding [∫] or [√], or rotating [VOL]
rapidly.*
• S–S.At : The tuning speed acceleration is
activated. (default)
• S–S. m : The tuning speed acceleration is
not activated.
*When tuning dial is assigned with [VOL].
11
OTHER FUNCTIONS
F
TX
MR
F
TX
MR
F
TX
MR
duty cycle
duty cycle
F
TX
MR
F
TX
MR
52
